User Manual

(Â2éE2)

5202912102

Version 02

Table of Contents

Chapters

Need help?

Do you have a question about the EDST300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rohde & Schwarz EDST300

Page 1 ® R&S EDST300 TACAN/DME Station Tester User Manual (Â2éE2) 5202912102 Version 02...
Page 2 ® This manual applies to the following R&S EDST300 models with software version 4.20 and later: ● ® R&S EDST300 (5202.9009.02) In addition to the base unit, the following options are described: ● R&S®EDST-B2 Low-Power Interrogator (5202.9509.02) ● R&S®EDST-B3 Internal Battery (5202.7187.02) ●...
Page 3: Table Of Contents
Safety instructions......................7 Labels on the product....................9 Warning messages in the documentation..............10 Korea certification class A..................10 2 Documentation overview..............11 3 Welcome to the R&S EDST300............12 4 Getting started..................13 Preparing for use......................13 Instrument tour......................20 Operating basics......................29 5 Measurement basics................36 Evaluating DME signals....................36...
Page 4 How to set up the R&S EDST300 interrogator............106 10.5 How to analyze pulses graphically................107 10.6 How to set up the R&S EDST300 for TACAN measurements........108 10.7 How to save and load measurement settings............109 11 Remote commands for DME/Pulse analysis........111 11.1...
Page 5 ® Contents R&S EDST300 B DME channel frequency list.............. 168 C Format description of DME measurement data......184 List of commands................190 Index....................194 User Manual 5202.9121.02 ─ 02...
Page 6 ® Contents R&S EDST300 User Manual 5202.9121.02 ─ 02...
Page 7: Safety And Regulatory Information
Intended use The R&S EDST300 is an analyzer designed for installing, testing and servicing pulsed terrestrial navigation systems like DME and TACAN ground equipment. Use the prod- uct only for its designated purpose. Observe the operating conditions and performance limits stated in the data sheet.
Page 8 ® Safety and regulatory information R&S EDST300 Safety instructions aged or broken, stop using the product. Contact Rohde & Schwarz customer service at https://www.rohde-schwarz.com/support. Operating the product The product is intended for mobile use. The maximum weight of the product is provi- ded in the data sheet.
Page 9: Labels On The Product
® Safety and regulatory information R&S EDST300 Labels on the product ● Do not expose the battery to high temperatures such as open flames, hot surfaces and sunlight. ● Only use the battery with the designated Rohde & Schwarz product.
Page 10: Warning Messages In The Documentation
® Safety and regulatory information R&S EDST300 Korea certification class A Table 1-1: Labels regarding product and environment safety Labeling in line with EN 50419 for disposal of electrical and electronic equipment after the prod- uct has come to the end of its service life.
Page 11: Documentation Overview
Further documents are available at: www.rohde-schwarz.com/product/EDST300 Getting Started manual Introduces the R&S EDST300 and describes how to set up and start working with the product. Includes basic operations and general information, e.g. safety instructions, etc. A printed version is delivered with the instrument.
Page 12: Welcome To The R&S Edst300
® EDST-K2 option). The modular design of the R&S EDST300 provides a high degree of flexibility to adapt it to the task at hand. An interrogator (R&S EDST-B2 option) with adjustable output power (-80 dBm to +30 dBm peak power) is available for distance measurements. An internal battery (R&S EDST-B3 option) and a test antenna (R&S EDST-Z1 option)
Page 13: Getting Started
® Getting started R&S EDST300 Preparing for use 4 Getting started ● Preparing for use.....................13 ● Instrument tour......................20 ● Operating basics..................... 29 4.1 Preparing for use Here, you can find basic information about setting up the product for the first time.
Page 14 7 4.1.4.1 Placing the product on a bench top If you want to set up the R&S EDST300 on a benchtop or prepare the R&S EDST300 for mobile use, proceed as follows. To place the product on a bench top 1.
Page 15 2. Lift the R&S EDST300 to shelf height. 3. Grab the handle and push the R&S EDST300 onto the shelf until the rack brackets fit closely to the rack. 4. Tighten all screws in the rack brackets with a tightening torque of 1.2 Nm to secure the R&S EDST300 in the rack.
Page 16 1. Loosen the screws at the rack brackets. 2. Remove the R&S EDST300 from the rack. 3. If placing the R&S EDST300 on a bench top again, unmount the adapter kit from the R&S EDST300. Follow the instructions provided with the adapter kit.
Page 17 Chapter 4.2.1, "Front panel view", on page 20). If the interrogator option R&S EDST-B2 is installed on the R&S EDST300, the instru- ment can also provide HF output to a transmitter antenna via the "RF1 IN/OUT" con- nector (see also "Antenna connections RF1 IN/OUT and RF2 IN"...
Page 18 TACAN stick with the TACAN software is inserted in one of the USB ports. The TACAN stick must be inserted before the R&S EDST300 is switched on. Do not remove the stick before switching off the R&S EDST300, or else the application is closed.
Page 19 After the instrument has fully booted, the most recently used measurement mode is automatically started. Using the installed battery If the R&S EDST300 is powered using the internal battery and the batteries become empty, the instrument switches itself off. You cannot switch it back on until the DC power supply is connected.
Page 20: Instrument Tour
Disconnect the product from the power source. 4.2 Instrument tour 4.2.1 Front panel view This chapter describes the front panel of the R&S EDST300, including all function keys and connectors. Figure 4-1: Front panel view of the R&S EDST300 Power key...
Page 21 The arrow toggles between different sets of functions in the same menu, if more menu items are available than softkeys. 4.2.1.4 Front panel interfaces Various interfaces are provided on the front panel of the R&S EDST300. User Manual 5202.9121.02 ─ 02...
Page 22 N-socket, 50Ω RF output with interrogator options If the R&S EDST300 is equipped with the interrogator option R&S EDST-B2, the "RF1 IN/OUT" connector can provide HF output to a transmitter antenna. The antenna has an equivalent frequency range and (peak) power range (1 W).
Page 23 100. Voltage supply for external consumers: 12 VDC OUT The R&S EDST300 provides a power supply for connected external devices at the 3- pole circular "12 VDC OUT" connector. The output for external consumers such as an active receiving antenna is supplied permanently with 12 VDC / 300 mA.
Page 24 ® Getting started R&S EDST300 Instrument tour General function keys Function Creates a screenshot of the current display For future use 4.2.1.6 Measurement keys Measurement keys provide access to the most common measurement settings and functions. A detailed description of the corresponding functions is provided in Chapter 7, "Config-...
Page 25 In dialog boxes that contain a "Cancel" button that it activates that button. 4.2.2 Rear panel view This figure shows the rear panel view of the R&S EDST300. The individual elements are described in more detail in the subsequent sections.
Page 26 16. 4.2.2.2 SUPPRESS IN / OUT connector The R&S EDST300 allows for a suppressor line signal to be input or output via the BNC "SUPPRESS IN / OUT" connector (see Chapter 4.1.8.2, "Connecting a suppres- line", on page 18).
Page 27 Use the female BNC "TRIGGER INPUT" connector to input an external trigger. An external trigger, for example from the DME transmission system, can control the mea- surement on the R&S EDST300. The (digital) voltage levels can range from 3.3 V to 33 V. The input impedance is 100 kΩ.
Page 28 REF 10 MHz IN/OUT The "REF 10 MHz IN/OUT" connector can provide an external reference signal to the R&S EDST300, or from the R&S EDST300 to a connected device. In either case, the . The connector is a 50 Ω...
Page 29: Operating Basics
The instrument name is required to establish a connection to the instrument in a LAN. 4.3 Operating basics This chapter provides an overview on how to work with the R&S EDST300. It describes what kind of information is displayed on the screen and how to operate the R&S EDST300 via the front panel keys and other interaction methods.
Page 30 Getting started R&S EDST300 Operating basics Figure 4-3: Typical R&S EDST300 screen display (using DME mode as an example) 1 = Softkeys to edit settings and activate functions 2 = Status bar 3 = Measurement result area 4 = Measurement settings area...
