- Page 1 Operating instructions AS-i CompactModule M8 AC2490...
- Page 2 1 Preliminary note Technical data, approvals, accessories and further information at www.ifm.com. 2 Safety instructions • Read this document before setting up the product and keep it during the entire service life. • The product must be suitable for the corresponding applications and environmental conditions without any restrictions.
- Page 3 3 Functions and features • Maximum number of modules per master: 62 • AS-Interface version 3.0, downward compatible • 4 inputs / 4 outputs / AS-i profile S-7.A.7 / extended addressing mode: yes • The unit can only be operated in conjunction with a version 3.0 master (master profile M4).
- Page 4 Parameter bit Designation Description Periphery fault 1 peripheral fault indication active 0 peripheral fault indication not active 6 Addressing ► Addressing the unit via the M12 connector; the address is set to 0 at the factory. Addressing unit AC1154 1: SFC-i + / 2: TTL → / 3: SFC-i - Wiring of the addressing socket 4: TTL ←...
