Max SN883CH/34 (CE) Operating And Maintenance Manual

34 degree clipped head framing stick nailer
Hide thumbs Also See for SN883CH/34 (CE):

Advertisement

Quick Links

Download this manual
SN883CH/34
34 DEGREE CLIPPED HEAD FRAMING
STICK NAILER
34-GRAD BEFESTIGTER RAHMEN-
STOCKHAUPTNAGLER
CLOUEUSE À MANCHE D'ENCADREMENT
DE TÊTE COUPÉE À 34 DEGRÉS
INCHIODATRICE A MANICA DI QUADRO
DI TESTA TAGLIATA A 34 GRADI
CLAVADORA DE BARRA DE MARCO
DE CABEZA CORTADA A 34 GRADOS
OPERATING and MAINTENANCE MANUAL
MANUEL D'UTILISATION et D'ENTRETIEN
MANUALE DI FUNZIONAMENTO E MANUTENZIONE
MANUAL DE OPERACIONES Y MANTENIMIENTO
BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE SAFETY WARNING AND
INSTRUCTIONS.
KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE.
WARNING
LESEN SIE VOR INBETRIEBNAHME DES GERÄTES DIE GEBRAUCHS- UND SICHERHEITS-
HINWEISE. BITTE BEWAHREN SIE DIE GEBRAUCHS- UND SICHERHEITSHINWEISE AUF,
DAMIT SIE AUCH SPÄTER EINGESEHEN WERDEN KÖNNEN.
ACHTUNG
AVANT D'UTILISER CET OUTIL, LIRE CE MANUEL ET LES CONSIGNES DE SECURITE
AFIN DE GARANTIR UN FONCTIONNEMENT SUR.
CONSERVER CE MANUEL EN LIEU SUR AVEC L'OUTIL AFIN DE POUVOIR LE
AVERTISSEMENT
CONSULTER ULTERIEUREMENT.
PRIMA DI USARE QUESTA MACCHINA, STUDIARE IL MANUALE PER PRENDERE ATTO
DEGLI AVVERTIMENTI E DELLE ISTRUZIONIPER LA SICUREZZA.
TENERE QUESTE ISTRUZIONI INSIEME ALLO STRUMENTO PER CONSULTAZIONI FUTURE.
ATTENZIONE
PARA EVITAR GRAVES DAÑOS PERSONALES O EN LA PROPIEDAD.
ANTES DE EMPLEAR LA HERRAMIENTA, LEER CON ATENCIÓN Y COMPRENDER LOS
SIGUIENTES INSTRUCCIONES DE SEGURIDAD.
ATENCIÓN
(
CE
BETRIEBSANLEITUNG
)

Advertisement

loading

Related Manuals for Max SN883CH/34 (CE)

Summary of Contents for Max SN883CH/34 (CE)

  • Page 1 SN883CH/34 34 DEGREE CLIPPED HEAD FRAMING STICK NAILER 34-GRAD BEFESTIGTER RAHMEN- STOCKHAUPTNAGLER CLOUEUSE À MANCHE D’ENCADREMENT DE TÊTE COUPÉE À 34 DEGRÉS INCHIODATRICE A MANICA DI QUADRO DI TESTA TAGLIATA A 34 GRADI CLAVADORA DE BARRA DE MARCO DE CABEZA CORTADA A 34 GRADOS OPERATING and MAINTENANCE MANUAL BETRIEBSANLEITUNG MANUEL D’UTILISATION et D’ENTRETIEN...
  • Page 2 INDEX INHALTSVERZEICHNIS INDEX INDICE INDICE ENGLISH Page to 15 Page DEUTSCH Page 17 to 29 Page FRANÇAIS Page 31 to 43 Page ITALIANO Page 45 to 57 Page ESPAÑOL Page 59 to 71 Page DEFINITIONS OF SIGNAL WORDS WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 3 ENGLISH OPERATING and MAINTENANCE MANUAL INDEX 1. SAFETY INSTRUCTIONS …………………………………………… 3 2. SPECIFICATIONS & TECHNICAL DATA ……………………………… 7 3. AIR SUPPLY AND CONNECTIONS …………………………………… 8 4. INSTRUCTIONS FOR OPERATION …………………………………… 10 5. MAINTENANCE ……………………………………………………… 15 6. STORAGE ……………………………………………………………… 15 7. TROUBLESHOOTING/REPAIRS ……………………………………… 15 BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE SAFETY WARNING AND INSTRUCTIONS.
  • Page 4 ENGLISH Thinner Gasoline 2. EAR PROTECTION MAY BE REQUIRED IN 5. DO NOT OPERATE THE TOOL NEAR A SOME ENVIRONMENTS FLAMMABLE SUBSTANCE As the working condition may include Never operate the tool near a flammable exposure to high noise levels which can lead substance (e.g., thinner, gasoline, etc.).
  • Page 5 ENGLISH 12. USE SPECIFIED FASTENERS (SEE PAGE 7) The use of fasteners other than specified fasteners will cause the tool malfunction. Be sure to use only specified fasteners when operating the tool. 9. INSPECT SCREW TIGHTNESS Loose or improperly installed screws or bolts cause accidents and tool damage when the tool is put into operation.
  • Page 6 • Do not modify the tool from original design foot place. or function without approval by MAX CO., Secure the hose at a point close to the area LTD. you are going to drive fasteners. Accidents may be caused due to the hose being pulled inadvertently or getting caught.