Page 31 Error and status messages). 4.3.2 Accessing the functionality All functions available on the R&S EDST300 can be accessed using the keys on the front panel of the instrument. Some keys provide a softkey menu on the display with further functions and settings.
Page 32 ® Getting started R&S EDST300 Operating basics To change a setting or activate a function 1. Select a key on the front panel of the instrument to activate a function directly, or to display a softkey menu. Select the softkey for the setting or function as required.
Page 33 If a field requires alphanumeric input, you can use the keypad on the front panel of the R&S EDST300. Every alphanumeric key represents several characters and one num- ber. The decimal point key (.) represents special characters, and the sign key (-) tog- gles between capital and small letters.
Page 34 In this case, check the error log for missed errors. The [UNCAL] display is only removed when the R&S EDST300 is switched off. All error and status messages displayed on the R&S EDST300 are also stored to an error log on the instrument for later inspection. (See Chapter 9.3.1, "Error...
Page 35 EDST300 Operating basics Message Description Can't mount The USB storage device connected to the R&S EDST300 could not be read cor- USB-Stick rectly. Mount USB-Stick: The USB storage device connected to the R&S EDST300 is ready to store data. USB LOGGING ON Data logging to a USB storage device is active.
Page 36: Measurement Basics
If the reply efficiency rises above the specified threshold, the R&S EDST300 immediately returns to the "track" mode. But after a specified time (by default: 10 s) the track is considered to be lost and the R&S EDST300 returns to the "search" mode to start over.
Page 37: Reply Efficiency
R&S EDST300 RF attenuator value is decreased, the R&S EDST300 moves to the "track" mode more quickly, but also returns to the "memory" mode more quickly. 5.2 Reply efficiency The reply efficiency of a DME system is the ratio of the number of received reply pul- ses to the number of transmitted interrogation pulses.
Page 38 ® Measurement basics R&S EDST300 RF attenuator Figure 5-1: Signal paths for different attenuation modes Select the attenuator mode such that the input level always remains within the speci- fied range. For details, see "Antenna connections RF1 IN/OUT and RF2 IN"...
Page 39: Measurements And Results
If the appropriate hardware option (Low-Power Interrogator, R&S EDST300-B2) is installed, the R&S EDST300 can act as a DME interrogator. It sends out pulses to the ground station which returns the signals to the R&S EDST300 at a different frequency with a delay (see Chapter 5.1, "Evaluating DME...
Page 40 DME and TACAN measurement mode Receiver modes The R&S EDST300 can measure either the pulses sent by the interrogator to the ground station, or the reply pulses sent from the ground station to the interrogator. You specify which signals you want to measure and analyze in the measurement settings.
Page 41 Interrogator pulse code (distance of the double pulses), according to the ICAO frequency list. 6.1.2 DME measurement results Access: [DME] Distance measurements are performed in a specific mode on the R&S EDST300, the "DME" mode. The following results are displayed for a distance measurement. Graphical results are described in Chapter 7.3, "Performing pulse...
Page 42 DME and TACAN measurement mode For reference measurements requiring very high accuracy, you can connect a power sensor from the R&S NRP family to the R&S EDST300 USB port. Results delivered by the power sensor are displayed on the R&S EDST300 without further configuration.
Page 43 Interval in which trigger events are detected in external trigger input (reciprocal of "TRIG IN COUNT [1/s]" on page 43). Remote command: on page 131 <RX>:DME:TRIG_IN_PERIOD? BEARING [°] TACAN signals only (requires option R&S EDST300-K1): Direction of the ground station in relation to the R&S EDST300. User Manual 5202.9121.02 ─ 02...
Page 44 ® Measurements and results R&S EDST300 DME and TACAN measurement mode Remote command: on page 157 <RX>:TACAN:BEARING? DELAY [µs] Reply delay time, that is: the delay time between the interrogator and reply pulse, including the ground station delay (50 µs for X channels / 56 µs for Y channels).
Page 45 ● The absolute phase of the 135 Hz signal to the auxiliary reference burst (ARB) The R&S EDST300 can evaluate TACAN signals only if the TACAN stick with the TACAN software is inserted in one of the USB ports (see Chapter 4.1.9, "Activating the...
Page 46 ® Measurements and results R&S EDST300 DME and TACAN measurement mode Figure 6-2: TACAN measurement results (page 2) MOD.DEPTH 15Hz [%]....................46 MOD.DEPTH 135Hz [%]....................46 BEARING [°]........................47 PHASE SHIFT [°]......................47 FREQ 15Hz [Hz]......................47 FREQ 135Hz [Hz]......................47 PHASE 15Hz [°]......................
Page 47 DME and TACAN measurement mode Remote command: on page 158 <RX>:TACAN:MOD_DEPTH_135HZ? BEARING [°] Direction of the ground station in relation to the R&S EDST300. Remote command: on page 157 <RX>:TACAN:BEARING? PHASE SHIFT [°] Measured phase shift between the 15 Hz and 135 Hz components...
Page 48 ® Measurements and results R&S EDST300 DME and TACAN measurement mode MRB PULSE COUNT Number of pulses measured in one MRB. "DBL" indicates that double bursts are counted (X channels), "SGL" indicates that sin- gle pulses are counted (Y channels).
Page 49 ® Measurements and results R&S EDST300 DME and TACAN measurement mode Figure 6-3: ID Analysis view Last ID [s]........................49 ID Period [s]........................49 EQ Pulse time [μ]......................49 ID PRR [1/s]........................49 ID Sequence Length..................... 50 ID-CODE........................50 Dash Length [ms]......................
Page 50: Graphical Pulse Analysis
6.2 Graphical pulse analysis Access: [PULSE] R&S EDST300 pulse analysis is used to test the RF output signal of DME / TACAN ground stations and interrogators and analyze pulse characteristics graphically. In "Pulse" mode, the power levels at a specific interrogator or transponder channel fre- quency are measured.
Page 51 ® Measurements and results R&S EDST300 Graphical pulse analysis Figure 6-4: Default Pulse analysis view (All parameters) 1 = Selected receiver channel and frequency for measurement 2 = Marker and analysis results 3 = Power vs time diagram for measured channel You can change the channel and frequency to be measured directly in the Pulse view, "Changing the receiver (RX) channel number"...
Page 52 ® Measurements and results R&S EDST300 Graphical pulse analysis full analysis. In this case, only the parameter results are displayed in the "Pulse" view (see Figure 6-4). For individual parameter analysis, the markers are displayed graphically in the dia- gram. The position and values of the markers are indicated numerically in the pulse results area.
Page 53 ® Measurements and results R&S EDST300 Graphical pulse analysis Remote command: on page 161 <RX>:PULSEVIEW:ANALYSIS? Pulse duration Pulse duration for each pulse in µs, calculated as the difference between two markers (M2-M1). Marker 1 is set at 50 % of the rising pulse slope, marker 2 is set at 50 % of the falling pulse slope.
Page 54 ® Measurements and results R&S EDST300 Graphical pulse analysis Figure 6-7: Pulse decay time results in Pulse view Remote command: on page 161 <RX>:PULSEVIEW:ANALYSIS? Pulse spacing Pulse spacing between the pulses of a pulse pair in µs, calculated as the difference between two markers (M2-M1).
Page 55 ® Measurements and results R&S EDST300 Graphical pulse analysis Figure 6-8: Pulse spacing results in Pulse view Remote command: on page 161 <RX>:PULSEVIEW:ANALYSIS? Peak variation Variation in pulse peak power values between two pulses, in dB. Remote command: on page 161 <RX>:PULSEVIEW:ANALYSIS?
Page 56 ® Measurements and results R&S EDST300 Graphical pulse analysis Mrk. max to peak 1 The difference between two markers (M2-M1). Marker 1 is set to the peak power level of the first pulse, marker 2 is set to the peak power level of the second pulse.
