- Page 1 EXOR International Industrial Computing Solutions eTOP-MON eTOP-MON 1600P/1800P/2100P User Manual www.exorint.net...
-
Page 2: Table Of Contents
Overview - eTOP-MON 1800P ..............2 VGA Port ...................16 Key Features ...................2 DVI Port (DVI-D) .................16 Overview - eTOP-MON 2100P ..............3 USB Port ....................17 Key Features ...................3 Specifications ..................4 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... - Page 3 Content Chapter 3: System Setup Panel Mounting ..................18 Chapter 4: Adjusting the Display OSD Menu Functions ................20 Appendix A: Extended Display Identification Data Timing Support..........33 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
-
Page 4: Preface
Declaration of Conformity in any form or by any means without the prior written consent from EXOR International S.p.A. The product(s) described in this manual complies with all applicable Disclaimer European Union (CE) directives if it has a CE marking. -
Page 5: Rohs Compliance
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, EXOR has established an engineering and manufacturing task force to implement the introduction of green products. -
Page 6: Warranty And Rma
This warranty covers all the products/shipments except for: b. It had been altered by persons other than an authorized EXOR service person or, which have been subjected to misuse, abuse, accident, or 1. Any claimed defect, products that have been repaired or modified by improper installation. - Page 7 RMA that EXOR has determined not to be covered by the warranty will Product Repairing be charged the EXOR Standard Repair Fee for the repairing. If a RMA is 1. EXOR will repair defective products covered under this limited warranty determined to be not repairable, customer will be notified and product(s) that are returned to EXOR;...
- Page 8 Basic Labor Cost and Testing Fee. b. Parts Fee: EXOR will charge for main IC chipsets such as the N.B., S.B., Super-IO, LAN, Sound, Memory, and so on. c. 3rd-party Device Fee: products replacement for CPU, DIMM, HDD, Chassis, and UPS.
-
Page 9: Safety Information
Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 10: Safety Precautions
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS. 10. All cautions and warnings on the equipment should be noted. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 11: Technical Support And Assistance
Preface Technical Support and Assistance Conventions Used in this Manual 1. For the most updated information of EXOR products, visit EXOR’s website Warning: at www.exorint.net. Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself 2. -
Page 12: Package Contents
Item Description USB Touch Cable (1.8m) VGA Cable (1.8m) Terminal blocks 3-pin Phoenix Contact Plug Terminal blocks 3-pin Phoenix USB Touch Cable VGA Cable Contact Plug Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 13: Ordering Information
21.5” Full HD Heavy Industrial 16:9 LED backlight P-Cap touch monitor US Power Cord UK Power Cord with VGA, DVI-D and DisplayPort input, 12~24VDC input EU Power Cord 1.8m DVI-D Cable Copyright © 2015 EXOR International S.p.A. All Rights Reserved. xiii eTOP-MON 1600P/1800P/2100P User Manual... -
Page 14: Chapter 1: Product Introduction
Mounting support: panel/wall/stand/VESA 100mm x 100mm Wide range power input 12V~24V DC Note: Photo is for reference. Please refer to the mechanical engineering drawing for final appearance. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 15: Overview - Etop-Mon 1800P
Mounting support: panel/wall/stand/VESA 100mm x 100mm Wide range power input 12V~24V DC Note: Photo is for reference. Please refer to the mechanical engineering drawing for final appearance. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 16: Overview - Etop-Mon 2100P
Mounting support: panel/wall/stand/VESA 100mm x 100mm Wide range power input 12V~24V DC Note: Photo is for reference. Please refer to the mechanical engineering drawing for final appearance. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 17: Specifications
Dimension: 417.4 x 312.4 x 51.75mm Video port: VGA (1xDB15)/DVI-D (1xDVI-D connector)/DisplayPort Weight: 5.48Kg DC power input connector: 3-Pin terminal block Certifications OSD Function CE (including EN61000-6-1/EN61000-6-2/EN61000-6-3/EN61000-6-4) OSD keypad Multilanguage OSD Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 18: Specifications
Dimension: 490.8 x 320.6 x 50.65mm Video port: VGA (1xDB15)/DVI-D (1xDVI-D connector)/DisplayPort Weight: 6.24Kg DC power input connector: 3-Pin terminal block Certifications OSD Function CE (including EN61000-6-1/EN61000-6-2/EN61000-6-3/EN61000-6-4) OSD keypad Multilanguage OSD Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 19: Specifications
Dimension: 562.4 x 382.4 x 50.85mm Video port: VGA (1xDB15)/DVI-D (1xDVI-D connector)/DisplayPort Weight: 7.87Kg DC power input connector: 3-Pin terminal block Certifications OSD Function CE (including EN61000-6-1/EN61000-6-2/EN61000-6-3/EN61000-6-4) OSD keypad Multilanguage OSD Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 20: Knowing Your Etop-Mon Series
Inside OSD Menu: Press to select the highlighted option in OSD menu. Increase Brightness/ decrease value move down/ increase value Menu AUTO|EXIT AUTO|EXIT Press to exit the OSD menu, or return to main menu. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 21: Rear Bottom View
DisplayPort to connect the system with display devices. DC Input DisplayPort DVI-D 12 – 24V DC Input Terminal block socket used to plug a DC power cord. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 22: Rear View Of Etop-Mon 1600P
Rear View of ETOP-MON 1600P VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Holes These are mounting holes for VESA mount (100x100mm) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 23: Rear View Of Etop-Mon 1800P
