- Page 1 User’s Manual for eTOP Series 300 Touchscreen Products eTOP Series 300 Operating Instructions MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A.
- Page 2 “as is” without warranty of any kind. Third-party brands and names are the property of their respective owners. www.exorint.com MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice...
-
Page 3: Table Of Contents
13 Special modes: Calibration, configuration and safe mode 13.1 Touchscreen calibration 13.2 Go to configuration mode 13.3 Safe mode 14 Dedicated LED indicators 15 Unpacking and packing Instructions MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 4: Introduction
Operator interface with TFT color 12” display eTOP313 Operator interface with TFT color 13.3” widescreen display eTOP315 Operator interface with TFT color 15” display MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 5: Safety Guide
ATTENTION: indicates a failure to observe safety rules and that deficiency may cause damage. ATTENTION CAUTION: indicates a failure to observe safety rules and that deficiency may cause defects to the equipment or inconsistencies. CAUTION MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 6: Product Overview
Report printing to serial printer. Reports are freely configurable using Designer. • Ethernet-based UniNet network to share data between HMIs and to serve data using UniNet OPC Server. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 7: Standards And Approvals
An example of this plate is shown in the figure below: eTOP306 product model name ETOP306U1P1 product part number 1846 year/week of production AA0000187123456789AA serial number HW76B3FW76S590P version id of the product MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 8: Technical Specifications
80 MHz ÷ 1 GHz, 10V/m EN 61000-4-3 electromagnetic field immunity test 1,4 GHz ÷ 2 GHz, 3 V/m 2 GHz ÷ 2.7 GHz, 1 V/m MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... - Page 9 100% duration: 1 cycle and 250 cycles (50Hz); 40% duration: 10 cycles (50Hz); duration: 25 cycles (50Hz); Phase: 0°-180° Test executed on the 230Vac side of the Exor International Power Supply EN 61000-4-11 Durability information Backlight service life 40000 Hrs. or more...
-
Page 10: Technical Data
1024 Event list 1024 1024 Voltage 18-30VDC 18-30VDC Current rating (at 24VDC) 0.55A 0.55A Temperature range (vertical 0-50°C 0-50°C installation) Weight 1 Kg 1 Kg MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... - Page 11 1024 Event list 1024 1024 Voltage 18-30VDC 18-30VDC Current rating (at 24VDC) 0.8A 0.8A Temperature range (vertical 0-50°C 0-50°C installation) Weight 1.2 Kg 2.1 Kg MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice...
- Page 12 1024 Event list 1024 1024 Voltage 18-30VDC 18-30VDC Current rating (at 24VDC) 1.05A 0.6A Temperature range (vertical 0-50°C 0-50°C installation) Weight 2.8 Kg 2.5 Kg MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice...
- Page 13 Real Time Clock Password Alarms 1024 Event list 1024 Voltage 18-30VDC Current rating (at 24VDC) 1.1A Temperature range (vertical 0-50°C installation) Weight 3.4 Kg MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice...
-
Page 14: Dimensions
276mm/10.86” 221mm/8.70” 42mm/1.65” 4mm/0.16” eTOP312 337mm/13.26” 267mm/10.51” 326mm/9.30” 256mm/10.1” 42mm/1.65” 4mm/0.16” eTOP313 337mm/13.26” 267mm/10.51” 326mm/9.30” 256mm/10.1” 42mm/1.65” 4mm/0.16” eTOP315 392mm/15.43” 307mm/12.1” 381mm/15” 296mm/11.65” 46mm/1.82” 4mm/0.16” MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 15: Installation Environment
• max surface roughness where the gasket is applied: O120 um Applying the rectangular gasket The gasket should be applied on the rear of the frame. Fig. 4.1 A. Gasket B. Installation cut-out MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 16: Installation Procedure
Place the fixing brackets as shown in figure (Fig. 4.2). Fig. 4.2 CAUTION Screw each fixing screw until the bezel corner gets in contact with the panel MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 17: Connections
5 Connections Fig. 5.1 1. Power 2. Aux Port 3. PLC Port 4. PC/Printer Port 5. Ethernet Port 6. USB Port (Fig. 5.2) Fig. 5.2 MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 18: Serial Port
Description Description SERIAL PORT CHA- CHB- +5V output +5V output CHB+ CHA+ The communication cable must be chosen for the type of device being connected. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 19: Ethernet Port
TX OUT + TX OUT - RX OUT + RX OUT - ON: Valid link has NOT been detected OFF: Valid link has been detected MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 20: Power Supply, Grounding And Shielding
The suggested wiring for the power supply is shown below. Fig. 6.2 All the electronic devices in the control system must be properly grounded. Grounding must be performed according to applicable regulations. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 21: Aux Port
Insert the module pressing simultaneously on the four corners. Do not plug the module and the ETAD adapter when power is applied to the operator panel. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 22: Battery
When the battery is fully charged, it ensures a period of 3 months of data back-up at 25°C. Battery ATTENTION Dispose of batteries according to local regulations. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 23: Cleaning Faceplates
The version of the Designer being used must be compatible with the firmware version of the panel to be programmed. Call for more information on compatibility between firmware and programming software. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 24: Command Summary
Note: The text ‘2 s’ associated to a key means that the key must be held pressed for two seconds to activate the associated function. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 25: Configuration Mode
select down activate selection activate selection ENTER return to Page Mode when EXT is selected CLEAR return to Page Mode MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 26: Special Modes: Calibration, Configuration And Safe Mode
Switch on the operator panel and tap in the bottom part of the display screen with a period of about half a second The panel will remain with black screen and system leds blinking MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 27: Dedicated Led Indicators
Please note that some indicators may be available only in some models of operator panels. You will find a complete reference to programming this product in the UniOP User’s Manual. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice... -
Page 28: Unpacking And Packing Instructions
15 Unpacking and packing instructions To repack the unit, please follow the instructions backwards. MANUGENETOP3xx - Version 2.00 © 2018 EXOR International S.p.A. - Subject to change without notice...
