Atid AT388 User Manual

Hide thumbs Also See for AT388:
Table of Contents

Advertisement

Quick Links

Download this manual
AT388 USER GUIDE
ATID Co.,Ltd
Ver 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT388 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atid AT388

Summary of Contents for Atid AT388

  • Page 1 AT388 USER GUIDE ATID Co.,Ltd Ver 1.1...

  • Page 2: Table Of Contents

    OFF ..................................16 OWER BARCODE, RFID TAG DATA CAPTURE ....................17 ............................... 17 ARCODE APTURE RFID T .............................. 17 APTURE SWITCH HOST COMMUNICATION MODE ................... 18 SCAN SETTING MODE ..........................19 ..................................19 ................................... 19 PLOAD ..................................19 RASE AT388 User Guide...
  • Page 3 IRMWARE PDATE REPARATION ........................... 44 IRMWARE PDATE ROCEDURE SDK (SOFTWARE DEVELOPMENT KIT)....................47 PRODUCT WARRANTY ..........................48 AT388 P ............................. 48 RODUCT ETAILS SDK D ................................48 OWNLOAD ........................48 ARRANTY AND ECHNICAL UPPORT ................................48 ERTIFICATIONS AT388 User Guide...

  • Page 4: Before The Beginning

    Before the Beginning The objective of user guide is to pass the basic contents related with AT388`s maintenance and smooth uses. User guide inclusive of text, images, logos, product name may not be distributed, modified, displayed, reproduced (in whole or in part) without the prior written permission of ATID Co,.Ltd.

  • Page 5: Key Features

    Key Features AT388 is a strong industrial product that meets IP65 and 1.5m drop standards. 2) AT388 comes with Honeywell high performance Barcode Engine N3680. 3) The Impinj’s high performance R2000 Module is equipped, allowing the UHF RFID Tag to be read/write at high speed.

  • Page 6: Product Specifications

    2D Engine (Support to read 1D & 2D Barcode) Communication Bluetooth BT V2.1+EDR / BLE V4.1 WLAN User Environment Operating Temp -20°C to 50°C Storage Temp -30°C to 70°C Charging Temp 0°C to 45°C Humidity 5~95% (non-condensing, +25°C Drop Spec 1.5m Sealing IP65 AT388 User Guide...

  • Page 7: Configuration Of The Product

    Configuration of the product 1. Product Components Micro USB Cable AT388 Battery Hand Strap AT388 User Guide...

  • Page 8: Product Appearance - Front

    7) Communication Mode Switching Button : Switches the USB and Bluetooth modes by this button. 8) Reset Button : Rebooting the product. 9) Cancel Button : Cancel or Call the upper menu. 10) RFID Antenna : Circular type RFID antenna. 180° tilt structure is applied. AT388 User Guide...

  • Page 9: Product Appearance - Left / Right , Top / Bottom

    3) Strap Hole : A neck strap or hand strap included with the product can be connected. Protective Cover : When the USB port is not in use, a protective cover is used to protect it from external contamination. AT388 User Guide...

  • Page 10: Product Appearance - Back

    ‘UNLOCK’ position to open the battery cover. 3) Product Label : A label is attached on here that showing the input voltage and certification information, etc, and the manufacturing serial number. AT388 User Guide...

  • Page 11: Operation Of The Product

    : Cancels the current selection in the Settings menu and returns to the previous step. 8) Power / OK Button : Press and hold for 1 second or longer to turn the power on/off, or select a specific item. AT388 User Guide...

  • Page 12: Configuration And Operation Of Led

    2) Scan LED : The blue LED turns on when recognizing Barcode or RFID information according to the setting. 3) Power LED : The red LED turns on when the product starts charging. Conversely, when the battery is low and flashes when charging is required. The green LED turns on when charging is complete. AT388 User Guide...

  • Page 13: Battery Replacement

    3) Remove the installed battery and insert a new battery into the battery slot with the + and - polarities aligned. 4) After assembling the battery cover again, move the battery LOCK to the LOCK position to fix the battery so that it does not come off. AT388 User Guide...

  • Page 14: Screen Configuration

    Screen Configuration AT388 displays various contents such as displaying the current status of the product and read data through a small OLED screen. The screen is divided into a status display section and a message display section. Status Display Area Message Display Area 1.

  • Page 15: Selection Of Operation Mode

    Selection of Operation Mode AT388 operates in three modes: scan mode, scan setting mode, and Device setting mode. 1) Scan Mode This is the first screen user can see when user turns on the product, and it is a mode in which user can check the read barcode and RFID tag in real time or connect with a host device.

