Xycom XVME-240 User Manual page 9

XVME-240 Manual
October, 1984
Characteristic
Number of I/O Channels
Number of Flag Output Lines
Number of Interrupt Input Lines
Output Characteristics -
Flag Outputs:
Vol Low-level output voltage
1o1 = 24mA
1o1 = 12 mA
Low-level
Iol
Voh High-level output voltage
Ioh High-level output current
Voh = 2.4V
Ioh = 2.OV
Channel Outputs:
Vol Low-level output voltage
Io1 = 48mA
Io1 = 16 mA
Iol Low-level
Voh High-level output voltage
Ioh High-level output current
Voh = 2.4V
Ioh = 2.OV
Slave Data Transfer Options -
A16: D16 (STAT)
A24 : D16 (STAT)
Interrupter Options -
Any one of 1(1)-I(7) (STAT)
Power Requirements -
All channels configured as inputs
All channels - high outputs
(max. load)
All channels - low outputs
Table l-l. DIO Module Specifications
output current
output current
Specification
~~~
64 (arranged in 8 logical ports)
8
8
0.5V max.
0.4V max.
24 mA max.
2.4V min.
mA max.
-3
-15 mA max.
0.5V max.
0.4V max.
48 mA max.
2.4V min.
-3 mA max.
-15 mA max.
+5V Typ. 2.7A
3.4A
Max.
+5V Typ. 3.6A
Max. 4.2A
+5V Typo 27
Max. 3.4A
l-4
