- Page 1 Model No. DC5371 Owner's Manual Wall Mount Dust Collector Visit us on the web at www.powertecproducts.com You will need this manual for safety instructions, operating procedures, and warranty. 22-1230...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT SPECIFICATIONS SECTION PAGE Motor . . . . . . . . . . . . . . . . . . . . . 1-HP, 120/240 V, 60-Hz, 1PH Motor Speed . -
Page 3: Safety Rules / Warnings
SAFETY RULES TOOL MAINTENANCE WARNING • Always unplug tool prior to inspection. For your own safety, read and understand all warnings and operating instructions before using any tool or equipment. • Consult manual for specific maintaining and adjusting procedures. WARNING • Keep tool lubricated and clean for a safe operation. Some dust created by power sanding, sawing, grinding, drilling •... - Page 4 IMPORTANT SAFETY WARNINGS GROUNDING INSTRUCTIONS NOTE: When using an electrical appliance, basic precautions should always be followed, including the following: This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance READ ALL INSTRUCTIONS for electric current to reduce the risk of electric shock.
-
Page 5: Assembly
SPECIFIC SAFETY INSTRUCTIONS • Turn machine off, disconnect power cord and ensure all WARNING moving parts have stopped completely before changing or Read and understand the instruction manual before operating the dust collector. Basic precautions listed below should always • be followed when using your dust collector to reduce the risk of •... -
Page 6: Test
Figure 2 • If mounting on a masonry wall use lag screws with lag Wall-mounted Bracket For Motor • If mounting to a framed wall attach the mounting bracket to a support board. Attach the support board with lag 5. Place the adhesive foam strip (supplied) around the dust Adhesive Foam Strip 6. -
Page 7: Grounding Instructions
GROUNDING INSTRUCTIONS MOTOR The dust collector is assembled with motor and wiring installed. WARNING Improper connection of equipment grounding conductor can The permanently split capacitor motor has the following result in the risk of electrical shock. Equipment should be grounded while in use to protect operator from electrical shock. Horsepower (Peak HP) . -
Page 8: Operation
TO CONVERT 3. Follow the 240V wiring diagram on the inside of the switch 5. Replace the plug on the existing power cord with a NEMA box cover. NOTE: The 240V wiring diagram is also in 6-15 plug. The plug must be plugged into matching outlet 847-780-6120 for that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 9: Maintenance
MAINTENANCE GENERAL MAINTENANCE LUBRICATION The sealed bearings in the motor have been permanently WARNING lubricated at the factory. They require no further lubrication. Make sure the machine is turned off and the cord is MACHINE STORAGE disconnected from the power source before servicing and removing/replacing any components on the machine. -
Page 10: Parts Illustration & List
FENCE ASSEMBLY WALL MOUNT DUST COLLECTOR PARTS ILLUSTRATION WALL MOUNT DUST COLLECTOR PARTS LIST Part No Description DC5371001 Main housing DC5371002 Inlet cover 4" DC5371003 Motor plate DC5371004 Wall mount bracket DC5371005 Impeller 10" DC5371006 DC5371007 DC5371008 Spring washer M6 DC5371009 Flat washer Ø1/4"... -
Page 11: Warranty
30- DAY SATISFACTION GUARANTEE POLICY During the first 30 days after the date of purchase, if you are dissatisfied with the performance of this POWERTEC tool for any reason, you may return the tool to the retailer from which it was purchased for a full refund or exchange. You must present proof of purchase and return all original equipment packaged with the original product. - Page 12 Southern Technologies, LLC Chicago, IL 60606...