  • Page 7: Specifications & Technical Data

    ENGLISH 2. SPECIFICATIONS AND TECHNICAL DATA 1. NAME OF PARTS q Frame y Trigger w Cylinder Cap u Grip e Contact Arm i Exhaust Cover r Nose o Pusher t Magazine !0 Adjustment Dial 2. TOOL SPECIFICATIONS PRODUCT NO. SN883CH/34 (CE) HEIGHT 310 mm (12-1/4”) WIDTH...

  • Page 8: Air Supply And Connections

    ENGLISH TOOL AIR FITTINGS: 3. AIR SUPPLY AND This tool uses a 3/8” N.P.T. male plug. The inside CONNECTIONS diameter should be 9.9mm (.39”) or larger. The fitting must be capable of discharging tool air pressure when disconnected from the air supply. RECOMMENDED OPERATING WARNING...
  • Page 9 HOSES: Hose has a min. ID of 6 mm (1/4”) and possibly causing injury. max. length of no more than 5 meters (17”). The supply hose should contain a fitting that will provide “quick disconnecting” from the male plug on the tool.

  • Page 10: Instructions For Operation

    ENGLISH 4. INSTRUCTIONS FOR OPERATION Read section titled “SAFETY INSTRUCTIONS”. WARNING 1. BEFORE OPERATION Check the following prior operation. Keep hands and body away from the discharge q Wear Safety Glasses or Goggles. outlet when driving the fasteners because of w Do not connect the air supply.
  • Page 11 ENGLISH MODEL IDENTIFICATION CONTACT TRIP MODEL with ANTI-DOUBLE Pusher FIRE MECHANISM The anti-double fire mechanism (US patent 5597106, UK patent 2286790) is installed on this tool. The common operating procedure on “Contact Trip” tools is for the operator to contact the work to actuate the trip mechanism while keeping the trigger pulled, thus driving a fastener each time the work is contacted.
  • Page 12 ENGLISH DRIVING FASTENERS SEQUENTIAL TRIP The Sequential Trip requires the operator to hold CONTACT FIRE OPERATION the tool against the work before pulling the trigger. For contact fire operation, hold the Trigger and This makes accurate fastener placement easier, depress the Contact Arm against the work for instance on framing, toe nailing and crating surface.
  • Page 13 ENGLISH ADJUSTABLE DIAL DEPTH CONTROL CONTACT TIP (OPTION) Adjustment Dial Deeper Shallow Contact Arm Contact Tip WARNING WARNING ALWAYS disconnect air supply before dial ALWAYS disconnect air supply before adjustment. attaching / detaching the contact tip. q With air pressure set, drive nails into a Attach the Contact Tip on the tip of Contact Arm, representative material sample to determine if when driving nails to a soft material.
  • Page 14 ENGLISH REMOVING JAMMED NAILS Nail Stopper w Push the Nail Stopper, and remove the strip nails from inside of the Magazine. WARNING ALWAYS disconnect air supply before removing jammed nails. Pusher Lever Hole Pusher e Pull and stayed the Pusher back using the PROCEDURE q Push the Pusher Lever and release the strip hole and a rod.

  • Page 15: Maintenance

    The troubleshooting and/or repairs shall be performance. The hose length between airset carried out only by the MAX CO., LTD. authorised and tool should be no longer than 5 m since a distributors or by other specialists.
  • Page 16 SN883CH/34 PNEUMATIC STAPLER ESPLOSO DEI EXPLODED EINZELTEILDAR- SCHEMA ECLATE ET DESPIECE DE LA COMPONENTI DE VIEW AND SPARE STELLUNG UND LISTE DES PIECES MAQUINA Y LISTA ELENCO DELLE PARTS LIST ERSATZEILLISTE DE RECHANGE DE RECAMBIOS PARTI DI RICAMBIO O-RING KIT Parts marked included the O-ring kit...
  • Page 17 SN883CH/34 ITEM PART MATERIAL ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL BB40406 Steel SCREW 5X12 SCHRAUBE 5X12 VIS 5X12 VITE 5X12 TORNILLO 5X12 KN12187 Stainless steel EXHAUST FILTER AUSLASSFILTER FILTRE ECHAPPEMENT FILTRO DI SCARICA FILTRO DE ESCAPE KN12194 Steel EXHAUST COVER ABSAUGHAUBE CAPOT D'ASPIRATION COPERCHIO DELLO SCARIO CAMPANA DE ASPIRACIÓN BB40429...
  • Page 18 SN883CH/34 ITEM PART MATERIAL ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL KN12216 Rubber MAGAZINE GUIDE A MAGAZINFÜHRER A GUIDE DE MAGASIN A GUIDA CARICATORE A GUÍA DE CARGADOR A KK23964 Stainless steel COMPRESSION SPRING 3964 DRUCKFEDER 3964 RESSORT Á PRESSION 3964 MOLLA DI COMPRESSIONE 3964 MUELLE DE COMPRESIÓN 3964 KN12222 Steel CONTACT BOLT...
  • Page 19 OSTSTRASSE 22, 40211 Camerastraat 19 DÜSSELDORF, GERMANY 1322 BB Almere The Netherlands TEL: +49-211-9365300 Phone: +31-36-546-9699 FAX: +49-211-93653017 FAX: +31-36-536-3985 www.max-ltd.co.jp/int/ (GLOBAL Site) www.max-europe.com (EUROPE Site) ★ 080321-00/00 PRINTED IN JAPAN GEDRUCKT IN JAPAN IMPRIMÉ AU JAPON STAMPATO IN GIAPPONE...
