(Plastic/Mesh)
Arm
(Plastic/Steel
)
Mechanism
(Steel
)
Caster
(Plastic)
For material recycling information please refer to the End of Life Recovery Matrix
and List of Recycling Facilities, which is available at www.allseating.com.
Disassembly Instructions
FLUID
Document: CAM-306
Revision: 01
Date: June 7, 2012
Seat
(Plastic/Mesh or
Foam/Plywood)
Cylinder
(Steel
)
Foot Rest
(Steel
)
Base
(Plastic or Aluminum)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allseating FLUID
Summary of Contents for Allseating FLUID
- Page 1 Seat (Plastic/Mesh or Foam/Plywood) Mechanism (Steel Cylinder (Steel Foot Rest (Steel Base Caster (Plastic or Aluminum) (Plastic) For material recycling information please refer to the End of Life Recovery Matrix and List of Recycling Facilities, which is available at www.allseating.com.
- Page 2 Document: CAM-306 Disassembly Instructions Revision: 01 FLUID Date: June 7, 2012 Tools: #2 #3 Phillips Head, Rubber Mallet or Hammer, Allen Key Skill Set: Good manual dexterity. Estimated Time: 16min per chair. Steps: 1. Armrest - 2min Turn the chair upside down, so the bottom is visible. Locate the four fasteners locate on the underside of the plastic seat frame and unfasten.
- Page 3 Document: CAM-306 Disassembly Instructions Revision: 01 FLUID Date: June 7, 2012 8. Foot Rest - 1min Remove footrest by placing one hand on cylinder and the other on footrest. Rotate the footrest in a direction to loose. Read the instruction on footrest for direction.