Page 57: Configuring And Performing Measurements
7.1 Configuring signal input and output Access: [SETUP] The R&S EDST300 can analyze signals received by its RF IN interface, but also pro- vide output to the same interface. Furthermore, a reference signal can be provided as input to the R&S EDST300 to improve accuracy of the measurements. All settings con- cerning signal input and output are described here.
Page 58 "RF 1 IN" RF input from the "RF 1 IN/OUT" connector on the front panel of the R&S EDST300 "RF 2 IN" RF input from the "RF 2 IN" connector on the front panel of the R&S EDST300...
Page 59 In some setups, you insert an attenuation element between the "RF1 IN/OUT" connec- tor on the R&S EDST300 and the device under test to protect the equipment. In other setups, you want to determine the attenuation due to the used cables.
Page 60 "RF1 IN/OUT" connector. The R&S EDST300 inserts the value for the "RF1 ext. attenuation" setting. 7.1.3 Configuring signal output Access: [SETUP] > "Signal Out" Different signals can be provided at one of the R&S EDST300's output connectors. Trigger Out Mode......................60 Analog Out........................
Page 61 Only available for TACAN analysis "ARB_TRIGGER" For each decoded ARB (auxiliary reference burst), a square pulse with a 1 μs pulse width is output. Only available for TACAN analysis (requires option R&S EDST300- K1). Remote command: on page 125 SETUP:TRIGGER_OUT_MODE...
Page 62 Defines whether the [REF 10 MHz IN/OUT] connector on the rear panel of the R&S EDST300 is used to receive a reference frequency from an external device, or to provide the internal reference frequency of the R&S EDST300 as output to a connec- ted device.
Page 63 7.1.5 Configuring DME interrogator signals Access: [SETUP] > "DME Interrog" The R&S EDST300 can act as a DME interrogator, sending out pulses to the ground station which returns the signals to the R&S EDST300 at a different frequency with a delay (see Chapter 5.1, "Evaluating DME...
Page 64 ® Configuring and performing measurements R&S EDST300 Configuring signal input and output Type of Prediction......................64 Track Pulses........................64 Search Pulses....................... 65 Memory Time (Tracking)....................65 Min. Reply Effic. (Tracking)................... 65 Delay Offset........................65 TX Pulse Shape......................65 ICAO Override.......................66 Type of Prediction Defines the type of algorithm used to calculate the expected reply pulse.
Page 65 ® Configuring and performing measurements R&S EDST300 Configuring signal input and output Remote command: on page 136 <RX>:DST:TPULSES Search Pulses Number of pulses during search mode for which the reply efficiency is calculated. The larger the value, the more stable and accurate the results, but the slower the inter- rogator.
Page 66 SETEXPERT 7.1.6 Receiving GPS signals Access: [GPS] A GPS input signal allows the R&S EDST300 to synchronize its time and positioning information with an accurate reference. Therefore, the R&S EDST300 provides an RS232 interface on its rear panel (see also Chapter 4.2.2.10, "RS232 GPS...
Page 67 GPRMC The GPRMC (Global Positioning Recommended Minimum Specific = minimum information) dataset received by the R&S EDST300 is displayed as an ASCII character set with 4800 Bd. GPGGA GPGGA (Global Positioning System Fix Dat) dataset containing the most important informa- tion of the GPS position and accuracy.
Page 68: Configuring Dme Measurements
® Configuring and performing measurements R&S EDST300 Configuring DME measurements Baud Rate Indicates and defines the currently used baud rate (or signalling rate) for the GPS sig- nal. Values from 4800 Bd to 115200 Bd are available. Remote command: on page 120...
Page 69 RX frequency, but also by the corresponding VHF fre- quency. If you enter a valid VHF frequency in the "RX freq" field, the R&S EDST300 recognizes it. The entered frequency is then displayed as the "VHF Frequency (VHFF)"...
Page 70 "VHFF", and the RX freq is set to the corre- sponding RX frequency. This function is only available with the TACAN option (R&S EDST300-K1). Interrogator Transmission (TX) frequency The frequency at which the interrogator pulses are transmitted, if enabled (see "Trans- mitter (TX) State"...
Page 71 PRR for Track Mode. An active transmitter is indicated by a yellow "TX ON" message in the status bar of the R&S EDST300 screen. NOTICE! Risk of damage to the instrument or injury due to false transmission settings. Only change transmission settings while the transmitter is deactivated. Falsely entered settings can lead to unexpected output levels that can cause damage or injury.
Page 72 127 <RX>:DME:ATTMODE Receiver (RX) Mode Defines the signal to be received and analyzed by the R&S EDST300, depending on the measurement task. The currently selected mode is indicated on the softkey. (Default) The signal transmitted by the DME ground station is mea- "Reply"...
Page 73: Performing Pulse Analysis
<RX>:DME:DEMOD_BW 7.3 Performing pulse analysis R&S EDST300 pulse analysis is used to test the RF output signal of DME / TACAN ground stations and interrogators and analyze pulse characteristics graphically. In Pulse mode, the power levels at a specific interrogator or transponder channel fre- quency are measured.
Page 74 ® Configuring and performing measurements R&S EDST300 Performing pulse analysis You can change the channel and frequency to be measured directly in the Pulse view, "Changing the receiver (RX) channel number" on page 69 and "Changing the receiver (RX) frequency"...
Page 75 ® Configuring and performing measurements R&S EDST300 Performing pulse analysis X-axis Scaling (Time/Div) Time per division; defines the scaling of the x-axis, which consists of 10 divisions. The valid value range is from 0.5 μs to 50 μs. Note that the hardware supports a minimum of 2 μs/div. Lower values do not reduce the time between two captured points, but represent a zoomed display.
Page 76 "Maxhold" The maximum value is determined over all previously measured pul- ses (pairs) and displayed. The R&S EDST300 saves each trace point in the trace memory only if the new value is greater than the previous one.
Page 77 RX frequency, but also by the corresponding VHF fre- quency. If you enter a valid VHF frequency in the "RX freq" field, the R&S EDST300 recognizes it. The entered frequency is then displayed as the "VHF Frequency (VHFF)"...
Page 78 ® Configuring and performing measurements R&S EDST300 Performing pulse analysis If the frequency is inside the valid range, but not assigned to a channel according to the ICAO frequency list, and it is not a VHF frequency, the associated parameters are indicated in yellow.
Page 79 Defines the signal which triggers the measurement. "Level" The measured input signal "External" An external trigger signal provided by a device connected to the [trigger in] connector on the rear panel of the R&S EDST300; The defined trigger level is irrelevant. "Interrog"...
Page 80 Access: [Marker] In the graphical pulse analysis display, up to three markers can be enabled to indicate special points of interest in the diagram. The R&S EDST300 can then use these spe- cific marker values to analyze characteristic pulse parameters.
Page 81 ® Configuring and performing measurements R&S EDST300 Performing pulse analysis Peak marker (Mrk. Max) Allows you to place the peak marker to any position in the measured signal manually. Enter the time which defines the x-axis value of the marker, or move the marker using the rotary knob.
Page 82: Data Management
Possibly you would like to restore or repeat a measurement you performed under spe- cific conditions on the R&S EDST300. Or you would like to troubleshoot a measure- ment and require a defined instrument state to detect the precise cause of the error. In these cases, you can store and recall instrument and measurement settings.
Page 83 Rename.........................84 Factory Preset When delivered, the R&S EDST300 has a default configuration. You can restore this defined initial state at any time as a known starting point for measurements. Presetting is often recommendable as a first step in troubleshooting when unusual measurement results arise.
Page 84: Logging Measurement Data
[START] If a USB storage device is connected to the R&S EDST300, a data file is created on the USB device. All measurement results from the running measurement are stored in the file. The message USB LOGGING ON is displayed in the status bar.
Page 85: Creating And Storing Screenshots
8.3 Creating and storing screenshots Access: [Setup] > "More Softkeys" > "Memory & Screenshots" You can create a screenshot of the current display on the R&S EDST300 at any time during operation. Screenshots are useful to document measurement results, for exam- ple.
