MAMMOMAT 1000/3000/3000 Nova
Installation
Installation and Start-Up Instructions
from serial No. 7000
Register 3
Print No.: SPB7-230.033.09.05.02
Replaces: SPB7-230.033.09.04.02
SP
© Sie mens AG 2001
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model
_or_ design,_are_
reserved.
English
Doc. Gen. Date: 06.01
66 08 033

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAMMOMAT 1000 Nova and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens MAMMOMAT 1000 Nova

Summary of Contents for Siemens MAMMOMAT 1000 Nova

  • Page 1 MAMMOMAT 1000/3000/3000 Nova Installation Installation and Start-Up Instructions from serial No. 7000 © Sie mens AG 2001 The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages. All rights, including rights created by patent grant or registration of a utility model...
  • Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or autho- rized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service procedures.

  • Page 3: Table Of Contents

    EMC measures at the cable entry ......5 - 1 Siemens-Elema AB Register 3 SPB7-230.033.09...
  • Page 4 Checking X-ray tube high voltage, tube current and mAs values ...10 - 5 M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD...
  • Page 5 Emergency stop ........14 - 3 Siemens-Elema AB Register 3 SPB7-230.033.09...
  • Page 6 Returning the LINA card ....... .19 - 8 M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD...
  • Page 7 OPDOSE settings ....... . . 21 - 6 22 ______Changes to previous version ____________________________________ 22 - 1 Siemens-Elema AB Register 3 SPB7-230.033.09...
  • Page 8 0 - 8 Contents This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 8 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 9: General

    Fixed object-table arm ("Wing 2" no counterweight) Generator with integrated Separate generator control panel and radiation shield Separate control console Free-standing radiation shield Fig. 1 Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 6 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...

  • Page 10: Mammomat 3000/3000 Nova

    Depending on the installation configuration, some points may be omitted. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 6 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 11: Meters And Appliances, Tools

    • Densitometer e.g PDA 81. • Service PC (e.g. Siemens Nixdorf PCD3-NSX/20 or similar) with connecting cable (PC- Generator), part no. 99 00 440 RE999. • Normi 7 test body (provided by the customer) or SIB phantom Type 42 001 (PTW or INAK).

  • Page 12: Important Notes On Start-Up

    Furthermore, the front page of the acceptance test certificate must also be completed with the operator´s data. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 6 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 13: Checking And Recording For The Dhhs Area Of Application

    The MAMMOMAT has been tested and adjusted at the factory, and should therefore be ready for operation after completion of the installation. The equipment is set to 400 V, 2-phase, on delivery. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 6...
  • Page 14 1 - 6 Prerequisites This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 6 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 15: Protective Measures

    Protective Measures after removing the covers from the the stand. Remove the protective strips only when the covers are to be mounted or when vertical adjustment of the swivel-arm system is necessary. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2...

  • Page 16: Delay Times Between Two Exposures

    100 min 15 max 200 min 30 max 300 min 45 max 400 min 60 max 500 min 75 M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 17: Preparatory Work

    As a general rule, the directional marks on the crates should be observed during trans- port, storage and unpacking. The stand crate is bolted together, while the cardboard box is secured with plastic straps. CAUTION Wear safety footwear! Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 8 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 18: Unpacking The Stand

    Upend the stand (4), with pallet (5) (two persons are required). Loosen the four bolts (6) and remove the pallet (5). M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 19: Removing The Transport Safeguards

    Transport safeguard for the lifting carriage Loosen the two screws (1/Fig. 3) and remove the red transport safeguard (2/Fig. 3). Reinsert screws (1/Fig. 3), they might be needed for service purposes. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 8...

  • Page 20: Transport Safeguard For The Rotary Motion

    Screw and spacer inserted from the inside of the stand Tighten the screw. Make sure that the transport safeguard is parallell to the stand. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 21: Protective Strips For The Metal Curtain

    Holders (2) for storing the protective strips when not in use, are provided on both sides of the curtain, see Fig. 7. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 8...

