CAUTION: Certain procedures described in this manual require electrical power to the vending
machine. Only trained personnel should perform these functions. Use extreme caution.
CAUTION: Certain procedures described in this manual require a qualified, trained technician
to perform the particular task at hand.
Fig. 1 - Exterior View
Display Window
Door
Locks (2)
Fig. 2 – Back View
Electrical Panel
Charging Knock-Outs (shown
covered, one per compartment)
Auxiliary Connection
Ethernet Port (shown covered)
Power Connection
Revision 1 03.2017

MACHINE OVERVIEW

7
Service Doors (2)
Unlock with key and
remove in 2
sections each.