Page 86: Color Vs. Black And White Screenshot
For color output: Press the [ENTER] key. Exporting screenshots to a USB device All screenshots on the R&S EDST300 are stored as .PNG files in the main directory of the connected USB device. Note: If a USB device is connected to the R&S EDST300 while the screenshot is taken, the screenshot is immediately stored to the USB device as a .PNG file.
Page 87: Obtaining Information On Open-Source Resources
Deleting all screenshots stored on the R&S EDST300 All screenshots stored on the R&S EDST300 are deleted irrevocably. Once the screenshots have been stored to an external memory device, you can delete them from the instrument. Otherwise, you copy them again each time you create new screenshots and want to store them to a USB device.
Page 88: General Instrument Setup
® General instrument setup R&S EDST300 General settings 9 General instrument setup Access: [SETUP] Some basic instrument settings can be configured independently of the selected mea- surement mode. Usually, you configure most of these settings initially when you set up the instrument according to your personal preferences or requirements.
Page 89: Setting Up A Network (Lan) Connection
119 SETUP:COUNT_PULSES 9.2 Setting up a network (LAN) connection The R&S EDST300 is equipped with a network interface and can be connected to an Ethernet LAN (local area network). The interface can be used, for example: ● To transfer data between a controlling device and the test device, e.g. to run a remote control program.
Page 90 How to configure the network (LAN) connection.............92 ● How to set up a remote connection.................92 9.2.1 Network settings Access: [Setup] > "Network" To operate the R&S EDST300 in a network, the following settings must be configured. User Manual 5202.9121.02 ─ 02...
Page 91 ® General instrument setup R&S EDST300 Setting up a network (LAN) connection TCP/IP DHCP....................... 91 TCP/IP Address......................91 TCP/IP Netmask......................91 TCP/IP Gateway......................92 Hostname........................92 TCP/IP DHCP If the network supports dynamic TCP/IP configuration using the Dynamic Host Configu- ration Protocol (DHCP), all address information can be assigned automatically. In this case, the TCP/IP parameters are not editable.
Page 92 See also "IP address vs host name" on page 90. 9.2.2 How to configure the network (LAN) connection To use the R&S EDST300 in a network, connect the instrument to the network by its LAN connector (see Chapter 4.2.2.8, "LAN interface", on page 28).
Page 93: Obtaining System Information
Access: [Setup] > "Error Log" The last 100 instrument status messages or errors displayed in the status bar during operation of the R&S EDST300 are also stored in an error log file on the instrument (see also Chapter 4.3.4, "Error and status messages",...
Page 94 If you detect that the latest software version is not yet installed, simply insert a USB storage device with the latest version in the R&S EDST300 and press the [ENTER] key. If a software installation file is found on the USB device, a software update is auto- matically started (after confirmation).
Page 95 Access: [Setup] > "More Softkeys" > "Hardware Status 1" The hardware status overview provides information on the current operating status of the individual hardware components in the R&S EDST300, such as test voltages and temperatures. User Manual 5202.9121.02 ─ 02...
Page 96 The "Overall Status" in the hardware status overview is indicated as "NOK" (not OK). As soon as the test voltage returns to the allowed range, the "Overall Status" returns to "OK". The "UNCAL" display, however, remains until the R&S EDST300 is switched off. Test voltages are color-coded: Table 9-1: Test voltage color-coding...
Page 97 ® General instrument setup R&S EDST300 Obtaining system information Figure 9-2: Hardware status for the mainboard, the power supply and the antenna distributing unit (DU board) - page 1 The second overview ("Hardware Status 2") provides information on the integrated receiver modules.
Page 98: Updating The Software
9.4 Updating the software Access: [Setup] > "More Softkeys" > "Inventory" Software updates and the Release Notes describing the improvements and modifica- tions for the R&S EDST300 are provided on the Internet at: http://www.rohde-schwarz.com/firmware/edst300 To update the software version 1. Store the software version to a USB storage device.
Page 99: Activating Additional Options
To activate the license key 1. Press the [Setup] key. Press the "More softkeys" key. 3. Press the "Options" softkey to display an overview of all available R&S EDST300 options. 4. Press the [Enter] button to open an input edit field for "Key".
Page 100: Configuring The Display And Audio Output
If the key is valid, the purchased options are enabled and identified as "available" in the overview. Figure 9-4: Available R&S EDST300 options If the key is not valid, the entered number is displayed in red. Figure 9-5: Invalid option key Correct the number and try again.
Page 101 Remote command: on page 118 SETUP:AF_VOLUME Speaker Enables or disables AF output at the loudspeaker on the rear panel of the R&S EDST300. Remote command: on page 121 SETUP:ANALOG_OUT_MODE Display Update Rate Defines the rate at which the display is updated to show new measurement results.
Page 102 [VOL] The [VOL] key on the front panel of the R&S EDST300 changes the volume setting for the AF output quickly during regular operation. When you press the key, the volume setting is temporarily displayed as a bar graph in the status bar of the display. Turn the rotary knob to change the volume and confirm the setting by pressing the [ENTER] key or the rotary knob.
Page 103 To change the volume setting for the loudspeaker quickly during regular operation of the R&S EDST300, press the [VOL] key on the front panel. The volume setting is tem- porarily displayed as a bar graph in the status bar of the display. Turn the rotary knob to change the volume and confirm the setting by pressing the [ENTER] key or the rotary knob.
Page 104: How To Perform Measurements And Analyze Pulses With The R&S Edst300
How to save and load measurement settings............109 10.1 How to configure signal input and output The R&S EDST300 can analyze signals received by its "RF IN" interface. It can also provide output to other interfaces. To configure the input signal for analysis 1.
Page 105: How To Perform A Distance Measurement
5. Connect a device to the [REF 10 MHz IN/OUT] connector on the rear panel of the R&S EDST300. The R&S EDST300 provides its internal 10 MHz reference signal as output at the [REF 10 MHz IN/OUT] connector. 10.2 How to perform a distance measurement The following step-by-step instructions demonstrate how to perform a basic distance measurement with the R&S EDST300.
Page 106: How To Analyze Interrogator Pulses
106. 10.4 How to set up the R&S EDST300 interrogator The following step-by-step instructions demonstrate how to set up the R&S EDST300 to send interrogator pulses and evaluate them. 1. Select [Setup]. 2. Select "More softkeys", then "DME Interrog.".
Page 107: How To Analyze Pulses Graphically
10. If necessary, select "TX P. Width" or "TX Level" (in the second softkey menu) to change the interrogator pulse width or the pulse power level, respectively. The R&S EDST300 now acts and behaves like the on-board interrogator of a nor- mal plane, sending interrogator pulses at the defined pulse rate.
Page 108: How To Set Up The R&S Edst300 For Tacan Measurements
The power level for the marker is displayed above the diagram ("Mark1"). 10.6 How to set up the R&S EDST300 for TACAN measure- ments The following step-by-step instructions demonstrate how to set up the R&S EDST300 to measure and analyze pulses from TACAN signals. 1. Switch off the R&S EDST300.
Page 109: How To Save And Load Measurement Settings
Default factory settings can also be restored to the instrument at any time. To restore factory default settings 1. Press the [Preset] key on the front panel of the R&S EDST300. 2. Select the "Factory Preset" softkey. 3. Confirm the message.
Page 110 User Presets. The name assigned to a User Preset can be changed anytime. 1. Press the [Preset] key on the front panel of the R&S EDST300. 2. Select the "Select" softkey. The number of the currently selected User Preset is indicated on the softkey. By default, the User Preset number 1 is selected.
Page 111: Remote Commands For Dme/Pulse Analysis
<RX> prefix If an optional second receiver board is available, the <RX> prefix defines which receiver board the command is addressed to (RX1, RX2). For the R&S EDST300, no second receiver board is available, so the prefix is irrel- evant. ●...