  • Page 22: Unpacking The Generator And Mounting The Radiation Shield (Optional)

    Remove the protective cover from the generator. Upend the generator (1/Fig. 8) and lift it off the pallet (2/Fig. 8) (two persons are required). M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 23 Mount the stanchions and lead-glass unit with 6 screws onto the generator (3, 4 / Fig. 8) (two persons are required). Cover the holes with plastic caps (7/Fig. 9). Fig. 9 Mounting the radiation shield Fig. 10 Siemens-Elema AB Register 3 SPB7-230.033.09 Page 7 of 8 M1000/3000/3000 Nova Solna, Sweden Rev.
  • Page 24 3 - 8 Preparatory work This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 8 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 25: Arranging The Components

    (option). The connection cable to the generator measures 10 m. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 6...

  • Page 26: Free-Standing Radiation Shield (Option)

    EMC (Electro Magnetic Compatibility) requirements. Remove the front cover (3) from the generator. Fig. 2 Removing the generator cover M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 6 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 27: Installing The Cable Ducts

    At the generator, cover the cable entry not used with the enclosed cover plate (7). Installations with separate control console For the connection cable separate control console – generator, additional cable ducts are required, unless the cables are to be laid underfloor. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 6...

  • Page 28: Laying The Cable Harness

    Anode rotation cable X9 Filament cable X8 Mains supply cables L1, L2 Protective ground Decompression-button cable (only with separate control console) M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 6 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 29: Installations With Separate Control Console

    ∅ 6.5 mm Plastic cap Wall-mounted cable duct is recommended ∅ 6.5 mm Vertical mounting Horizontal mounting Fig. 5 Wall-mounted control console Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 6 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01 SPS-UD Installation and Start-Up...

  • Page 30: Aligning The Stand

    If bolting to the floor is required, please refer to Chapter 20 "Bolt- ing the stand/generator to the floor" on page 20 - 1. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 6 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 31: Cable Connections

    Lay the cable harness from the stand to the generator and leave approximately 3 cm of the shielding at the U-bracket, see Fig. 1. Stow away excessive cable lengths as shown in Fig. 2. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 14...

  • Page 32: Note On Separate Control Console And Separate Generator

    5 - 8 for information on how to install the additional connection cable between the control console and the generator. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 14 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 33: Emc Measures On The Bottom Plate

    Fig. 7 in this chapter. NOTICE Do not remove insulation and do not ground the shields of the AEC signal cables to X10 and X11. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 14 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 34: Connecting The Stand Cable-Harness

    Make sure that there aren’t any air bubbles between the disc and the connector. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 14 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 35: Connecting The High-Voltage Connector

    Tighten the sleeve nut (2) by hand. Tighten the stop screws on the sleeve nut. Position the high-voltage cable (3) to the right in the generator and fasten with cable ties (4). Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 14...

  • Page 36: Connecting The Cable Harness To The Generator

    X10 and X11 at the end of the cable. Connect the AEC signal cable connectors, X10 and X11, to D700 X10 (5) and X11 (6). M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 14 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 37: Rotating Anode Cable X9

    Connect the two blue free wires from connector D711 X9 (1) to capacitor C51 (2). Clamp the cable to the chassis with a cable clamp (3). CAUTION When fitting the cable clamp, ensure satisfactory contact between shield braid (4) and chassis. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 7 of 14 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 38: Installations With Separate Control Console And Separate Generator

    Lay the connection cable in a free U-bracket. Fold the shield braid over the U-bracket and secure with a hose clamp as shown in Fig. 9. Fig. 9 Shielding the control console cable M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 8 of 14 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 39 T3/X30 at the side of the circuit board chassis. Connect the ground wire to the protective ground terminal below fuse F10, see Fig. 11. Protective ground T3/X30 Fig. 11 Connecting the cables from the separate control console Siemens-Elema AB Register 3 SPB7-230.033.09 Page 9 of 14 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 40: Main Voltage Connection

    Labels are included in the installation material. For more details about changing mains, insertion or removal of NOTICE jumpers, fuses, labeling etc., see Wiring Diagram. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 10 of 14 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 41: Connecting The Incoming Mains To The Stand (400 V, 2-Phase)

    GENERATOR STAND Incoming mains 208, 230, 240, 277 or 400 VAC P.E N L1 L2 L3 X899 X881 Fig. 14 Incoming mains, 2-phase Siemens-Elema AB Register 3 SPB7-230.033.09 Page 11 of 14 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01 SPS-UD...