  • Page 16: Power On, Off

    3) After ‘Scan Ready’ message is displayed on the screen, user can start to read Barcode data or RFID Tag data. 2. Power OFF After the AT388 boots normally, press and hold the Button for about 2 seconds to display a message to confirm whether the power is off.

  • Page 17: Barcode, Rfid Tag Data Capture

    2. RFID Tag Data Capture Select the mode to use while the product is powered on. 2) When the ‘Scan Ready’ message is displayed, user can capture the RFID Tag Data by pressing the ‘RFID Scan’ Button. AT388 User Guide...

  • Page 18: Switch Host Communication Mode

    • The ‘?’ sign changes to ‘H’, ‘S’, and ‘L’ when connected to the actual parent device. • Refer to page 15 for ‘H, S, and L status’. 4) Pressing the Button while connected to the Host will prompt user to switch communication. AT388 User Guide...

  • Page 19: Scan Setting Mode

    3. Erase Data This function completely deletes the data stored in the internal storage. Data once erased cannot be recovered. 4. Data Space This is a function to check the usage of internal storage. AT388 User Guide...

  • Page 20: Comm & Mode

    4) Batch – USB : The captured data is saved in the internal storage and then sent to the host device in batches via USB. 5) Interactive – BTH : Transmits captured data to host device according to ATID Protocol. In the host device, it is linked with the application developed with ATID SDK. (Android, Windows, iOS).

  • Page 21: Device Setting Mode

    BARCORDE – RFID : When the Barcode Scan Button is pressed, the barcode is activated, and • when the RFID Scan Button is pressed, the RFID is activated. BARCORDE + RFID : When the any Button is pressed, device capture Barcode and RFID together • at the same time. AT388 User Guide...

  • Page 22: Comm & Mode

    • 3. Comm & Mode AT388 can be connected to the host device through Bluetooth or USB. User can make detailed connection settings in this menu. BTH Protocol : This is the communication protocol to use when connecting with the host device via Bluetooth.
  • Page 23 Batch – USB : The captured data is saved in the internal storage and then sent to the host device • in batches via USB. Interactive – BTH : Transmits captured data to host device according to ATID Protocol. In the • host device, it is linked with the application developed with ATID SDK. (Android, Windows, iOS).

  • Page 24: Data Format

    Month & Date : Set whether to use month/day data for time data. (MMDD) • Hour & Minute : Set whether to use hour/minute data for time data. (HHMM) • 3) Quantity : Set whether to input the quantity of read barcode data. The Quantity setting works only AT388 User Guide...
  • Page 25 5) Terminator : This is a function to set the delimiter to be added to the end of the data when transmitting captured data in HID mode to the host device connected to the AT388. It can be set among LF, CR, CR & LF, tab, space, semicolon, and None.

  • Page 26: Network Setup

    Host Pairing : When using Bluetooth connection mode, it provides a function for pairing with the Host device. ‘1. BTH Pairing’ : Changes to standby for pairing with the Host device through Bluetooth and • exchanges information related to pairing. The device identification name required for pairing is also displayed. AT388 User Guide...

  • Page 27: System Setup

    6. System Setup Set the time, buzzer, vibrator, display, etc. options of AT388. Clock Setting : This is a menu to set the current time of AT388. The specified time can be used with Barcode Label Data. Please set the time regularly as time errors can occur.

  • Page 28: Config Setup

    In this mode, the connection mode is changed so that it is connected through a PC and a USB VCP (Virtual Serial Port). For the dedicated setting program for PC, please refer to the separately distributed manual. AT388 User Guide...

  • Page 29: Factory Reset

    For details on firmware, please contact the reseller or manufacturer. 11. Download FW This function is used to update the firmware of the product. For details, please refer to ‘Firmware Update’ Chapter. AT388 User Guide...

  • Page 30: Use Of Batch Processing Mode

    Using Batch Processing Mode If AT388 is set to ‘Batch Processing Mode’, data can be saved in the internal storage of the device without connecting to the host. The stored data can be transmitted to the host device through USB or Bluetooth communication.

