Summary of Contents for Atid RF-PRISMA
- Page 1 RF-PRISMA USER GUIDE ATID Co.,Ltd Ver 0.1...
-
Page 2: Table Of Contents
USING THE IOS HOST DEMO APPLICATION ..................19 FIRMWARE UPDATE ..........................20 ..........................20 IRMWARE PDATE REPARATION ........................... 20 IRMWARE PDATE ROCEDURE SDK (SOFTWARE DEVELOPMENT KIT)....................23 PRODUCT WARRANTY ..........................24 RF-P ............................. 24 RISMA RODUCT ETAILS SDK D ................................24 OWNLOAD RF-Prisma User Guide... - Page 3 ........................24 ARRANTY AND ECHNICAL UPPORT ................................24 ERTIFICATIONS RF-Prisma User Guide...
-
Page 4: Before The Beginning
Before the Beginning The objective of user guide is to pass the basic contents related with RF-Prisma`s maintenance and smooth uses. User guide inclusive of text, images, logos, product name may not be distributed, modified, displayed, reproduced (in whole or in part) without the prior written permission of ATID Co,.Ltd. -
Page 5: Key Features
4) It can be connected to a PC through Micro USB and can be charged simultaneously with data transmission. 5) Even without a charging adapter, it can be charged using a regular smartphone charger. RF-Prisma User Guide... -
Page 6: Product Specifications
2D Engine (Support to read 1D & 2D Barcode / Optional) Communication Bluetooth BT V2.1+EDR / BLE V4.1 (MFi Certified) User Environment Operating Temp -10°C to 45°C Storage Temp -30°C to 60°C Humidity 5~95% (non-condensing, +25°C Drop Spec 1.2m RF-Prisma User Guide... -
Page 7: Configuration Of The Product
Smartphone Holder Battery Pack Hand Strap Micro USB Cable Adaptor 2. Product Appearance Data LED Bluetooth LED Charging LED RFID Antenna Power Button 버튼ㄹㅇ안테나 Reading Toggle Button Reset Button Battery Pack Strap Anchor Battery Release Button USB Connector RF-Prisma User Guide... -
Page 8: Barcode Option
Smartphone holders are provided with different types of brackets as shown below depending on whether or not the barcode option is selected. For a detailed guide on attaching to the bracket, please refer to the ‘Attaching the Smartphone Holder’ section. Barcode Module Option Standard Option RF-Prisma User Guide... -
Page 9: Operation Of The Product
2) Reading Toggle Button : Reading starts when it is pressed once, and reading execution and stop are alternated each time it is pressed. In case of reading, the reading state is maintained even if the button is not pressed. If RF-Prisma is not connected to the host, this button does not work. -
Page 10: Battery Replacement
• unkonwn adapter may cause malfunction of the device. The device is charged even when a USB cable is connected for data communication • with a PC. In this case, it will charge at a low rate. RF-Prisma User Guide... -
Page 11: Attaching The Smartphone Holer
1) Open the product fixing structure of the 2) Covers the product fixing structure. smartphone holder and position the product as shown in the picture. 3) Flip the smart holder fixing clip upward for fixing the smartphone holder. RF-Prisma User Guide... -
Page 12: Installation Smartphone Holder With Barcode Module
Push the protective part down to separate Place the smartphone holder on the them. exposed position by separating the protective part. After that, tighten the screw, and cover the protective cap for fixing it. RF-Prisma User Guide... -
Page 13: Using The Android Demo Application
If you click ‘Connect to new Bluetooth If user click the reader user wants to device’, RF-Prisma that is turned on connect to, the Host device will ask you to nearby will be searched and displayed. - Page 14 Barcode Option : Set options related to the barcode function. • For details on how to use the demo app, refer to the ‘RF Prisma SDK Demo Guide for Android Developer’ document included in the SDK. RF-Prisma User Guide...
-
Page 15: Windows Host Bluetooth Connection Settings
Windows Host Bluetooth Connection Settings To send/receive data with a Windows platform device using Bluetooth, the RF-Prisma requires a PC with built-in Bluetooth functionality or a dedicated Bluetooth dongle. This chapter describes the Bluetooth connection method for Windows 10, which are representative Windows platforms. - Page 16 5) Turn on RF-Prisma and select Bluetooth as the device type to add. Select to start searching for Bluetooth devices requesting pairing in the vicinity. 6) If user clicks the device user wants to connect among the searched Bluetooth devices, the pairing information screen of the target device is activated.
- Page 17 7) When pairing is completed normally, ‘Your device is ready to go!’ message is displayed. Click the Done button to complete the pairing process. 8) When the device is added successfully, the device will be registered with the message ‘Paired’. RF-Prisma User Guide...
-
Page 18: Using The Windows Host Demo Application
1) When the Demo App for Windows Host included in the SDK is executed on the host device, it is executed as follows. 2) Select and connect the connection method (USB or Bluetooth) between RF-Prisma and the Windows Host device. -
Page 19: Using The Ios Host Demo Application
The demo application is available from iOS version 10.2 or later. • 데 For details on how to use the demo app, refer to the ‘ATID Reader Demo Guide • for iOS’ document included in the SDK. RF-Prisma User Guide... -
Page 20: Firmware Update
Save the firmware file in a specific folder on your PC. Execute the firmware update program. ‘After clicking the ‘Load Binary File’ button, move to the folder where the firmware file was saved earlier and select the image to update. RF-Prisma User Guide... - Page 21 Connect RF-Prisma to PC using USB Cable. Click the ‘select comport’ button in the PC update program to select the COM Port assigned to the RF-Prisma connected to the PC. COM Port is assigned a different number depending on the PC situation.
- Page 22 Click the ‘DOWNLOAD’ button to start the firmware update. After a while, the product will automatically restart when the download is complete. RF-Prisma User Guide...
-
Page 23: Sdk (Software Development Kit)
When the device operates in interactive mode, a separate program must be developed by referring to the SDK provided by ATID in order to utilize the data transmitted from the host device. ATID Bluetooth Reader SDK supports three platforms: Android, Windows, and iOS. -
Page 24: Product Warranty
If you need RF-Prisma SDK, please contact us or the place of purchase. 3. Warranty and Technical Support All ATID Co.,Ltd. products can be repaired free of charge for one year based on the product manufacturing date. However, in principle, any defects caused by customer carelessness in use shall be repaired even during the free repair period.