  • Page 42: Connecting The Mains Supply To The Generator (400 V, 2-Phase)

    Wire marked L1 to F10 and L2/N to F20. Connect the protective ground wire from the stand to the generator (3). M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 12 of 14 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 43: Measures For Changing From 2-Phase To 1-Phase Connection

    Wiring Diagram for details. Connect the mains supply cable between stand and generator to fuses F10 and F20 on the generator. Wire marked L1 to F10 and L2/N to F20. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 13 of 14...
  • Page 44 5 - 14 Cable connections This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 14 of 14 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 45: Checks Before Powering Up The Generator

    Remove fuses F10 (1) and F20 (2) or, when single-phase supply, fuse F10 (1). Connect line resistance meter to fuse holders F10 and F20. Mains supply "ON". Carry out measurement. Mains supply "OFF". Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 4 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 46: Checking The Line Voltage In The Generator

    Z1 (5). There must be 195 V- 253 V between the terminals. Measure the voltage at the output of line filter Z1 it must lie within 195 V- 264 V. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 47: Checking The Supply Voltages

    System "ON". Check that the following orange diodes are "ON" on p.c. board D704: V39 (+15 V) V38 (-15 V) V41 (+5 V) V40 (+24 V) Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 4 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...
  • Page 48 6 - 4 Mains connection and power supply This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 49: Attaching The Swivel-Arm Covers

    Before installing the side covers, the cables are to be connected. MAMMOMAT 1000/3000/3000 Nova Connect cables X807 (1) to control-button circuit boards D807 (2). Connect ground wires (3) to patient handles (4). Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2...

  • Page 50: Attaching The Side Covers

    The front cover must not press against the collimator (risk of damage). Fasten the front cover to the side covers with two short screws (5). M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 51: Microprocessors

    Flashing rapidly. P.C. board D711: • V9 "ON" (line voltage on). • V13 "OFF" (system stand-by). • V11 "ON" (system on). • V16 "ON" (intermediate circuit - filament). Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2 M1000/3000/3000 Nova Solna, Sweden Rev.
  • Page 52 8 - 2 Checking the microprocessors This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 53: Checks Without High Voltage

    Press the exposure buttons on the control panel. The rotating anode shall start up. At the end of the time limit, the rotating anode is braked. Release the exposure buttons. System "OFF". Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2...
  • Page 54 9 - 2 Checks without high voltage This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 55: Preparation

    Set switch S2 (SS) to "ON" (upper position) on P.C. board D702. Remove the jumper and connect the mAs meter to mAs measuring sockets X3 and X4 on P.C. board D710. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 10...

  • Page 56: Kv-Adjustment

    Make an exposure and check that the DVM shows +2.700 V +0.010 V. Note the values in the kV-adjustment protocol on page 21 - 3. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 10 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 57 Do not overload the X-ray tube by making too many exposures in a short time. R43 does not need to be relocked with locking paint. Mains and system OFF. Disconnect DVM from R72 and R73. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 10 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 58: Filament

    Perform Learn filament for available options. Note the new values in the Test protocol (Filament). Only settings for Mo available for M1000. NOTICE M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 10 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 59: Checking X-Ray Tube High Voltage, Tube Current And Mas Values

    The accuracy of the mAs product must be &10%. Replace the jumper previously removed from sockets X3 and X4 on P.C. board D710. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 10 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 60: Oscilloscope Diagrams

    160 ms 20 ms/T NOTE Record the measured kV and mAs value in the Test protocol, page 21 - 7. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 10 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 61 2 V/T (1 T <=> 80 mA) 150 mA 2 V/T (1 T <=> 80 mA) 0.53 s 0.1 s/T 0.67 s 0.1 s/T Siemens-Elema AB Register 3 SPB7-230.033.09 Page 7 of 10 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...
  • Page 62 Small focus is selected by attaching a magnification table. NOTICE Record the measured kV and mAs value in the test protocol, page 21 - 7. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 8 of 10 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 63 1 V/T (1 T <=> 40 mA) 125 mA 1 V/T (1 T <=> 40 A) 100 ms/T) 100 ms/T ) total exposure time dependent on programmed sensitivity Siemens-Elema AB Register 3 SPB7-230.033.09 Page 9 of 10 M1000/3000/3000 Nova Solna, Sweden Rev.
  • Page 64 10 - 10 Checks with high voltage This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 10 of 10 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 65: Checking And Programming With The Service Pc

    OD variation then cannot be guaranteed. Primarily, use the correction tables for Kodak Min-R 2000 if the film/screen in question is a Kodak etc. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 22 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 66: Preparation Of Backup Floppy

