Service
Repair Manual
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and
0BN, Rear Final Drive 0BP
Engine ID
Edition 12.2012
Service Department. Technical Information
CJW
CJW
CJW
B
C
E
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
CTW
CTW
CAT
A
B
A
CNR
CCG
B
A