Page 112: Configuring Remote Operation
EDST300 Configuring remote operation 11.1 Configuring remote operation The R&S EDST300 can be operated in the following modes: ● Local mode: manual operation using the graphical user interface directly at the instrument is available; remote commands can also be executed ●...
Page 113 Usage: Setting only Manual operation: "Creating a screenshot" on page 85 LOCAL Switches back to local operation of the R&S EDST300. The graphical user interface of the R&S EDST300 becomes available again. Return values: <SettingResult> READY Setting was successfully applied.
Page 114: Obtaining Instrument Information
<State> ON | OFF Remote lock is set; no local operation by keyboard is possible. The "LOCAL" button on the R&S EDST300 has no effect. To enable local operation again, release the remote lock (using REMOTELOCK OFF. Releases the remote lock; local operation is enabled again.
Page 115 This command clears the error log. Return values: <State> READY. The command was executed successfully. GETERRORLOG This command retrieves error log entries. Return values: <Error-Log> GETHWINVENTORY Queries the hardware modules installed in the R&S EDST300. Return values: <HWModules> string Example: GETHWINVENTORY //Result: //EDS300K:5202.7006K02,999999,01.00 //EDST300:5202.7006.02,101325,02.00 //MAINBOARD:5202.7035.02,999999,06.00 //EDS_DU:5202.7058.02,101343,05.00...
Page 116 ® Remote commands for DME/Pulse analysis R&S EDST300 Obtaining instrument information GETHWSTATUS Queries the status of the hardware modules inside the R&S EDST300. Return values: <HWStatus> OK | NOK An error has occurred for at least one hardware element. Example:...
Page 117 ® Remote commands for DME/Pulse analysis R&S EDST300 Obtaining instrument information Return values: <Version> string Usage: Query only MAIN_BOARD_CPLD_VER? Queries the main board CPLD-Software version Return values: <Version> string Usage: Query only MAIN_BOARD_FPGA_VER? Queries the main board FPGA-Software version Return values: <Version>...
Page 118: General Instrument Setup
® Remote commands for DME/Pulse analysis R&S EDST300 General instrument setup 11.3 General instrument setup ..........................118 *RST .......................118 FACTORY_PRESET ....................118 SETUP:AF_VOLUME? ..................... 118 SETUP:AF_VOLUME ..................... 119 SETUP:COUNT_PULSES? ....................119 SETUP:COUNT_PULSES ..................119 SETUP:DISPLAY_UPDATE_MS? ..................119 SETUP:DISPLAY_UPDATE_MS ....................119 SETUP:MORSEMOST ......................119 SETUP:SPEAKER? ......................119...
Page 119 Remote commands for DME/Pulse analysis R&S EDST300 General instrument setup SETUP:COUNT_PULSES? SETUP:COUNT_PULSES <PulseType> Determines whether the R&S EDST300 counts single or double pulses (pulse pairs) in the measured signal. Parameters: <PulseType> DOUBLE Only double pulses are counted, that is: two identical pulses sent with the required pulse spacing.
Page 120: Configuring Signal Input And Output
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring signal input and output Parameters: SwitchSpek ON | OFF Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful. 11.4 Configuring signal input and output ......................
Page 121: Getgpssync
"Sync" on page 68 SETUP:ANALOG_OUT_MODE? SETUP:ANALOG_OUT_MODE <Output> Queries or defines the type of analog signal to be provided at the [ANALOG OUTPUT] connector on the rear panel of the R&S EDST300. Parameters: <Output> RX_DEMOD The demodulated baseband signal is output.
Page 122: Setup:ext_Attenuation_Type
R&S EDST300 INPUT_RF2 RF input from the "RF 2 IN" connector on the front panel of the R&S EDST300 INPUT_BBAND Analog input from the [ANALOG IN] connector on the rear panel of the R&S EDST300 *RST: INPUT_RF1 Return values: <SettingResult> READY Setting was successfully applied.
Page 123: Setup:reference:extreference
R&S EDST300. The internal 10 MHz reference signal is used for measurement with the R&S EDST300. Output The internal 10 MHz reference signal of the R&S EDST300 is provided as output to a device at the [REF 10 MHz IN/OUT] con- nector (for SETUP:REFERENCE:SOURCE INTERN).
Page 124: Setup:sync1_Out
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring signal input and output ERROR An error occurred; setting was not successful. Manual operation: "Source" on page 62 SETUP:SYNC1_OUT? SETUP:SYNC1_OUT <InputSource> Queries or defines the type of synchronization signal output at the "SYNC1 OUT" con- nector on the rear panel.
Page 125: Configuring Measurements
Configuring measurements SETUP:TRIGGER_OUT_MODE? SETUP:TRIGGER_OUT_MODE <OutputTrig> Queries or defines the type of trigger signal to be provided at the [TRIGGER OUTPUT] connector on the rear panel of the R&S EDST300. Parameters: <OutputTrig> PULSE_TRIGGER For each measured DME pulse, a square pulse with the same pulse width is output synchronously.
Page 126 ® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements 11.5.1 Configuring the measurement mode ...................... 126 <RX>:MEASMODE? ....................126 <RX>:MEASMODE_DME ....................126 <RX>:MEASMODE_PULSE <RX>:MEASMODE? Queries the current measuring mode Return values: <Mode> MODE_DMETAC DME/TACAN measurement mode, see Chapter 6.1, "DME and TACAN measurement mode",...
Page 127: Rx>:Dme:attmode
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements 11.5.2 DME measurements ....................127 <RX>:DME:ATTMODE? ....................127 <RX>:DME:ATTMODE ......................128 <RX>:DME:FREQ? ......................128 <RX>:DME:FREQ ....................128 <RX>:DME:MEASTIME? ....................128 <RX>:DME:MEASTIME ....................129 <RX>:DME:DEMOD_BW? ....................129 <RX>:DME:DEMOD_BW ......................129 <RX>:DME:RFCH? ......................129 <RX>:DME:RFCH...
Page 128: Rx>:Dme:freq
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements *RST: AUTO Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful. Example: RX1:DME:ATTMODE LOW_DIST Manual operation: "Att.Mode" on page 71 "Att.Mode" on page 76 <RX>:DME:FREQ?
Page 129: Rx>:Dme:demod_Bw
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements ERROR An error occurred; setting was not successful. Manual operation: "Measurement Time" on page 71 <RX>:DME:DEMOD_BW? <RX>:DME:DEMOD_BW <Bandwidth> Queries or defines the bandwidth of the digital filter used for DME measurement.
Page 130: Rx>:Dme:rf_Bw
Manual operation: "RF bandwidth (RF BW)" on page 73 <RX>:DME:RXMODE? <RX>:DME:RXMODE <SignalType> Queries or defines the signal to be received and analyzed by the R&S EDST300, depending on the measurement task. Parameters: <SignalType> REPLY The signal transmitted by the DME ground station is measured.
Page 131: Rx>:Dme:trig_In_Count
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements <RX>:DME:TRIG_IN_COUNT? <TrigCount> Number of measured trigger events on external trigger input. Only single pulses are counted. Parameters: <TrigCount> numeric value Number of pulses per capture time (1/s) If no trigger is counted: 0...
Page 132: Rx>:Dst:txpulse_Width
Usage: Setting only Manual operation: "TX Pulse Code (P.Code)" on page 70 <RX>:DST:TXPULSE_WIDTH? <RX>:DST:TXPULSE_WIDTH <PWidth> Defines or queries the width of the pulses the R&S EDST300 interrogator transmits to the ground station. Parameters: <PWidth> numeric value Width in μs Range: 0.8 to 4.5...
Page 133 ® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements ......................136 <RX>:DST:TXON? ......................136 <RX>:DST:TXON ....................137 <RX>:DST:TXPOWER ......................137 SET_ICAO_OVR ......................... 137 SETEXPERT <RX>:DST:DELAY_OFFSET? <RX>:DST:DELAY_OFFSET <Offset> Defines an offset to the delay between the transmission of the request pulse and the reply pulse.
