Dining Collection
Round Tables
Assembly Guide
IMPORTANT!
DO NOT fully tighten the bolts until all bolts are started.
Once all bolts are inserted, go back & tighten all the bolts.
HARDWARE INCLUDED
A
1/4"-20 X 1.25"
B
1/4"-20 X 2"
C
The Top Support on the Leg
Assembly will look like this for
the 48" Table and will be
flipped for the 36" Table.
BRACE
B
1) Attach the (2) Braces to the
Leg Assembly with (2) B Bolts.
SEQUOIA
PROFESSIONAL
by
Qty: 4
Qty: 8
2" UMBRELLA GROMMET
Pedestal Assembly
BRACE
B
LEG ASSEMBLY
For information on Care and Cleaning or to Register your
SEQUOIA PROFESSIONAL product by highwood , please visit
Qty: 1
Leg Assembly
www.highwood-usa.com.
TOOLS INCLUDED
5/32" HEX KEY
B
Brace
2) Attach the Leg Assembly to
the (2) Braces with (2) B Bolts.
CM-DTRSQ36_48 | CM-CTRSQ36_48
B
Brace
01.20.2022
PAGE 1 OF 2