    Copy the contents of AEC_inst to A: C:\AEC_inst> copy *.* a: Use this floppy for the remainder of the installation. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 67: Offset Compensation

    Test condition: 40 <= Doserate <= 62 <ESC> to exit 1 Help Exp support 10 Quit Fig. 1 Service PC-menu, Test offset compensation dialog Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 22 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...
  • Page 68 Repeat steps 6 to 8 until all exposure alternatives, as listed above, are covered. Remove metal plate (part no. 65 52 728). Exit the offset compensation test in service PC by pressing Esc. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 69: Configuration Of The Aec

    • One step (1/8 E.P.) corresponds to approximately 0.06 O.D. with an incremental gamma of 5. • Measure the optical density on the emulsion side of the film. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 22 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 70: Correction Of The Measured Optical Density (O.d.)

    Replenishing speed of developer and fixer (liquids) If possible, develop the film among other films when the developer is warm and stabilized. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 71 25 mm Film Measuring point O.D. Fig. 2 Position of AEC calibration plexi and film *Applicable on condition that the detector is placed in chest-wall position. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 7 of 22 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...

  • Page 72: Incremental Gamma

    Optical density Step above Density region of interest Step below 9 11 13 15 17 19 21 Sensitometer step numbers M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 8 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 73: Overview Of Work Routine

    "AEC Correction tables" on Page 11 - 10. "Sensitivity correction (fine setting)" on Page 11 - 19. "Sensitivity" on Page 11 - 20. "Copy H to D" on Page 11 - 21. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 9 of 22...

  • Page 74: Aec Correction Tables

    Grid slow speed % of max <ESC> to exit, <TAB> move to next entry field 1 Help 2 Save 10 Quit M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 10 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 75: Installation Of Aec Correction Tables

    Place the cursor by one of the desired Anode/Filter/Speed combinations. Press <F2>. Install new table New ID: 0000 <F2> to continue, <ESC> to exit Siemens-Elema AB Register 3 SPB7-230.033.09 Page 11 of 22 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...
  • Page 76 1 under "Calibrate correction tables" on Page 11 - 13. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 12 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 77: Calibrate Correction Tables

    Place the marker by one of the desired Anode/Filter/Speed combinations. Press <F3> to transfer the table. This message box is displayed while the service PC receives the correction table. Receiving correction table for Mo/Mo H 63% done Siemens-Elema AB Register 3 SPB7-230.033.09 Page 13 of 22 M1000/3000/3000 Nova Solna, Sweden Rev.
  • Page 78 Sensitivity correction Used: 0 New: 0 <F2> save, <F3> exp support, <F4> continue, <ESC> exit Fig. 5 Dialog Sensitivity correction M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 14 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 79 “Calibrate correction tables”, since measurements are relative to factory results at 1.5 O.D. The O.D. preferred by the customer can be adjusted later either in Sensitivity correction or Sensitivity. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 15 of 22...
  • Page 80 <ENTER> when ready or <ESC> to cancel. <ENTER> - ok / <ESC> - cancel Follow the instructions in the message box shown. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 16 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 81 When all desired object table groups are calibrated, press <F2> to install the calibrated correction table in the AEC. Installing correction table ID: 1104 for Mo/Mo H 29% done Siemens-Elema AB Register 3 SPB7-230.033.09 Page 17 of 22 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 82: Recalibration Of An Object Table

    Press <F2> to save. Recalibrate the desired object table group according to the normal procedure, from step 2, page 11 - 13. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 18 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 83: Sensitivity Correction (Fine Setting)

    If the value differs from 1.5 O.D. (or by customer preferred) adjust the values in dialog AEC - Sensitivity correction (Fig. 7). Repeat the procedure described in steps 2 to 6. Save with <F2>. Repeat this procedure for the other object tables if applicable. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 19 of 22...

