These disassembly instructions are also applicable to PRESTO and TWIST.
Arm
(Plastic/Steel
)
Seat
(Foam/Plywood)
Base
(Plastic)
For material recycling information please refer to the End of Life Recovery Matrix
and List of Recycling Facilities, which is available at www.allseating.com.
Disassembly Instructions
CHIROFORM
Document: CAM-302
Revision: 02
Date: October 16, 2014
Back
(Foam/Plywood)
Mechanism
(Steel
)
Cylinder
(Steel
)
Caster
(Plastic)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allseating CHIROFORM
Summary of Contents for Allseating CHIROFORM
- Page 1 These disassembly instructions are also applicable to PRESTO and TWIST. Back (Foam/Plywood) (Plastic/Steel Seat (Foam/Plywood) Mechanism (Steel Cylinder (Steel Base (Plastic) Caster (Plastic) For material recycling information please refer to the End of Life Recovery Matrix and List of Recycling Facilities, which is available at www.allseating.com.
- Page 2 Document: CAM-302 Disassembly Instructions Revision: 02 CHIROFORM Date: October 16, 2014 These disassembly instructions are also applicable to PRESTO and TWIST. Tools: #2 #3 Phillips head, Rubber mallat or hammer, Small flathead screwdriver, Box cutter. Skill Set: Good manual dexterity.
- Page 3 Document: CAM-302 Disassembly Instructions Revision: 02 CHIROFORM Date: October 16, 2014 6. Base - 1min Hold the base legs firmly and strike the bottom of cylinder with a hammer until base comes loose, remove base. 7. Cylinder - 1min Remove cylinder by placing one hand on can of cylinder and hit the bottom of the mechanism with hammer until cylinder separates from mechanism.
