ABSOLUTE MAXIMUM RATINGS

Symbol Description
V Supply Voltage*
CC
T Storage Temp
STG
T Oper Ambient Temp
A
Notes:
* Voltage on all pins with respect to GND.
† See ordering information

STANDARD TEST CONDITIONS

The characteristics listed here apply for standard test
conditions as noted. All voltages are referenced to
GND. Positive current flows into the referenced pin
(Figure 17).
STANDARD TEST CONDITIONS
T = 25°C, V = GND = 0V, f = 1.0 MHz, unmeasured pins returned to ground.
A CC
Parameter
Input capacitance
Output capacitance
I/O capacitance
4
Min Max Units
–0.3 +7.0 V
– 6 5 + 1 5 0 C
† †
Max
12 pF
12 pF
12 pF
Stresses greater than those listed under Absolute
Maximum Ratings may cause permanent damage to
the device. This is a stress rating only; operation of the
device at any condition above those indicated in the
operational sections of these specifications is not
implied. Exposure to absolute maximum rating condi-
tions for extended periods may affect device reliabil-
ity.
From Output
Under T est
Figure 17. Test Load Diagram
®
Z08617 NMOS Z8 8-B MCU
IT
K C
EYBOARD ONTROLLER
150 pF
