Fluke 3130-G2M User Manual

Portable pressure calibrator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com
3130
Portable Pressure Calibrator
Users Manual
PN 4222409
February 2013
© 2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Fluke 3130-G2M

Summary of Contents for Fluke 3130-G2M

  • Page 1 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com 3130 Portable Pressure Calibrator Users Manual PN 4222409 February 2013 © 2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.

  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction ......................1 How to Contact Fluke Calibration ..............2 Safety Information ..................... 2 Standard Equipment ................... 3 Features ......................4 Buttons ......................4 Display ......................5 Calibrator Interface ..................6 Typical Connections ..................7 Power Options ....................
  • Page 4 3130 Users Manual Calibrate a Pressure-to-Current Transmitter ..........24 Calibrate a Pressure-to-Voltage Transmitter ..........25 %-Error Function ..................26 Storage Capability ....................29 Remote Operation ....................29 Set Up the RS-232 Port for Remote Control ..........30 Change from Remote to Local Operation ............31 Command Use ....................
  • Page 5 List of Tables Table Title Page Symbols ........................3 Mode Concurrency ....................13 Common Commands ....................33 Product Commands ....................34 Parameter Units ...................... 35 Error Codes ......................36 Replaceable Parts ....................43...
  • Page 6 3130 Users Manual...
  • Page 7 List of Figures Figure Title Page Buttons ........................4 Display ........................5 Controls ........................6 External Pressure Supply ..................7 Pressure Supply with Internal Pump ..............8 Pressure Measurement ................... 8 Menu Map ......................10 Top-Level Menu ..................... 11 Main Menu ......................12 Display Configuration Menu ..................
  • Page 8 3130 Users Manual...

  • Page 9: Introduction

    Introduction The Fluke 3130 (the Product) is a portable pressure calibrator that can use two methods to source pressure: • An internal, electronic pump that has a range of -12 psi to 300 psi (-0.8 bar to 20 bar) •...

  • Page 10: How To Contact Fluke Calibration

    For safe operation and maintenance of the Product: • Use only Fluke approved power adapters to charge the battery. See the “User-Replaceable Parts and Accessories” section.

  • Page 11: Standard Equipment

    Fluke’s website for recycling information. Standard Equipment Items included with the Product are in the list below. If the Product is damaged or something is missing, immediately contact Fluke Calibration. See the “How to Contact Fluke Calibration” section. • Printed 3130 Safety Information •...

  • Page 12: Features

    3130 Users Manual Features Product features and user interface information is in the subsequent sections. Buttons The Product buttons are on the left-side of the Product face and are shown in Figure 1. HOME ZERO PUMP hbb005.eps Button Description  Push to turn on the Product.

  • Page 13: Display

    Portable Pressure Calibrator Features Display The display can be made up of a maximum of three process measurement sections plus the menu bar which is always at the bottom of the display. The sections of the display are referred to by the Product and in this manual as UPPER, MIDDLE, LOWER, and menu bar. Push the softkeys that correspond to items shown on the menu bar to move through the Product menus.

  • Page 14: Calibrator Interface

    ZERO PUMP FINE VENT LINE BEFORE MAKING SELECTION ADJUSTMENT LOOP V mA 24 V DC SWITCH TEST CHARGE FLUKE CORPORATION SERIAL NO. EVERETT, WA USA 30 V MAX www.flukecal.com 16 V DC 5.6 A hbb006.eps Item Description Supply metering valve. Use the supply metering valve to regulate the incoming air supply.

  • Page 15: Typical Connections

    ZERO PUMP FINE VENT LINE BEFORE MAKING SELECTION ADJUSTMENT LOOP V mA SWITCH TEST 24 V DC CHARGE FLUKE CORPORATION SERIAL NO. EVERETT, WA USA 30 V MAX www.flukecal.com 16 V DC 5.6 A hbb002.eps Figure 4. External Pressure Supply...
  • Page 16 FINE VENT LINE BEFORE MAKING SELECTION ADJUSTMENT LOOP V mA 24 V DC SWITCH TEST CHARGE FLUKE CORPORATION SERIAL NO. EVERETT, WA USA 30 V MAX www.flukecal.com 16 V DC 5.6 A hbb003.eps Figure 5. Pressure Supply with Internal Pump...

