Resolution, Frame rate, Bitrate type, video quality, etc. Three video streams are
available for configuration in this menu. Viewing experience is subject to the
actual network conditions.
• Resolution: Adjust the stream resolution from the available options
in the drop-down menu.
• Frame rate: The higher the frame rate, the more individual frames
will be shown per second. A higher FPS results in smoother video
but will increase the bitrate of the video stream.
• Bitrate type: Select between CBR and VBR bitrate types. Bitrate is
related to image quality.
• Bitrate (Kbps): Bitrate type must be set to CBR to manually adjust
this setting. A higher bitrate will result in better image quality.
• Video Quality: Bitrate type must be set to VBR to manually adjust
this setting. The higher the image quality, the more bitrate will be
required.
• I-Frame interval: Determines how many frames are allowed
between a "group of pictures" when a new scene begins in a video,
until that scene ends, and if an entire group of frames (or pictures)
can be considered as a "group of pictures". If there is not much
motion in the scene, setting the value higher than the frame rate
can potentially resulting in less bandwidth usage. However, if the
o
CBR: Compression bitrate will remain constant, of
change in the video scene.
o VBR: Compression bitrate will be adjusted according
to scene changes. For example, for scenes that do
not have much movement, the bitrate will remain at
a lower value. This can help optimize the network
bandwidth usage of the camera.
