F r i e d r i c h
MAMMOMAT Nova - Opdima
Maintenance Instructions
System
MAMMOMAT 1000/3000/3000 Nova - Opdima
The protocol SPB7-230.105.03.05.02 is required for
these instructions
Print No.:
SPB7-230.101.03.05.02
Replaces: SPB7-230.101.03.04.02
06134709
SP
2003
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 02.06
written
Advertisement
Table of Contents
Related Manuals for Siemens MAMMOMAT 1000 Nova Opdima
Summary of Contents for Siemens MAMMOMAT 1000 Nova Opdima
- Page 1 Maintenance Instructions System MAMMOMAT 1000/3000/3000 Nova - Opdima The protocol SPB7-230.105.03.05.02 is required for these instructions 06134709 2003 © Siemens AG The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages.
- Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service pro- cedures.
-
Page 3: Table Of Contents
Final tests ............16 6 _______ Changes since the previous version _______________________________ 17 Siemens AG SPB7-230.101.03.05.02... -
Page 4: Training
General information General information Training • Training workshop or at least 1 installation MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG Page 4 of 18 02.06 CS PS SP Medical Solutions... -
Page 5: Required Documents
SPB7-230.203.13... 3000- Opdima® (included in the Opdima® delivery) • MAMMOMAT 1000/3000/3000 Nova - Opdima® Service SPB7-230.061.11 ... Instructions (included in the Opdima® delivery) Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima Page 5 of 18 Medical Solutions 02.06 CS PS SP... -
Page 6: Required Tools, Measurement And Auxiliary Devices
Test Pattern (07-555), http://www.nucl.com • Cleaning agents* specified in the Instructions for Use MAMMOMAT 1000/3000 Nova, chapter "Cleaning, disinfection" • Standard service tools* MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG Page 6 of 18 02.06 CS PS SP Medical Solutions... -
Page 7: Text Emphasis
NOTE NOTE contains information provided with special emphasis to fa- cilitate proper use of the equipment or proper execution of a pro- cedure, i.e. hints, tips. Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima Page 7 of 18 Medical Solutions 02.06... -
Page 8: Safety Information And Preventive Measures
Tests or adjustments that must be made with the radiation ON are identified by the radiation warning symbol. During these types of adjustments, radiation protective cloth- ing must be worn. MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG Page 8 of 18 02.06 CS PS SP Medical Solutions... -
Page 9: Checks
Opdima®, chapter "Instructions for obtaining the system host ID and host name". • Document country settings in the Maintenance Protocol • If applicable, document the network and printer parameters in the Maintenance Proto- col. Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima Page 9 of 18 Medical Solutions 02.06... -
Page 10: Checks
Be sure that the unit is installed in a clean environment and is not exposed to dust. • Check that the correct MO media is used. Only Sony standard media (Siemens part no. 66 33 734, Sony RMO-S561, 9.1 GB rewritable) can be used as MO media. •... - Page 11 • Check that the biopsy unit is safely locked to the MAMMOMAT. Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima Page 11 of 18 Medical Solutions 02.06...
-
Page 12: Test
Testing Test Test of units For instructions on how to test the units, see the Service Instructions for Opdima®, chapter "Test of units". MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG Page 12 of 18 02.06 CS PS SP Medical Solutions... -
Page 13: Calibration
• If the biopsy unit accuracy is not satisfactory, perform calibration according to the Ser- vice Instructions for Opdima®, chapter "Calibration of the biopsy unit". Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima Page 13 of 18 Medical Solutions 02.06... -
Page 14: Checks
"Check of Opdima AEC". Resolution For instructions on how to check the resolution, see the Service Instructions for Opdima®, chapter "Check of resolution". MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG Page 14 of 18 02.06 CS PS SP Medical Solutions... -
Page 15: Checks
Check that the camera is properly locked to the object table. UIs and SPEED info • Check whether all relevant UIs and SPEED info has been completed. • Check that the customer creates regular backups. Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima Page 15 of 18 Medical Solutions 02.06... -
Page 16: Final Tests
MAMMOMAT 1000/3000 Nova (chapter "Cleaning, disinfection") and repair any dam- aged paint. • System ON. Final test exposure Take one final test exposure. MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG Page 16 of 18 02.06 CS PS SP Medical Solutions... - Page 17 Changes since the previous version Changes since the previous version Document has been converted to the Data Management System - DMS. Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima Page 17 of 18 Medical Solutions 02.06 CS PS SP...
- Page 18 Changes since the previous version MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG Page 18 of 18 02.06 CS PS SP Medical Solutions...
