- Page 1 HA55SF-ST (CE) PNEUMATIC BRAD NAILER OPERATING and MAINTENANCE MANUAL ENGLISH BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE SAFETY WARNING AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE. WARNING...
-
Page 2: Table Of Contents
DEFINITIONS OF SIGNAL WORDS WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. NOTE: Emphasizes essential information. INDEX 1. -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS 2. EAR PROTECTION MAY BE REQUIRED IN SOME ENVIRONMENTS As the working condition may include ex- posure to high noise levels which can lead to hearing damage, the employer and user WARNING should ensure that any necessary hearing TO AVOID SEVERE PERSONAL INJURY OR protection is provided and used by the op- PROPERTY DAMAGE... - Page 4 Thinner Gasoline 9. INSPECT SCREW TIGHTNESS 5. DO NOT OPERATE THE TOOL NEAR A Loose or improperly installed screws or FLAMMABLE SUBSTANCE bolts cause accidents and tool damage when the tool is put into operation. Inspect Never operate the tool near a flammable to confirm that all screws and bolts are tight substance (e.g., thinner, gasoline, etc.).
- Page 5 12. USE SPECIFIED FASTENERS (SEE PAGE 7) The use of fasteners other than specified fasteners will cause the tool malfunction. Be sure to use only specified fasteners when operating the tool. 16. DO NOT DRIVE FASTENERS ON TOP OF OTHER FASTENERS Driving fasteners on the top of other fas- teners may cause deflection fasteners which could cause injury.
- Page 6 • Keep the tool in a dry place out of reach of children when not in use. • Do not use the tool without Safety Warning label. • Do not modify the tool from original design or function without approval by MAX CO., LTD.
-
Page 7: Specifications And Technical Data
Nail Removing Lever (Empty firing prevention lever) Contact Arm Switching Lever Barely pressing Mode Change to conven- tional sequential trip. 2. TOOL SPECIFICATIONS PRODUCT NO. HA55SF-ST (CE) HEIGHT 237 mm (9-1/8") WIDTH 63 mm (2-1/2") LENGTH 258 mm (10-1/8") WEIGHT 1.1 kg (2.4 lbs.) - Page 8 3. BRAD NAIL SPECIFICATIONS .075" 1.9 mm .055" 1.4 mm .051" 1.3 mm .051" 1.3 mm 5/8" 5/8" 7/8" 7/8" 1" 1" 15 mm 15 mm 1-3/16" 1-3/16" 20 mm 20 mm 1-3/8" 1-3/8" 25 mm 25 mm 1-5/8" 1-5/8" 30 mm 30 mm 1-3/4"...
-
Page 9: Air Supply And Connections
3. AIR SUPPLY AND CON- NECTIONS Thinner Gasoline WARNING DO NOT OPERATE THE TOOL NEAR A Read section titled "SAFETY IN- FLAMMABLE SUBSTANCE Never operate the tool near a flammable sub- STRUCTIONS". stance (e.g., thinner, gasoline, etc.). Volatile fumes from these substances could be drawn into the compressor and compressed together with the air and this could result in an explosion. -
Page 10: Instructions For Operation
Disconnect the air supply. nailers. To use the tool, you always need the special air compressor and air hose (MAX PowerLite Compressor and MAX PowerLite Hose). Use of high-pressure gas (for example, oxygen, acetylene, etc.) causes abnormal combustion, possibly resulting in explosion. - Page 11 Nail WARNING Keep hands and body away from the discharge outlet when driving the fasteners because of dangerous of hitting the hands or body by mis- take. NAIL LOADING NOTE: Ensure the point of nail stick to be ridden in the bottom of magazine.
- Page 12 AIR HOSE CONNECTION MODEL IDENTIFICATION SEQUENTIAL TRIP The Sequential Trip requires the operator to Air chuck hold the tool against the work before pulling the trigger. This makes accurate fastener placement Air plug easier, for instance on framing, toe nailing and crating applications.
- Page 13 CONTACT TRIP CONTACT TRIP WITH ANTI-DOUBLE FIRE MECHANISM Identified by BLACK TRIGGER. (US patent 5597106, UK patent 2286790) Identified by RED TRIGGER. DRIVING FASTENERS PRESSING METHOD SELECTING MECHANISM (Contact Arm Switching Mechanism) In this equipment, the contact arm switching lever may be used to change the contact arm position. Contact Arm Contact Arm Tip Nail Driving Method...
- Page 14 SINGLE FIRE OPERATION For single fire operation, depress the contact arm against the work surface and pull the trigger. Tool can not fire a second nail until the trigger is released and tool can cycle. Nail-releasing Lever Contact Arm ∗ This equipment incorporates an empty-firing prevention device so that the contact arm will not move when there is no nail loaded.
- Page 15 Deeper Shallow Refer to the figure for direction to turn the dial. Click Lever Slider Reconnect air supply. While pressing the click lever, pull out the slider. THE CONTACT TIP Adjustment dial Contact Arm A Contact Tip Remove the contact tip that is stored inside the rear part of the slider.
- Page 16 CLEARING JAMMED NAILS Indented Part Hexagonal Bar Contact Arm A Spanner Magazine Pulling on the contact arm A (1), insert it into the indented part of the contact tip (2). WARNING Contact Arm Driver Guide ALWAYS disconnect air supply before clearing jammed fastener.
- Page 17 METHOD OF CHANGING THE HOOK DI- RECTION Mount the driver guide, and securely tighten the screws. It is also possible to mount the hook on the right ∗ In the situation where the driver guide is diffi- hand side of the main unit. cult to mount, remove the screws completely Remove the screw using a hexagonal before mounting the guide.
-
Page 18: Maintenance
ING/REPAIRS plug inlet with the jet oiler. (Recommended Oil : ISO VG32) The troubleshooting and/or repairs shall be carried out only by the MAX CO., LTD. author- INSPECT AND MAINTAIN DAILY OR ised distributors or by other specialists. BEFORE OPERATION... - Page 20 OSTSTRASSE 22, 40211 Camerastraat 19 DÜSSELDORF, GERMANY 1322 BB Almere The Netherlands TEL: +49-211-9365300 Phone: +31-36-546-9699 FAX: +49-211-93653017 FAX: +31-36-536-3985 www.max-ltd.co.jp/int/ (GLOBAL Site) www.max-europe.com (EUROPE Site) 080321-00/00...
