We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• ATTENTION: during use, the
appliance and its accessible
parts become very hot.
Children must be kept away
from the appliance.
• ATTENTION: during use, the
appliance and its accessible
parts become very hot. Never
touch the heating elements
during use.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
flames with a fire blanket or
24 - PRECAUTIONS
24
24
27
27
27
28
28
28
28
28
28
28
29
29
29
29
30
30
other appropriate cover.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical,
sensory or mental capacity, or
lacking in experience in the use
of electrical appliances,
provided that they are
supervised or instructed by
adults who are responsible for
their safety.
• Children must not play with the
appliance.
• Keep children under the age of
8 at a safe distance unless they
are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
31
31
31
31
32
33
33
34
34
34
34
36
36
37
38
38
39
91477A894/A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Smeg Victoria SF6905P1
Summary of Contents for Smeg Victoria SF6905P1
-
Page 1: Table Of Contents
Other parts Positioning Accessories We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions other appropriate cover. • This appliance may be used by... - Page 2 • Cleaning and maintenance current standards. must not be carried out by • Do not try to repair the unsupervised children. appliance yourself or without • The cooking process must the assistance of a qualified always be monitored. A short technician.
- Page 3 • Do not use steam jets to clean • Never use the oven door to the appliance. lever the appliance into place • Do not spray any spray product when fitting. near the appliance. • Avoid exerting too much • Do not obstruct ventilation pressure on the door when openings and heat dispersal open.
-
Page 4: For This Appliance
damaged, contact technical metres above sea level. support immediately to arrange For this appliance for it to be replaced in order to • Do not rest any weight or sit avoid possible hazards. on the open door of the • Always use any necessary/ appliance. -
Page 5: Manufacturer's Liability
Manufacturer’s liability Information for European Control Bodies The manufacturer declines all liability for damage to persons or property caused by: Fan forced mode • use of the appliance other than that the ECO function used to define the energy specified; efficiency class complies with the specifications •... -
Page 6: How To Read The User Manual
for use in high temperature applications such conventions: as ovens. • This appliance contains light sources of Warning/Caution efficiency class "G". How to read the user manual Information/Advice This user manual uses the following reading DESCRIPTION General description 1 Control panel 5 Door 2 Seal 6 Fan... -
Page 7: Other Parts
required function, set the cooking temperature Rack using the temperature knob. Other parts Shelves The appliance features shelves to position trays and racks at different heights. The insertion heights are indicated from the bottom upwards. Useful for supporting containers with food Cooling fan during cooking. -
Page 8: Use
Preliminary operations the food which is being cooked. See General safety instructions. • Remove any protective film from the outside or inside of the appliance, including accessories. • Remove any labels (apart from the technical data plate) from the accessories and Using the oven shelves. -
Page 9: Cooking Advice
BASE Cooking advice The heat only comes from the bottom of General advice the cavity. Perfect for cakes, pies, tarts • Use a fan assisted function to achieve and pizzas. consistent cooking at several levels. • It is not possible to shorten cooking times by TURBO increasing the temperature (the food could Allows quick cooking on multiple... -
Page 10: Mini Guide To Accessories
• To defrost meat, use the rack placed on the To save energy second level and a tray on the first level. In • Stop cooking a few minutes before the time this way, the liquid from the defrosting food normally used. -
Page 11: Information For Supervisory Bodies
Weight Temperature Food Function Shelf Time (minutes) (kg) (°C) Salmon trout Turbo/Fan-assisted 150 - 160 35 - 40 Monkfish Turbo/Fan-assisted 60 - 65 Flounder Turbo/Fan-assisted 45 - 50 Pizza Turbo/Fan-assisted 8 - 9 Bread Fan-assisted/Fan-Heated 190 - 200 25 - 30 Focaccia Turbo/Fan-assisted 180 - 190... - Page 12 1. Open the door completely and insert two 2. Remove the internal glass pane by pulling pins into the holes on the hinges indicated in the rear part gently upwards, following the the figure. movement indicated by the arrows 1. 3.
-
Page 13: Cleaning The Oven Cavity
6. Clean the external glass pane and the Drying panes removed previously. Cooking food generates moisture inside the appliance. This is a normal phenomenon and does not affect the appliance’s operation in any way. Each time you finish cooking: 1. Let the appliance cool down. 2. -
Page 14: Extraordinary Maintenance
overflow out of the cavity. 3. Use a non-scratch sponge with brass filaments on hard to remove deposits. 4. In case of grease residues use specific oven cleaning products. 5. Remove the residual water inside the oven. 6. Replace the self-cleaning panels and the rack/tray support frames, if fitted. -
Page 15: Installation
5. Replace the light bulb with one of the same Take care not to scratch the enamel of type (40 W). the oven cavity wall. 6. Refit the cover. Ensure the moulded part of the glass (A) is facing the door. 4. -
Page 16: Positioning
Cable replacement Fastening bushings Power voltage Danger of electrocution • Disconnect the mains power supply. 1. Unscrew the rear casing screws and remove the casing to access the terminal board. 1. Remove the bushing covers on the front of the appliance. 2. - Page 17 Mounting into a column (mm) Make sure that the cabinet top/rear section has an opening approx. 35-40 mm deep. 40 - INSTALLATION 91477A894/A...
- Page 18 A min. 603 mm B 560 - 568 mm C 583 - 585 mm D 9 - 11 mm E min. 5 mm F 121 - 1105 mm G min. 560 mm H min. 594 mm co Cutout for power cord (min. 6 cm jb Electrical connection box 91477A894/A INSTALLATION - 41...
- Page 19 Mounting under worktops (mm) If the appliance is to be built-in under a worktop, a wooden bar has to be installed order to use the seal that is glued to the back of the front panel to prevent water or other liquids leaking in. Make sure that the piece of furniture top/rear part has an opening approx.
- Page 20 A min. 603 mm B 560 - 568 mm C 583 - 585 mm D 9 - 11 mm E min. 5 mm F 121 - 1105 mm G min. 560 mm H min. 594 mm co Cutout for power cord (min. 6 cm jb Electrical connection box wb Wooden bar (recommended) 91477A894/A...