Page 134 ® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements Parameters: <Value> numeric value Reply efficiency in percent Range: 20 to 99 Return values: <State> READY. The command was executed successfully. Manual operation: "Min. Reply Effic. (Tracking)" on page 65 <RX>:DST:PRED_TYPE <Algorithm>...
Page 135 G auss pulse with a rise and fall time of 2.5 μs Asymmetric Gauss pulse with a rise time of 2.0 μs and a fall time of 2.7 μs Only available for TACAN measurements, requires option R&S EDST300-K1. Manual operation: "TX Pulse Shape" on page 65 <RX>:DST:SETTXLEVEL <Power>...
Page 136 "Track Pulses" on page 64 <RX>:DST:TXON? <RX>:DST:TXON <State> Queries or defines the state of the interrogator. If activated, the R&S EDST300 trans- mits interrogator pulses to the ground station with the specified pulse repetition rate (see PRR for Search Mode/ PRR for Track Mode.
Page 137 An error occurred; setting was not successful. Manual operation: "Transmitter (TX) State" on page 71 <RX>:DST:TXPOWER <Power> Defines the level at which the R&S EDST300 interrogator transmits pulses to the ground station. Parameters: <Power> Power in W or dBm Range: -80 dBm to +30 dBm (max.
Page 138 ® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements 11.5.4 Pulse analysis The following commands are only available in Pulse mode, see <RX>: on page 126. MEASMODE_PULSE .....................139 <RX>:PULSEVIEW:AVRG? ....................139 <RX>:PULSEVIEW:AVRG ....................139 <RX>:PULSEVIEW:BW? ....................139 <RX>:PULSEVIEW:BW ..................140 <RX>:PULSEVIEW:TIMEDIV?
Page 139: Rx>:Pulseview:avrg
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements ..............148 <RX>:PULSEVIEW:YSCALE_MAXLEV_UW ..............149 <RX>:PULSEVIEW:YSCALE_MAXLEV_NW? ..............149 <RX>:PULSEVIEW:YSCALE_MAXLEV_NW ..............149 <RX>:PULSEVIEW:YSCALE_MAXLEV_PW? ..............149 <RX>:PULSEVIEW:YSCALE_MAXLEV_PW ..............149 <RX>:PULSEVIEW:YSCALE_MAXLEV_V? ................149 <RX>:PULSEVIEW:YSCALE_MAXLEV_V ..............150 <RX>:PULSEVIEW:YSCALE_MAXLEV_MV? ..............150 <RX>:PULSEVIEW:YSCALE_MAXLEV_MV ..............150 <RX>:PULSEVIEW:YSCALE_MAXLEV_UV? ..............150 <RX>:PULSEVIEW:YSCALE_MAXLEV_UV <RX>:PULSEVIEW:AVRG? <RX>:PULSEVIEW:AVRG <NoPulses>...
Page 140: Rx>:Pulseview:timediv
MAXHOLD The maximum value is determined over all previously measured pulses (pairs) and displayed. The R&S EDST300 saves each trace point in the trace memory only if the new value is greater than the previous one.
Page 141: Rx>:Pulseview:trigdelay
Manual operation: "Trigger Delay" on page 79 <RX>:PULSEVIEW:TRIGDOUBLE? <RX>:PULSEVIEW:TRIGDOUBLE <State> Queries or defines the behavior of the R&S EDST300 after a single trigger. Parameters: <State> ON | OFF Triggering only occurs when a double pulse, that is: a pulse pair is detected.
Page 142: Rx>:Pulseview:triglevrf_Mv
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements <RX>:PULSEVIEW:TRIGLEVRF_MV? <RX>:PULSEVIEW:TRIGLEVRF_MV <Level> Queries or defines the RF trigger level. The valid value range depends on the selected y-axis unit for the power axis (see<RX>:PULSEVIEW:UNIT on page 144). ● V: 0 µV to 2 V ●...
Page 143: Rx>:Pulseview:trigslope
LEVEL The measured input signal EXTERN An external trigger signal provided by a device connected to the [trigger in] connector on the rear panel of the R&S EDST300 INTERROG The pulses sent by the R&S EDST300 interrogator TAC_MRB The TACAN main reference burst (if available)
Page 144: Rx>:Pulseview:unit
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements DME_PULSE A detected DME double pulse Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful. Manual operation: "Trigger Source" on page 79 <RX>:PULSEVIEW:UNIT? <RX>:PULSEVIEW:UNIT <Unit>...
Page 145: Rx>:Pulseview:yscale_Mv_Div
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements Parameters: <Scaling> 1 | 2 | 3 | 5 | 10 Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful. Manual operation: "Y-axis Scaling (<Unit>/Div)"...
Page 146: Rx>:Pulseview:yscale_Nw_Div
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements Example: PULSEVIEW:UNIT MW //Result: READY. PULSEVIEW:YSCALE_MW_DIV 0:5 //Result: READY. PULSEVIEW:YSCALE_MAXLEV_MW 5 //Result: READY. Manual operation: "Y-axis Scaling (<Unit>/Div)" on page 75 <RX>:PULSEVIEW:YSCALE_NW_DIV? <RX>:PULSEVIEW:YSCALE_NW_DIV <Scaling> Power range per division; defines the scaling of the y-axis, which consists of 10 divi- sions.
Page 147: Rx>:Pulseview:yscale_Uw_Div
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements Parameters: <Scaling> 1 | 2 | 3 | 5 | 10 | 20 | 30 | 50 | 100 Default unit: μV Return values: <SettingResult> READY Setting was successfully applied.
Page 148: Rx>:Pulseview:yscale_Maxlev_Dbm
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements <RX>:PULSEVIEW:YSCALE_MAXLEV_DBM? <RX>:PULSEVIEW:YSCALE_MAXLEV_DBM <Scaling> The maximum power level on the y-axis. Parameters: <Range> Range: -70 to +30 Default unit: dBm Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful.
Page 149: Rx>:Pulseview:yscale_Maxlev_Nw? :Pulseview:yscale_Maxlev_Nw
® Remote commands for DME/Pulse analysis R&S EDST300 Configuring measurements <RX>:PULSEVIEW:YSCALE_MAXLEV_NW? <RX>:PULSEVIEW:YSCALE_MAXLEV_NW <Range> The maximum power level on the y-axis. Parameters: <Range> Range: 1.0 to 1000 Default unit: nW Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful.
Page 150: Retrieving Results
® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results <RX>:PULSEVIEW:YSCALE_MAXLEV_MV? <RX>:PULSEVIEW:YSCALE_MAXLEV_MV <Scaling> The maximum power level on the y-axis. Parameters: <Range> Range: 1.0 to 1000 Default unit: mV Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful.
Page 151 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results ......................151 <RX>:MEASDATA? ......................151 <RX>:MEASDEF? ......................151 SETUSBLOGTIME .......................152 SETUSBLOGMODE ......................152 SETSTREAMTRG .....................153 <RX>:STOPSTREAM ......................153 <RX>:STREAM <RX>:MEASDATA? <ListType> This command returns the contents of one line in the logged data as a comma-separa- ted list.
Page 152 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results Example: Set the log interval to once per second. SETUSBLOGTIME 1000 //Result: READY. Manual operation: "[START]" on page 84 SETUSBLOGMODE <Mode> Defines how often a new log file is created.
Page 153 "[STOP]" on page 84 <RX>:STREAM <ListType> This command enables the R&S EDST300 to start sending a data stream to the remote control device as soon as the trigger event occurs (see SETSTREAMTRG on page 152). The data stream contains the results of the specified channel and time slots.
Page 154 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results ......................156 <RX>:DST:DELAY? ......................157 <RX>:DST:DST? ....................... 157 GETNRPPOW <RX>:DST:REPEFF? Queries the current reply efficiency in %. Return values: <Result> numeric value Default unit: % Usage: Query only Manual operation: "REPLY EFFIC. [%]"...
