Seat
(Foam/Plywood)
Cylinder
(Steel
)
Caster
(Plastic)
For material recycling information please refer to the End of Life Recovery Matrix
and List of Recycling Facilities, which is available at www.allseating.com.
Disassembly Instructions
THERAPOD
Document: CAM-313
Revision: 01
Date: June 7, 2012
Back
Foam/Plastic
Arm
(Plastic/Steel
Mechanism
(Steel
)
Base
(Plastic or Aluminum)
)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allseating THERAPOD
Summary of Contents for Allseating THERAPOD
- Page 1 Date: June 7, 2012 Back Foam/Plastic (Plastic/Steel Seat (Foam/Plywood) Mechanism (Steel Cylinder (Steel Base (Plastic or Aluminum) Caster (Plastic) For material recycling information please refer to the End of Life Recovery Matrix and List of Recycling Facilities, which is available at www.allseating.com.
- Page 2 Document: CAM-313 Disassembly Instructions Revision: 01 THERAPOD Date: June 7, 2012 Tools: #2 #3 Phillips Head, Rubber Mallet or Hammer, Allen Key, Box Cutter Skill Set: Good manual dexterity. Estimated Time: 15min per chair. Steps: 1. Armrest - 2min Turn the chair upside down, so the bottom is visible. Locate the four fasteners locate on the underside of the seat pan and unfasten.
- Page 3 Document: CAM-313 Disassembly Instructions Revision: 01 THERAPOD Date: June 7, 2012 7. Mechanism - 2min Turn the chair upside down so the bottom is visible. Locate the four fasteners located on the underside of the seat pan or seat slider and unfasten. Remove mechanism from the seat pan or seat slider.
