MULTIPLE LOCKER CONFIGURATION

To install a third locker, use the Auxiliary Cable on the back of the main unit Auxiliary Connection (Fig. 2).
Fig. 6 – Auxiliary Cable
Locker 2
Main Locker
Locker 3
Revision 1 03.2017
10
