8 key multifunction control bus scs
Hide thumbs Also See for H4652:

Advertisement

Quick Links

8 key multifunction control
BUS SCS

Description

Flush mounted multifunction control, with 8 backlit keys in the centre section, where
the icons indicating the functions allocated to the keys can be found.
The device can be c
red in two di erent ways:
- Physical c
ration
, by inserting the c
- C
ration using the MyHOME_Suite software
the website www.homesystems-legrandgroup.com; this last type of c
has the advantage of o ering many more options when compared with the physical.
c
ration.
Irrespective of the mode implemented, an A/PL address must always be assigned to
the control.
In can be programmed in 4 operating modes:
- The self-learning mode
(cyclical or non cyclical) gives the possibility of associating
to each key the majority of the typical controls of the automation, sound, and video
door entry (staircase lights, door lock, call t
systems, in addition to the auxiliary controls.
- The scenario mode
gives the possibility of recalling, programming and deleting 8
scenarios of a scenario module.
- The swivelling mode
gives the possibility of driving 4 light points of shutters in
succession (room or group).
- CEN mode gives the possibility of using the control together with scenario
programmer MH200N or MH201.

Related items

3541 - 0 675 95 A5 sheets with symbol customisations, BLACK
3542 - 0 675 96 A5 sheets with symbol customisations, WHITE
For the customisation of the sheets, it is possible to use the tool found in the
MyHOME_Suite
software, which can be downloaded from the websi
te www.homesystems-legrandgroup.com.

Technical data

Power supply from SCS BUS:
18 – 27 Vdc
Absorption:
with LEDs O :
with LEDs On at 100%: 20 mA
Operating temperature:
0 – 40 °C
Standards, Cer
cations, Marks
EN 60669-2-1
EN 50491-5-1
EN 50428

Dimensional data

Siz
nted modules
rators in the appropriate housings.
, which can be downloaded from
ration
r, door lock and camera cycling)
-
5 mA
Front view
1
Rear view
5
4
Legend
Kyes
1.
Customisable labels
2.
Clamps for connection to the SCS BUS
3.
C
rator socket
4.
Programming pushbutton for self-learning and scenario modes
5.
0 675 92
H4652
LN4652
1
2
3