  • Page 17: Power Options

    Portable Pressure Calibrator Power Options Power Options The Product can be powered with the internal, high-capacity NiMH battery and/or the universal power supply (90 V ac to 250 V ac) that charges the battery pack. The universal power supply can power the Product at the same time it charges the battery pack. A fully- discharged battery can take a maximum of 14 hours to recharge.
  • Page 18 3130 Users Manual Active Display Active Display hbb001.eps Figure 7. Menu Map...

  • Page 19: Top-Level Menu

    Portable Pressure Calibrator Product Menus Top-Level Menu The top-level menu is shown in Figure 8. It has three levels. hbb009.eps Figure 8. Top-Level Menu • MENU- Push the MENU softkey to get to the main menu. See the “Main Menu” section.

  • Page 20: Display Configuration Menu

    3130 Users Manual The main menu is shown in Figure 7 and has three levels. hbb010.eps Figure 9. Main Menu • CONFIG (Configuration) - Push  to access the config menu. Push  again to go to the Display Configuration menu. This will let you change the parameters for each display section.

  • Page 21: Zero Function

    Portable Pressure Calibrator Zero Function Table 2. Mode Concurrency Active Display P[1] [EXT] P[1]ST [EXT]ST Volts MEAS/24V P[1] [EXT] P[1]ST Other [EXT]ST Displays MEAS/24V Volts Zero Function When  is pushed, the Product zeros its active display if a pressure mode is selected, and the pressure is within the zero limit.

  • Page 22: Other Menu Controlled Functions

    3130 Users Manual Other Menu Controlled Functions There are many submenus below the main menu. These can be accessed through the MORE option of the main menu. A submenu contains three options. The first option is unique to the function. The second and third options are always the same. The NEXT option leads to the subsequent menu.

  • Page 23: Save And Recall Menu Setups

    Portable Pressure Calibrator Other Menu Controlled Functions Save and Recall Menu Setups The current Product setup is saved for recall at the next power up. Five different setups can be saved for later use. To access these setups, go through the menu list until SETUPS is shown.

  • Page 24: Activate And Deactivate A Display

    3130 Users Manual Activate and Deactivate a Display Use the DISPLAY menu to select which display to use. The ON/OFF option turns the selected display on or off. The selected display and current on/off state are shown in the lower display. See Figure 16. To choose which displays are active: 1.

  • Page 25: Initial Setup And Basic Pressure Generation

    Portable Pressure Calibrator Initial Setup and Basic Pressure Generation Initial Setup and Basic Pressure Generation The Product has a special low-volume calibration hose for faster pressure generation and quick pressure stabilization. "Quick-fit" hose connectors and different adapters are included. It is recommended that this hose is used to get the best results. After the fittings are installed and the Product is connected to the UUT (unit under test), the Product is ready for use.

  • Page 26: Media Compatibility

    The Product is only to be used with clean, dry gases. External Modules The Product has a digital interface to support the Fluke 700P series of pressure modules. These modules are available for different ranges that include gauge, vacuum, differential, and absolute pressure.
  • Page 27 Portable Pressure Calibrator Pressure Measurement 2. The same connections are used for the current source. Select mA-Source or mA Sim-2W from the configuration display. 3. This selection can only be made in the lower display. Also, in source mode, the Product generates 0...

  • Page 28: Measure Voltage

    3130 Users Manual Measure Voltage To measure voltage, use the connections on the front of the Product. Select the VOLTS function on one of the displays. The Product can measure to a maximum of 30 V dc. See Figure 19. Note The display shows "OL"...

  • Page 29: Pressure Switch Test

    VENT LINE BEFORE MAKING SELECTION ADJUSTMENT Pressure LOOP Switch V mA 24 V DC SWITCH TEST CHARGE FLUKE CORPORATION SERIAL NO. EVERETT, WA USA 30 V MAX www.flukecal.com 16 V DC 5.6 A hbb020.eps Figure 20. Switch Test Connections 3. Connect the Output of the Product to the pressure switch.
  • Page 30 3130 Users Manual 6. Apply pressure with the pump slowly until the switch opens. Note In the switch test mode, the display-update rate is increased to help capture changes to pressure inputs. Even with this enhanced sample rate, the UUT should be charged slowly with pressure to ensure accurate readings.

