This disassembly instruction is applicable to L1 task chair.
Mechanism
(Steel)
Cylinder
(Steel)
Casters x5 (Plastic
and Steel)
For material recycling information please refer to the End of Life Recovery Matrix
and List of Recycling Facilities, which is available at www.allseating.com.
Disassembly Instructions
L1 Task Chair
1
Document No:
Issue Date:
Revision:
Revised Date:
Headrest
(plastic + foam)
Backrest
(plastic)
Arms
(plastic)
Seat and Shroud
(plastic + foam)
Base
(plastic)
CDM-L1024
19-MAY-2020
0
