General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your lawn
& garden Spot sprayer.
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-800-831-0027
MONDAY-FRIDAY, 8:00 AM TO 5:00 PM CST
If you should have a question or experience a problem with
your Fimco Industries Product: Visit our website @
www.fimcoindustries.com or call the Toll free number above. Our
technical support representatives will be happy to help you.
In most cases a customer service rep. can resolve
the problem over the phone.
To obtain prompt, efficient service, always remember to give the
following information....
• Correct Part Description and/or part number
• Model number and Serial Number
Part descriptions and numbers can be obtained from the
illustrated parts list section(s) of this manual.
Retain a copy of your receipt for your
unit, as it will be required to validate
any warranty service.
Warranted against manufacturer or
workmanship defects from date of
purchase with copy of receipt:
Homeowner Usage: Sprayer-One Year and Pump-Two Years.
Commercial Usage: Sprayer and Pump-90 Days.
OWNER'S MANUAL
Model: LG-10-EC (5301547)
(10 Gallon Lawn & Garden Spot Sprayer)
WARNING:
Cancer and Reproductive Harm.
www.P65Warnings.ca.gov
WARNING:
To reduce the risk of injury, the
user must read and understand the operator's
manual before using this product.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5194787
(10/22)]
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fimco LG-10-EC
Summary of Contents for Fimco LG-10-EC
- Page 1 Warranted against manufacturer or workmanship defects from date of www.fimcoindustries.com purchase with copy of receipt: 1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049 Homeowner Usage: Sprayer-One Year and Pump-Two Years. Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440 [5194787 (10/22)] Commercial Usage: Sprayer and Pump-90 Days.
- Page 2 Tank Care and Winter Storage ..........4 Sprayer Exploded View/Parts List ........7 Pump Exploded View and Parts List ........4 Warranty ................8 Model: LG-10-EC (5301547) (10 Gallon Lawn & Garden Spot Sprayer) Technical Specifications • 10 Gallon Corrosion-Resistant Polyethylene Tank •...
- Page 3 Drain and then refill half full, add the recom- mended amount of a good quality tank cleaner, such as FIMCO Tank Neutralizer and Cleaner. (If no tank cleaner is available, you may substitute dish soap for this step, about 1-2 oz.
- Page 4 1.2 GPM - 60 PSI Available Replacement Parts Replacement Pump: 5151086 DON’T • • Clean and rinse your pump after each use with Fimco Tank Neu- Use to pump bleach. • tralizer. Use to pump petroleum products such as diesel fuel, gasoline or •...
- Page 5 Before Troubleshooting or Attempting to Service the Pump: ♦ Review Troubleshooting Chart: Do Not attempt to repair until steps below are followed. ♦ Personal Protective Gear: Wear protective gear when servicing pump. ♦ Disconnect Power: Disconnect the power to the pump and relieve the pressure from the system. ♦...
- Page 6 Sprayer and Pump FAQs: ♦ Why does the pump not run all the time? This is an on-demand pump and only runs when a discharge is open (spray gun, bypass, boom (if applicable) or a leak in the system. ♦ Why does the pump surge while using the spray gun? Low flow/high pressure may cause the pump to surge (or cycle).
- Page 7 Exploded View/Parts List: LG-10-EC (5301547) Intake Detail Page 7...
- Page 8 WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the conditions set forth above are fulfilled and the Equipment or any part thereof is found to be defective, Fimco, Ind. shall, at its own cost, and at its option, either repair or replace the defective Equipment or part.