  • Page 84: Sensitivity

    The O.D. preferred by the customer can be set with this NOTICE function. The customer’s own phantom(s) can also be used. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 20 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 85: Copy H To D

    1 Help 2 Copy 3 10 Quit Press <F2>. A dialog will appear during copying from H to D. When copying is completed the message “Transfer successful” appears. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 21 of 22 M1000/3000/3000 Nova Solna, Sweden Rev.
  • Page 86 11 - 22 Calibrating and adjusting the AEC This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 22 of 22 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 87: Testing The Aec-Function

    Page 11 - 1. These limits apply for film with max. incremental gamma 5.0. NOTICE It is important to make sensitometer exposures on all films to be measured. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 4 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 88: Testing And Adjusting Opdose

    0 - 30 mm Mo / Mo Fig. 3 Mammomat 1000 installations with single filter from serial no. 7400 / software version 4.2 M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 89 Save with the store button. Repeat the procedure described in steps 3-7 for the other used programs. Note the OPDOSE settings in the attached test protocol. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 4...
  • Page 90 12 - 4 Testing This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 91: Setting The Real Time Clock

    Select nominal line voltage ____ V with cursor keys < ↑ > < ↓ > and < ENTER>. Type in line impedance ____ Ω . Enter the measured line impedance. Calculated power is ___ kW. Max. possible tube power is displayed. Save the programmed values with <F2>. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2...
  • Page 92 13 - 2 Further programming This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 93: Rotary Motion

    (+135 degrees clockwise and -180 degrees counterclockwise). The projection angle is shown on the display at the lower part of the stand. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 1 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 94: Vertical Adjustment

    All eight vertical adjustment buttons (four on either side) must be checked. The switching off in upper and lower end position is effected by switches S881 and S884 respectively. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 95: Emergency Stop

    The button shall latch and all motorized movements of the equipment shall be blocked ("Er 824" shall appear). To reset the emergency-stop button, turn it clockwise. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 3 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 96 14 - 4 Checking the swivel-arm system This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 97: Checking And Adjusting The Field Light Time

    Switch on the field light by pressing switch (1/Fig. 1) or by pressing the compression foot switch (2/Fig. 2). The field light shall go out automatically after a preset period of time (normally 20 s.). Fig. 2 Foot switch Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 98: Adjusting The Field Light Time

    Program according to the following: Main menu: Select <Configuration>. Select <Miscellaneous>. Select <Illumination time>. Type in illumination time and save with < F2>. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 99: Checking The Compression Device

    Place a piece of soft material on the object table, for example a rolled up towel or a piece of foam-rubber (4/Fig. 1). Check the function of the foot switch for motorized compression/decompression (1) and (2) in (Fig. 2). Fig. 2 Foot switch Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 4 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 100: Decompression Button (Only With Separate Control Console)

    M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 101: Checking The Opcomp

    NOTICE OPCOMP has been thoroughly tested by Siemens. If any factors are changed, OPCOMP will no longer be an optimization of com- pression force and image quality according to Siemens’ clinical test.
  • Page 102 16 - 4 Checking the compression device and OPCOMP This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 103: Checking The Exposure Blocking

    % of max Grid slow speed % of max <ESC> to exit, <TAB> move to next entry field 1 Help 2 Save 10 Quit Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...

  • Page 104: Cassette Loaded Switch On

    The film cassette must be exchanged after each exposure. A sec- ond exposure before exchanging the cassette is not possible (exposure release is blocked). M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 105: General

    The light field must coincide with the radiation field within the following tolerances: &6.5 mm Left edge: &6.5 mm Right edge: &6.5 mm Back edge: &6.5 mm Front edge: Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 4 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01 SPS-UD...

  • Page 106: Measuring Procedure

    Write down the values of the centering cross corresponding to the side edges and the front edge of the object table. Release exposure (Mo/Mo). Develop exposed films. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 107: Evaluation

    . The other sides must be completely exposed. Repeat this check with all object tables and both "wings" (base plates). 1. adjust within the given tolerance in step 1 above if necessary Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 4...
  • Page 108 18 - 4 Checking the radiation field limitation This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 109: Final Procedures

    Select <Backup> <Copy installation area to floppy> <All>. Leave the program with <F10> when the backup is ready. Keep the backup floppy with other documentation for the MAMMO- NOTICE MAT in question. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 8 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 110: Removing The Measuring Instruments

    (2). Store the strips in the holders provided on both sides of the curtain. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 111: Mammomat Stand

    Be careful not to damage the cables at the cable outlet! Fit inner plastic strip (7) to the front and side covers and fasten with screws (8), eight on either side. Press on the outer plastic strip (9). Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 8...

  • Page 112: Fitting The Mammomat Cap

    Cable-outlet cover Fit the cable outlet cover (1) to the stand and fasten with screws (2) and contact washers (3). M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 113: Mounting The Front Cover Onto The Generator

    (incl mains cable) and any metallic part of the stand and generator which the patient/operator may come in contact with. The protective ground resistance must not exceed 0.2 Ω . Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 8...