Page 155 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results Return values: <Result> Usage: Query only Manual operation: "ID-CODE" on page 43 <RX>:DME:ID_PRR? Returns the pulse repetition rate during ID transmissions Return values: <Result> Default unit: 1/s Usage: Query only Manual operation: "ID PRR [1/s]"...
Page 156 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results <RX>:DME:PULSE_SPACING? Returns the measured pulse spacing in us (corresponds to the pulse code as specified in the Chapter B, "DME channel frequency list", on page 168). Return values: <PCode> integer...
Page 157: Rx>:Tacan:bearing
..................158 <RX>:TACAN:FREQ_135HZ? ...................158 <RX>:TACAN:FREQ_15HZ? ................158 <RX>:TACAN:MOD_DEPTH_135HZ? ................158 <RX>:TACAN:MOD_DEPTH_15HZ? ..................159 <RX>:TACAN:PHASE_135HZ? ..................159 <RX>:TACAN:PHASE_15HZ? ..................159 <RX>:TACAN:PHASE_SHIFT? ................ 159 <RX>:TACAN:SET_DMESCREEN_PAGE ....................160 <RX>:DME:SET_VIEW <RX>:TACAN:BEARING? Direction of the ground station in relation to the R&S EDST300. User Manual 5202.9121.02 ─ 02...
Page 158: Rx>:Tacan:freq_135Hz
® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results Return values: <Result> Default unit: degrees Usage: Query only Manual operation: "BEARING [°]" on page 43 "BEARING [°]" on page 47 <RX>:TACAN:FREQ_135HZ? Returns the measured frequency of the nominal 135 Hz components Return values: <Result>...
Page 159: Rx>:Tacan:phase_135Hz
Note that this command is maintained for compatibility reasons only. Use <RX>:DME: for new remote control programs. SET_VIEW Parameters: <Page> DMESCREENPAGE_DME DME measurement results DMESCREENPAGE_TAC1 TACAN measurement results (page 1) (TACAN only, requires option R&S EDST300-K1) DMESCREENPAGE_TAC2 TACAN measurement results (page 2) User Manual 5202.9121.02 ─ 02...
Page 160 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results DMESCREENPAGE_MAINT ID Analysis results (TACAN only, requires option R&S EDST300-K1) Return values: <SettingResult> READY Setting was successfully applied. ERROR An error occurred; setting was not successful. Usage: Setting only <RX>:DME:SET_VIEW <View>...
Page 161 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results <RX>:PULSEVIEW:DATASET? Returns the measured power values from the power vs time diagram ("Pulse" view). Return values: <Result> comma-separated list of numeric values The number of values depends on the x-axis scaling (see <RX>:...
Page 162 ® Remote commands for DME/Pulse analysis R&S EDST300 Retrieving results Example: PULSEVIEW:ANALYSIS? Analysis_OK: true, Pulse1_Risetime_us: 2.000, Pulse1_Widthtime_us: 3.464, Pulse1_Decaytime_us: 1.987, Pulse2_Risetime_us: 1.995, Pulse2_Widthtime_us: 3.466, Pulse2_Decaytime_us: 1.999, Pulse_Spacingtime_us: 11.998, Peak_Variation_dB: -0.023, Peak_1_dBm: -31.164, Peak_2_dBm: -31.140, READY. Usage: Query only Manual operation: "Pulse rise time"...
Page 163: Troubleshooting
® Troubleshooting R&S EDST300 Contacting customer support 12 Troubleshooting Blown fuse If the product does not start, a blown fuse in the power supply can be the cause. Con- tact the Rohde & Schwarz customer service to confirm the fault symptoms. If the power supply has a blown fuse, you must return the product to the Rohde &...
Page 164: Maintenance, Storage, Transport And Disposal
13.2 Calibration Access: [CAL] It is recommended that the R&S EDST300 be calibrated once a year by a certified Rohde & Schwarz service technician. 13.3 Handling batteries Safe handling of batteries is described in "Handling batteries safely"...
Page 165: Storage
® Maintenance, storage, transport and disposal R&S EDST300 Disposal lithium battery, the instrument has to be opened. Only technical personnel authorized by Rohde & Schwarz are allowed to open the instrument. In both cases, contact Rohde & Schwarz customer service. See Chapter 12.1, "Con-...
Page 166 ® Maintenance, storage, transport and disposal R&S EDST300 Disposal Figure 13-1: Labeling in line with EU directive WEEE Rohde & Schwarz has developed a disposal concept for the eco-friendly disposal or recycling of waste material. As a manufacturer, Rohde & Schwarz completely fulfills its obligation to take back and dispose of electrical and electronic waste.
Page 167: Annex
® References R&S EDST300 Annex A References [1] Convention on International Civil Aviation Convention on International Civil Aviation, Volume 1 (Radio Navigation Aids), Sixth Edition of Volume 1 – July 2006; International Civil Aviation Organization Annex 10, Volume I Radio Navigation Aids, ICAO Application Notes: ●...
Page 168: B Dme Channel Frequency List
® DME channel frequency list R&S EDST300 B DME channel frequency list The following table indicates the frequencies and pulse codes for the interrogator (DME on-board transmitter) and reply (DME ground station) signals for specific DME channels as defined by the International Civil Aviation Organization (ICAO, see [1]).
Page 169 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1033 1033 1096 1034 1034 1097 1035 1035 1098 1036...
Page 170 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1042 1105 1043 1043 1106 1043 1106 1044 1044 1044...
Page 171 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1050 1050 1050 1113 1050 1113 1051 1051 1114 1051...
Page 172 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1056 1119 1057 1057 1120 1057 1120 1058 1058 1058...
Page 173 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1063 1126 1064 1001 1064 1001 1064 1127 1064 1127...
Page 174 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1070 1133 1071 1008 1071 1134 1071 1134 1072 1009...
Page 175 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1077 1140 1078 1015 1078 1015 1078 1141 1078 1141...
Page 176 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1086 1023 1086 1149 1087 1024 1087 1150 1088 1151...
Page 177 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1096 1033 1097 1160 1097 1034 1098 1161 1098 1035...
Page 178 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1106 1043 1106 1043 1107 1170 1107 1044 1107 1044...
Page 179 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1114 1177 1114 1051 1114 1051 1115 1178 1115 1052...
Page 180 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 1122 1185 1122 1059 1122 1059 1123 1186 1123 1060...
Page 181 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 105Z 1129 1066 106X 1130 1193 106Y 1130 1067 106Z...
Page 182 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 113Y 1137 1074 113Z 1137 1074 114X 1138 1201 114Y...
Page 183 ® DME channel frequency list R&S EDST300 Interrogation Reply DME chan- Frequency DME/N [µs] Initial Final Frequency Pulse codes nel number [MHz] approach approach [MHz] [µs] (IA) [µs] (FA) [µs] 121Y 1145 1082 122X 1146 1209 122Y 1146 1083 123X...
Page 184: C Format Description Of Dme Measurement Data
® Format description of DME measurement data R&S EDST300 C Format description of DME measurement data Which set of parameters are logged is user-definable and can be defined individually for each measurement by selecting the list type. When a list is stored to a file, a header line is automatically included that describes the provided parameters.
Page 185 ® Format description of DME measurement data R&S EDST300 If a parameter value is not available, nan is inserted. Table C-2: Logged parameters and their assignment to list types Parameter Value range Description Stream Counter. Counts the outgoing stream mes-...
Page 186 ® Format description of DME measurement data R&S EDST300 Parameter Value range Description AttMode "LOW_NOISE"," Attenuator at time of measurement NORM","LOW_DI In Attmode “AUTO” this value shows the real hard- ST" ware setting. IF2Gain GAIN0,GAIN15 Internal hardware setting. or GAIN30...