Rear View of ETOP-MON 1800P VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Holes These are mounting holes for VESA mount (100x100mm) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 24: Rear View Of Etop-Mon 2100P
Rear View of ETOP-MON 2100P VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Holes These are mounting holes for VESA mount (100x100mm) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 25: Mechanical Dimensions
ETOP-MON 1600P 76.7 417.4 (OUTLINE) 51.75 396 (MOUNTING LINE) 10.7 35.76 345.89 (V/A) 60.5 167.5 Active Area (344.23*193.54) Active Center 158.7 26.75 CUT OUT SIZE T=12mm (MAX) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 26: Etop-Mon 1800P
Chapter 1: Product Introduction ETOP-MON 1800P 113.4 50.65 490.8 (OUTLINE) 195.4 39.6 411.6 (V/A) Active Area(344.23*193.54) Active Center 470.4 (MOUNTING LINE) 10.2 25.65 475.4 CUT OUT SIZE T=12mm (MAX) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 27: Etop-Mon 2100P
ETOP-MON 2100P 149.2 50.85 562.4 (OUTLINE) 542 (MOUNTING LINE) 10.2 41.88 478.64 (V/A) 167.5 167.5 113.2 Active Area(476.64*268.11) Active Center 231.2 25.85 CUT OUT SIZE T=12mm (MAX) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 28: Chapter 2: Connector Pin Definitions
Connector type: Phoenix Contact 1x3 3-pin terminal block Connector type: DisplayPort Definition Definition Definition LANE0_P LANE0_N LANE1_P LANE1_N LANE2_P LANE2_N LANE3_P LANE3_N CONFIG1 CONFIG2 AUX_CH_P AUX_CH_N RETURN DP_PWR Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 29: Vga Port
SGND TMDS Data 1- TMDS Data 1+ Shield HSYNC or CSYNC VSYNC Hot plug detect TMDS data 0- TMDS data 0+ Shield Shield TMDS clock+ TMDS clock- Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 30: Usb Port
Chapter 2: Connector Pin Definitions USB Port Connector type: USB port Definition VCC5 DATA_N DATA_P Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... -
Page 31: Chapter 3: System Setup
12mm. If the distance between the front bezel and panel mount hole is too wide, it will not fit the panel mount kit. ETOP-MON 1800P 12mm 12mm ETOP-MON 1600P ETOP-MON 2100P Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... - Page 32 Do not overtighten the screws to prevent damaging the CAUTION! CAUTION! CAUT CAUT CAUT CAUT CAUTION! UTIO UTION! UTIO UTIO ION! Panel PC. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
-
Page 33: Chapter 4: Adjusting The Display
► ► luminance contrast to decrease the contrast. 1. Luminance ► ► ► ► ► Luminance Luminance Contrast Contrast Brightness Brightness Eco Mode Eco Mode Standard Standard Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... - Page 34 Eco Mode settings. Luminance Luminance Contrast Contrast Brightness Brightness Eco Mode Standard Eco Mode Standard The following Eco Mode options are available: Text, Standard, Sports, Movie, Game and Internet. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 35 ► DCR On or Off. luminance to scroll right to turn ► ► ► ► ► ► DCR On or Off. Luminance Contrast Brightness Eco Mode Standard Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 36 ► ► ► ► ► ► ► Phase the screen towards left. H.Position V.Position Image Ratio Wide Image Setup Clock Phase H.Position V.Position Image Ratio Wide Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 37 Image Setup Image Setup Clock Clock Phase Phase H.Position H.Position V.Position V.Position Image Ratio Wide Image Ratio Wide Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 38 ► ► ► ► ► ► Clock to move the screen down. Phase H.Position Image Setup V.Position Clock Image Ratio Wide Phase H.Position V.Position Image Ratio Wide Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 39 Blue The following color temperature options are available: Warm, Normal, Cool, User and sRGB. To configure the RGB values manually, select User from the Color Temp. options. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 40 ► ► ► increase the value. luminance Color Temp. ► ► ► ► ► ► ► ► decrease the value. Color Temp. User Color Temp. Green Blue Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 41 OSD Setup H.Position ► ► ► ► ► ► ► V.Position to move the OSD screen towards left. Timeout Language English OSD Setup H.Position V.Position Timeout Language English Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 42 OSD screen down. to decrease the OSD screen timeout value. OSD Setup OSD Setup H.Position H.Position V.Position V.Position Timeout Timeout Language English Language English Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 43 OSD Setup H.Position V.Position Timeout Language English The following languages are available: English, Simplified Chinese, Traditional Chinese, Korean, Russian, Portuguese, French and Spanish. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 44 Reset Information Resolution 1366(H) x 768 (V) H.Frequency: 48KHz Extra V.Frequency: 60Hz D-SUB Input Select DDC/CI Reset Information Resolution 1366(H) x 768 (V) H.Frequency: 48KHz V.Frequency: 60Hz Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
- Page 45 Extra D-SUB Input Select Reset DDC/CI Information Resolution 1366(H) x 768 (V) Reset H.Frequency: 48KHz V.Frequency: 60Hz Information Resolution 1366(H) x 768 (V) H.Frequency: 48KHz V.Frequency: 60Hz Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
-
Page 46: Appendix A: Extended Display Identification
1280 x 1024 60Hz 1280 x 1024 75Hz 1280 x 1024 75Hz 1280 x 1024 75Hz 1366 x 768 60Hz 1366 x 768 60Hz 1366 x 768 60Hz Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual... - Page 47 1366 x 768 60Hz 1600 x 900 60Hz 1600 x 900 60Hz 1600 x 900 60Hz 1920 x 1080 60Hz 1920 x 1080 60Hz 1920 x 1080 60Hz Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-MON 1600P/1800P/2100P User Manual...