  • Page 31: Transmission Of Stored Data

    In ‘Scan Mode’, press ‘◀ Button’ for 2 seconds to enter ‘Scan Setting Mode’. Select ‘2. Upload Data’ menu. User must proceed to the next step without pressing ‘YES’. Search for ‘AT388-XXXX’ in Bluetooth Device Scan Menu of Android Host and register it. AT388 User Guide...
  • Page 32 ‘Scan Setting Mode’ menu. 2) Example #2 : Data transmission method when setting ‘Batch-USB’ , Windows Host, ‘USB- VCP’. Reading Barcode or RFID Tags under batch processing mode. The read data is displayed on the AT388 screen. AT388 User Guide...
  • Page 33 As the % of transmitted data is displayed on the device screen, the data stored in the Host is transmitted. When transmission is complete, the message ‘100% finished’ is displayed on the device. Unlike ‘HID’ mode, since there is no terminator, data is output continuously without line AT388 User Guide...
  • Page 34 Connect the Demo App and click the ‘Stored Data’ menu. If user press the ‘Load’ button in the ‘Stored Data’ menu, the saved data is transferred to the Demo App. For details on how to use the Android demo application, refer to the ‘ATID Reader Demo Guide’ document included in the SDK.

  • Page 35: Using The Android Demo Application

    2) User can download the demo app through ‘Google App Store’ or install it on the host device by using the installation file included in the SDK. For details on how to use the Android demo application, refer to the ‘ATID Reader Demo Guide for Andorid’ document included in the SDK.

  • Page 36: Bluetooth Connection Settings

    Bluetooth Connection Settings To send/receive data with a Windows platform device using Bluetooth, the AT388 requires a PC with built-in Bluetooth functionality or a dedicated Bluetooth dongle. This chapter describes the Bluetooth connection method for Windows 7 and Windows 10, which are representative Windows platforms.
  • Page 37 3) The Bluetooth device is automatically searched. After selecting the ‘AT388-XXXX’ that you want to connect to, press ‘Next (N)’ to proceed with adding a device. 4) When the connection code confirmation window is displayed, click ‘Next (N)’ to proceed. The connection code does not need to be specially changed.
  • Page 38 Bluetooth devices. From this menu, user can find the COM port information assigned to the Bluetooth device. 8) After that, exit the AT388 setup menu and set it to the desired operation mode before using it. AT388 User Guide...

  • Page 39: Windows 10 Platform

    2. WINDOWS 10 Platform After entering the Device Setting Mode of AT388, move to ‘5. Network Setup → 2. Host Paring → 3. BTH Pairing’. 2) Enter the Windows Settings menu through ‘ Start → Settings’ of Windows. 3) Select ‘Device’ menu in Windows settings.
  • Page 40 After checking that it matches information of the screen of AT388, if it matches, click the ‘Connect’ button. The 4 digits after the device name to be searched are the last 4 digits of the Bluetooth Module MAC Address.
  • Page 41 The COM Port information assigned to the device can be checked in the ‘Hardware’ tab of the ‘Properties’ of the connected device in ‘Devices and Printers’ of the control panel. 10) After confirming that the AT388 and the host device are connected, exit the Device Setting Menu and set the desired operation mode before use.

  • Page 42: Using The Windows Host Demo Application

    ‘Interactive-XXX’. 3) User can install the demo app included in the SDK on the host device. For details on how to use the Windows demo application, refer to the ‘ATID Reader Demo Guide for Windows’ document included in the SDK.

  • Page 43: Using The Ios Host Demo Application

    2) User can download the demo app through the ‘App Store’. The demo application is available from iOS version 10.2 or later. • For details on how to use the demo app, refer to the ‘ATID Reader Demo Guide for iOS’ • document included in the SDK. AT388 User Guide...

  • Page 44: Firmware Update

    2. Firmware Update Procedure Save the firmware file in a specific folder on your PC. Execute the firmware update program. After clicking the ‘Load Binary File’ button, designate the folder where the firmware file was previously saved. AT388 User Guide...
  • Page 45 Connect AT388 to PC using USB Cable. Enter ‘11. Download FW’ from ‘Device Setting Menu’. Click the ‘select comport’ button of Firmware Download Tool. Then, select the COM Port assigned to AT388 connected to your PC. COM Port is assigned a different number depending on the PC situation.
  • Page 46 Click the ‘offline’ button to attempt to connect to the device. When connected normally, the button changes to ‘online’ and displays the current firmware version. Click the ‘DOWNLOAD’ button to start the firmware update. After a while, the product will automatically restart when the download is complete. AT388 User Guide...

  • Page 47: Sdk (Software Development Kit)

    When the device operates in interactive mode, a separate program must be developed by referring to the SDK provided by ATID in order to utilize the data transmitted from the host device. ATID Bluetooth Reader SDK supports three platforms: Android, Windows, and iOS.

  • Page 48: Product Warranty

    If you need an AT388 SDK, please contact us or the place of purchase. 3. Warranty and Technical Support All ATID products can be repaired free of charge for one year based on the product manufacturing date. However, in principle, any defects caused by customer carelessness in use shall be repaired even during the free repair period.
