Check Point 13000 Installation

Appliance replacing

Hide thumbs Also See for 13000:

13000 Appliance Replacing Hard

Disk Drives

705939

Protected

2014

Important - Make sure that you are electromagnetically grounded when

performing the following procedures. ESD (electrostatic discharge) can

damage the appliance.

For a list of our Third Party Copyright notices, please refer to:

Classification [Protected]

For a list of our trademarks, please refer to: http://www.checkpoint.com/copyright.html.

http://www.checkpoint.com/3rd_party_copyright.html

P/N:705939

Table of Contents

Need help?

Do you have a question about the 13000 and is the answer not in the manual?

Page 1 ESD (electrostatic discharge) can damage the appliance. Classification [Protected] P/N:705939 © 2014 Check Point Software Technologies Ltd. All rights reserved. For a list of our trademarks, please refer to: http://www.checkpoint.com/copyright.html. For a list of our Third Party Copyright notices, please refer to: http://www.checkpoint.com/3rd_party_copyright.html...
Page 2 Removing a Hard Disk Drive Item Description Ejector handle Hard drive casing To remove a hard disk drive: On the hard disk drive, push left on the ejector handle to unlock the drive. Important - Do not use the ejector handle to remove the hard disk drive from the appliance.
Page 3 Installing a Hard Disk Drive Insert the replacement hard disk drive into the appliance. To install a hard disk drive: Hold the hard drive casing and insert the replacement hard disk drive into the slot. Push the extraction handle to close it. The hard disk drive clicks into position.
Page 4 To monitor the RAID status of the hard disks using SNMP: Set up SNMP traps to send information about the RAID. Use OID: 1.3.6.1.4.1.2620.1.6.7.7 For more about configuring the SNMP settings on the appliance, see the Gaia or SecurePlatform Administration Guide for the applicable version. To hot swap a hard disk drive: Important - Make sure that there is at least one fully synchronized hard disk in the system.