  • Page 114: Face Shield

    19 - 6 Final procedures Face shield Fig. 5 Face shield Slide the face shield (1) onto the holder for external diaphragms. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 115: Warning Label On Control Panel

    Ð MAM00206 Fig. 6 Warning label on control panel Siemens-Elema AB Register 3 SPB7-230.033.09 Page 7 of 8 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01 SPS-UD Installation and Start-Up...

  • Page 116: Affixing The Identification Labels

    The metal plates (article no. 65 52 728 and 65 61 026) are to remain with the customer, for future use. Keep them with other material and documentation for the MAMMOMAT in question. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 8 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 117: Stand And Generator With Integrated Radiation Shield And Control Panel

    DIN 9021B, ISO 7093 or equivalent. Tighten the screws to 10 Nm. Make sure that the screws do not come in contact with any con- CAUTION ductive material such as reinforcing iron. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 4...

  • Page 118: Installation With Separate Generator

    Base plate for separate generator Generator secured with wall brackets Fig. 3 Base plate and wall brackets for separate generator M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 119: Free-Standing Radiation Shield (Option)

    Free-standing radiation shield (option) Fig. 4 Free-standing radiation shield The free-standing radiation shield must be bolted to the floor, see separate instructions enclosed with the radiation shield. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 4 M1000/3000/3000 Nova Solna, Sweden Rev.
  • Page 120 20 - 4 Bolting the stand/generator to the floor This page intentionally left blank. This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 4 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 121: Working With The Service Pc

    < ∗ > key and then release both keys. <F1> Key <F1> calls up a selective help text. <F10> Key <F10> exits the program. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 8 M1000/3000/3000 Nova Solna, Sweden Rev.

  • Page 122: Connecting The Service Pc

    Save the entered data with <F2>. Page back in the program with <ESC>. The appropriate instructions are shown on the monitor. End the procedure with the service PC with <F10>. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

  • Page 123: Test Protocol

    Use this protocol with the instructions in "Filament" on Page 10 - 4. Anode Filament current Large focus molly Large focus tungsten Small focus molly Small focus tungsten Siemens-Elema AB Register 3 SPB7-230.033.09 Page 3 of 8 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...

  • Page 124: Aec Performance Test

    W/Rh 25 kV, 6 cm plexi* W/Rh 32 kV, 2 cm plexi Tolerances: BOD e 0.30 absolute corr corr M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 4 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 125 Mo/Rh 26 kV, 6 cm plexi* Mo/Rh 32 kV, 2 cm plexi Tolerances: BOD e 0.45 absolute corr corr Siemens-Elema AB Register 3 SPB7-230.033.09 Page 5 of 8 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01 SPS-UD Installation and Start-Up...

  • Page 126: Wing 2 M3000/3000 Nova

    Use this protocol with the instructions in "Testing" on Page 12 - 1. Density Speed button Anode/filter Breast below above corr correction (H or D) combination thickness M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 6 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 127 Required values 30 kV &5% ______V x 5 kV/V = _____kV 10 mAs &10% ______V x ____ s x 40 mA/V = ____ mAs Date:______________ Sign:____________ Siemens-Elema AB Register 3 SPB7-230.033.09 Page 7 of 8 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01...
  • Page 128 ______V x 5 kV/V = _____kV 125 mA &10% ______V x 40 mA/V = ____ mA Date:______________ Sign:____________ Keep measuring protocol in technical documentation. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 8 of 8 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...
  • Page 129 Changes to previous version 22 - 1 Chapter 0 Chapter completely revised. Chapter 11 Page 1 New correction tables in Table 1. Siemens-Elema AB Register 3 SPB7-230.033.09 Page 1 of 2 M1000/3000/3000 Nova Solna, Sweden Rev. 05 06.01 SPS-UD Installation and Start-Up...
  • Page 130 22 - 2 Changes to previous version This page intentionally left blank. M1000/3000/3000 Nova Register 3 SPB7-230.033.09 Page 2 of 2 Siemens-Elema AB Installation and Start-Up Rev. 05 06.01 SPS-UD Solna, Sweden...

This manual is also suitable for:

Mammomat 3000 nova

Table of Contents