  • Page 31: Calibrate Transmitters

    Portable Pressure Calibrator Pressure Measurement 9. Select the "NEXT" option to show the pressure at which the switch closed and the deadband. See Figure 24. hbb024.eps Figure 24. Switch Test and Deadband Results 10. Select the "NEW TEST" option to clear the data and do another test. 11.

  • Page 32: Calibrate A Pressure-To-Current Transmitter

    PUMP FINE VENT LINE BEFORE MAKING SELECTION ADJUSTMENT LOOP V mA SWITCH TEST 24 V DC CHARGE FLUKE CORPORATION SERIAL NO. EVERETT, WA USA 30 V MAX www.flukecal.com 16 V DC 5.6 A hbb026.eps Figure 26. Calibrate a Pressure-to-Current Transmitter...

  • Page 33: Calibrate A Pressure-To-Voltage Transmitter

    PUMP FINE VENT LINE BEFORE MAKING SELECTION ADJUSTMENT Transmitter LOOP V mA 24 V DC SWITCH TEST CHARGE FLUKE CORPORATION SERIAL NO. EVERETT, WA USA 30 V MAX www.flukecal.com 16 V DC 5.6 A +24 V Power Common Signal Output hbb035.eps...

  • Page 34: Error Function

    FINE VENT LINE BEFORE MAKING SELECTION ADJUSTMENT LOOP V mA 24 V DC SWITCH TEST CHARGE FLUKE CORPORATION SERIAL NO. EVERETT, WA USA 30 V MAX www.flukecal.com 16 V DC 5.6 A hbb027.eps Figure 28. Connections with a Pressure Transmitter with % Error Function Example: If a pressure transmitter under test has a full-scale range of 2 bar and gives a 4 ...
  • Page 35 Portable Pressure Calibrator Pressure Measurement 3. The first option is the port setting. Use the "SELECT" option to scroll through the choice of ports (pressure connections). When this is done, select the "NEXT" option. See Figure 29. hbb028.eps Figure 29. Port Setting Screen 4.
  • Page 36 3130 Users Manual 6. Use the arrow keys to set the upper limit of the measurement range. Select DONE SET when finished. See Figure 32. hbb031.eps Figure 32. Setting the Upper Limit 7. Use the arrow keys to set lower limit of the measurement range, and select DONE SET when finished.

  • Page 37: Storage Capability

    Note To use the remote control option, a custom RS-232 cable must be purchased. See the “How to Contact Fluke Calibration” section. With this connection, you can write programs on the PC. Use Windows languages like Visual Basic to operate the Product, or use a Windows terminal like Hyper Terminal, for single commands.

  • Page 38: Set Up The Rs-232 Port For Remote Control

    1. Start Hyper Terminal (located on your computer in Accessories/Communications of the Windows Start menu). 2. Select New Connection. 3. For Name enter “Fluke 3130”. 4. Select the serial port that the Product is connected to. 5. Enter the above information for port settings.

  • Page 39: Change From Remote To Local Operation

    Portable Pressure Calibrator Remote Operation Change from Remote to Local Operation The Product uses three modes of operation: • Local • Remote • Remote with Lockout Local mode is the default mode. Commands can be entered with the buttons on the Product or with a computer.

