Summary of Contents for Chauvet Professional OMINE10WWZ
- Page 1 User Manual...
- Page 2 Edition Notes The OVATION Min-E-10WW User Manual Rev. 7 covers the description, safety precautions, Edition installation, programming, operation, and maintenance of the OVATION Min-E-10WW. Chauvet Notes released this edition of the OVATION Min-E-10WW User Manual in 2017. CHAUVET is a registered trademark of CHAUVET & Sons, LLC. (d/b/a CHAUVET or Chauvet). Trademarks The CHAUVET logo in its entirety including the Chauvet name and the dotted triangle, and all other trademarks in this manual pertaining to services, products, or marketing statements are...
-
Page 3: Table Of Contents
Table of Contents Table of Contents 1. Before You Begin ............................1 What Is Included ................................1 Claims ......................................1 Manual Conventions ..................................1 Symbols ....................................... 1 Safety Notes ................................. 2 Personal Safety .................................... 2 Mounting And Rigging .................................. 2 Power And Wiring .................................. -
Page 5: Before You Begin
Before You Begin 1. B EFORE EGIN · · OVATION Min-E-10WW Gel frame (2.75 in/70 mm accessories) What Is · · Gobo holder size: 37.5 mm (outside), Warranty Card Included · 20 mm (image, glass), 25 mm (image, steel), Quick Reference Guide 1 mm (max. -
Page 6: Safety Notes
Before You Begin Read all the following Safety Notes before working with this product. These notes include Safety Notes important information about the installation, usage, and maintenance of this product. This product contains no user-serviceable parts. Any reference to servicing in this User Manual will only apply to properly trained Chauvet certified technicians. -
Page 7: Introduction
Introduction 2. I NTRODUCTION The OVATION Min-E-10WW is a compact warm white LED ellipsoidal product. The OVATION Description Min-E-10WW features standard beam shaping shutters, a gobo/effect slot, lens barrels that are interchangeable, and the capability to run on standard theater dimmers as well as 0–10 VDC dimmers. -
Page 8: Dimensions
Introduction Dimensions 5.12 in 130 mm 11.42 in 290 mm 9.76 in 248 mm 8.9 in 225 mm OVATION Min-E-10WW User Manual Rev. 7... -
Page 9: Setup
Setup 3. S ETUP Each OVATION Min-E-10WW has a fixed power supply that works with an input voltage of AC Power either 120 VAC, 60 Hz, or 230 VAC, 50 Hz. To determine the power requirements for each OVATION Min-E-10WW, refer to the label affixed to the product. You can also refer to the Technical Specifications chart in this manual. -
Page 10: Mounting
Setup Before mounting this product, read and follow the Safety Notes. For our CHAUVET® Mounting Professional line of mounting clamps, go to http://trusst.com/products/. Orientation Always mount this product in a safe position and make sure there is adequate room for ventilation, configuration, and maintenance. -
Page 11: Operation
Operation 4. O PERATION Rotating the The OVATION Min-E-10WW allows manual rotation of the barrel assembly, as follows. 1. Locate the barrel rotation knobs at the top and bottom of the reflector housing. Barrel Assembly 2. Loosen the knobs by turning them counter-clockwise. ·... -
Page 12: Technical Information
Technical Information 5. T ECHNICAL NFORMATION To maintain optimum performance and minimize wear, you should clean this product frequently. Product Usage and environment are contributing factors in determining the cleaning frequency. Maintenance As a rule, clean this product at least twice a month. Dust build-up reduces light output performance and can cause overheating. -
Page 13: Technical Specifications
Technical Specifications 6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 13.4 in (225 mm) 5.12 in (108 mm) 5.24 in (232 mm) 3.0 lb (1.4 kg) (product only) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range... -
Page 14: Photometrics Chart
User Manual Photometrics Chart OVATION Min-E-10WW User Manual Rev. 7... -
Page 15: Returns
Technical Specifications Send the product prepaid, in the original box, and with the original packing and accessories. Returns Chauvet will not issue call tags. Call Chauvet and request a Return Merchandise Authorization (RMA) number before shipping the product. Be prepared to provide the model number, serial number, and a brief description of the cause(s) for the return.