Page 187 ® Format description of DME measurement data R&S EDST300 Parameter Value range Description *ARB PULSE Number of pulse (pairs) per ARB group COUNT *MRB Spac- Pulse spacing of MRB pulses ing[µs] *ARB Spacing[µs] Pulse spacing of ARB pulses *MRB Peak Maximum pulse spacing of MRB pulses Space[µs]...
Page 188 ® Format description of DME measurement data R&S EDST300 Parameter Value range Description Long. GPS longitude Alt.[m] GPS altitude Speed[km/h] GPS speed Sats. Number of GPS satellites GPS fix “NO GPS" GPS Status "INVALID" "GPS" "DGPS" ( also used for EGNOS ) "GPS Prec."...
Page 189 ® Format description of DME measurement data R&S EDST300 Example: The following extract of a sample file shows the data results for a TAC3 list. Ctr,RX,MDME,Flags,Date,Time,dTime[ms],Freq[MHz],MeasTime[ms],AttMode,IF2Gain, PeakLevel[dBm],AvrgLevel[dBm],PulseRepRate[1/s],DeltaFreq[kHz],PulseSpacing[µs],ID_ON, ID_PRR[1/s],ID_CODE,ID_PERIOD,Mod15[%],Mod135[%],Freq15[Hz],Freq135[Hz],Phase15[°], Phase135[°/9],Bearing[°],Phaseshift[°],MRB PRR[1/s],ARB PRR[1/s],MRB COUNT,ARB COUNT, MRB Spacing[µs],ARB Spacing[µs],MRB Peak Space[µs],ARB Peak Space[µs],Counter [1/s], dot len[ms],dash len[ms],gap[ms],letter gap[ms],EQ pulse [µs],Delay[µs],Dist[km],...
Page 190: List Of Commands
® List of commands R&S EDST300 List of commands *IDN?................................114 *RST................................118 <RX>:DME:ATTMODE..........................127 <RX>:DME:ATTMODE?..........................127 <RX>:DME:AVRGLEVEL?..........................154 <RX>:DME:CARRIER_F_DELTA?........................ 154 <RX>:DME:DEMOD_BW..........................129 <RX>:DME:DEMOD_BW?..........................129 <RX>:DME:FREQ............................128 <RX>:DME:FREQ?............................128 <RX>:DME:ID_CODE?..........................154 <RX>:DME:ID_PRR?.............................155 <RX>:DME:ID_SEQLEN?..........................155 <RX>:DME:MEASTIME..........................128 <RX>:DME:MEASTIME?..........................128 <RX>:DME:PEAKLEVEL?..........................155 <RX>:DME:PULSE_REPT_RATE?....................... 155 <RX>:DME:PULSE_SPACING?........................156 <RX>:DME:RF_BW............................130 <RX>:DME:RF_BW?............................. 130 <RX>:DME:RFCH............................129 <RX>:DME:RFCH_PS?..........................156 <RX>:DME:RFCH?............................129...
Page 191 ® List of commands R&S EDST300 <RX>:DST:TPULSES.............................136 <RX>:DST:TPULSES?...........................136 <RX>:DST:TX_PCODE..........................131 <RX>:DST:TXON............................136 <RX>:DST:TXON?............................136 <RX>:DST:TXPOWER...........................137 <RX>:DST:TXPULSE_WIDTH........................132 <RX>:DST:TXPULSE_WIDTH?........................132 <RX>:MEASDATA?............................151 <RX>:MEASDEF?............................151 <RX>:MEASMODE_DME..........................126 <RX>:MEASMODE_PULSE.......................... 126 <RX>:MEASMODE?............................126 <RX>:PULSEVIEW:ANALYSIS?........................161 <RX>:PULSEVIEW:AVRG..........................139 <RX>:PULSEVIEW:AVRG?...........................139 <RX>:PULSEVIEW:BW..........................139 <RX>:PULSEVIEW:BW?..........................139 <RX>:PULSEVIEW:DATASET?........................161 <RX>:PULSEVIEW:TIMEDIV........................140 <RX>:PULSEVIEW:TIMEDIV?........................140 <RX>:PULSEVIEW:TRACE...........................140 <RX>:PULSEVIEW:TRACE?.........................140 <RX>:PULSEVIEW:TRIGDELAY........................141 <RX>:PULSEVIEW:TRIGDELAY?.........................141 <RX>:PULSEVIEW:TRIGDOUBLE....................... 141 <RX>:PULSEVIEW:TRIGDOUBLE?......................
Page 192 ® List of commands R&S EDST300 <RX>:PULSEVIEW:YSCALE_MAXLEV_UV?....................150 <RX>:PULSEVIEW:YSCALE_MAXLEV_UW....................148 <RX>:PULSEVIEW:YSCALE_MAXLEV_UW?....................148 <RX>:PULSEVIEW:YSCALE_MAXLEV_V....................149 <RX>:PULSEVIEW:YSCALE_MAXLEV_V?....................149 <RX>:PULSEVIEW:YSCALE_MV_DIV......................145 <RX>:PULSEVIEW:YSCALE_MV_DIV?....................... 145 <RX>:PULSEVIEW:YSCALE_MW_DIV......................145 <RX>:PULSEVIEW:YSCALE_MW_DIV?...................... 145 <RX>:PULSEVIEW:YSCALE_NW_DIV......................146 <RX>:PULSEVIEW:YSCALE_NW_DIV?.......................146 <RX>:PULSEVIEW:YSCALE_PW_DIV......................146 <RX>:PULSEVIEW:YSCALE_PW_DIV?.......................146 <RX>:PULSEVIEW:YSCALE_UV_DIV......................146 <RX>:PULSEVIEW:YSCALE_UV_DIV?......................146 <RX>:PULSEVIEW:YSCALE_UW_DIV......................147 <RX>:PULSEVIEW:YSCALE_UW_DIV?.......................147 <RX>:PULSEVIEW:YSCALE_V_DIV......................147 <RX>:PULSEVIEW:YSCALE_V_DIV?......................147 <RX>:SETUP:INPUT............................. 122 <RX>:SETUP:INPUT?...........................122 <RX>:STOPSTREAM............................ 153 <RX>:STREAM..............................153 <RX>:TACAN:BEARING?..........................157...
Page 193 ® List of commands R&S EDST300 REMOTELOCK.............................. 114 REMOTELOCK?............................114 RX_BOARD_FPGA_VER?..........................117 SET_ICAO_OVR............................137 SETEXPERT..............................137 SETGPSBAUD.............................. 120 SETGPSSYNC.............................. 121 SETSTREAMTRG............................152 SETUP:AF_VOLUME............................ 118 SETUP:AF_VOLUME?..........................118 SETUP:ANALOG_OUT_MODE........................121 SETUP:ANALOG_OUT_MODE?........................121 SETUP:COUNT_PULSES..........................119 SETUP:COUNT_PULSES?........................... 119 SETUP:DISPLAY_UPDATE_MS........................119 SETUP:DISPLAY_UPDATE_MS?........................119 SETUP:EXT_ATTENUATION_TYPE......................122 SETUP:EXT_ATTENUATION_TYPE?......................122 SETUP:MORSEMOST...........................119 SETUP:REFERENCE:EXTREFERENCE?....................123 SETUP:REFERENCE:SOURCE........................123 SETUP:REFERENCE:SOURCE?......................... 123 SETUP:RF1_EXTATTENUATION........................122...
Page 194: Index
® Index R&S EDST300 Index Alphanumeric parameters ..........33 Factory defaults ..............83 ANALOG IN Restoring ..............109 Connector ..............27 ANALOG OUT Connector ..............27 GBAS Application cards ............... 11 Data format ............... 184 Application notes ............... 11 Arrow keys ................ 23 Attenuation Basics .................
Page 195 ® Index R&S EDST300 Parameters Entering ..............32, 33 Power Key ................21 Power supply Connector ..............26 Preset Key ................83 Presettings ................ 82 REF INPUT Connector ..............28 Release notes ..............11 Restoring Factory defaults ............109 RF input attenuation Basics .................