  • Page 40: Character Processing

    For example: VAL? Shows 5.830000E01,PSI,0.000000E00,PSI,0.000000E+00,A Character Response Data (CRD) Data shown as keywords. For example: PRES_UNIT? Shows BAR,BAR,PSI Indefinite ASCII (IAD) Any ASCII characters followed by a terminator. For example: *IDN? Shows Fluke, 3130, 1234567, 1.00 (1234567 is the serial number)

  • Page 41: Calibrator Status

    Portable Pressure Calibrator Remote Operation Calibrator Status Error Queue If an error occurs from invalid input or buffer overflow, its error code is sent to the error queue. The error code can be read from the queue with the command FAULT?. The error queue holds 15 error codes.
  • Page 42 3130 Users Manual Table 4. Product Commands Command Description DAMP Turns on or off Damp DAMP? Show if DAMP is on/off DISPLAY Turns on or off the displays specified in the command DISPLAY? Shows which displays are on/off ERROR_LOOP Turns on or off loop power in percent error mode ERROR_LOOP? Shows the current state of loop power in error mode ERROR_MODE...
  • Page 43 Portable Pressure Calibrator Remote Operation Table 4. Product Commands (cont.) Command Description PRES_UNIT Set the pressure unit for the indicated display PRES_UNIT? Shows the pressure from the indicated display PUMP_LIMIT Sets the approximate value at which the pump will turn off PUMP_LIMIT? Shows the approximate value at which the pump will turn off REMOTE...

  • Page 44: Enter Commands

    Clears the error queue. Also ends all pending operations. When you write programs, use this command before each procedure to prevent buffer overflow. *IDN? Shows the manufacturer, model number, and firmware revision of the Product. For example: *IDN? Shows Fluke, 3130 0, 1.00...

  • Page 45: Calibrator Commands

    Portable Pressure Calibrator Remote Operation Calibrator Commands DAMP Turns on or off the dampening function. For example: If you send DAMP ON, this will turn the dampening function on. DAMP? Shows the current state of the dampening function. For example: If you send DAMP?, this will show ON if the dampening function is on.
  • Page 46 3130 Users Manual ERROR _LOOP? Shows the current state of loop power in percent error mode. For example: If you send ERROR_LOOP?, it will show ON if loop power is on in error mode. ERROR_ MODE Turns on or off percent error mode. For example: To turn on percent error mode, send ERROR_MODE ON.
  • Page 47 Portable Pressure Calibrator Remote Operation HART_ON Turns on the Hart resistor. HART_OFF Turns off the Hart resistor. HART? Shows the state of the Hart resistor. For example: If the Hart resistor was on, HART? shows ON. HI_ERR Sets the 100 % point for the percent error mode calculation in the current engineering units.
  • Page 48 3130 Users Manual LOCAL Returns the Product to local operation if it was in remote mode. The command also clears LOCKOUT if the Product was in lockout mode. LOCKOUT Sending this command sets the lockout state, when the unit is in REMOTE or goes to remote, it stops use of the keypad completely.
  • Page 49 Portable Pressure Calibrator Remote Operation This command also switches the Product into mA output mode. A number and a unit must be entered after the command. For example: OUT 5 MA sets the current output at 5 mA. OUT? Shows the output of the Product. Using the above example, OUT? shows: 5.000000E-03, A.
  • Page 50 3130 Users Manual Sets the output for current simulation. This command also switches the Product into mA simulation mode. A number and a unit must be entered after the command. For example: SIM 5 MA sets the current simulation at 5 mA SIM? Shows the output of the current simulation.

  • Page 51: Maintenance

    To prevent possible damage to the Product, do not use solvents or abrasive cleansers. User-Replaceable Parts and Accessories Table 7 lists the Fluke part number of each user-replaceable part or accessory for the Product. Table 7. Replaceable Parts Item Description...

  • Page 52: Specifications

    3130 Users Manual Specifications Specifications are valid for one year unless otherwise noted. Electrical Specification Measurement Inputs Range Accuracy 0.015 % of reading ±0.002 mA 0 mA to 24.000 mA 0.015 % of reading ±0.002 V Volts 0 mA to 30.000 V dc Outputs Range 4 mA to 24.00 mA...

  • Page 53: Standards And Agency Approval

    Portable Pressure Calibrator Specifications Media Compatibility ......... Any clean, dry, non-corrosive gas Standards and Agency Approval Safety ..............IEC 61010-1, 30V Max, Pollution Degree 2 Electromagnetic Environment ......IEC 61326-1: Basic/Portable Ingress Protection ..........IP67 (Case closed), IP40 (Case open) Vibration ............
  • Page 54 3130 Users Manual...
