1. Product Overview

1.1 Product Introduction

The ICR-4401 is a LAN Router & Powerful Edge Computing Gateway focused on the
global market.
This router is an ideal solution for demanding IoT applications such as industrial routers
and gateways, digital signage, industrial computers, and tablets, etc.
The router, assembled in a robust metal box, is equipped with five 1Gb Ethernet ports,
one SFP cage together with interfaces of RS232, RS485, CAN bus, two binary inputs and
two binary outputs. A microSD card can be inserted under this cover as well. The desig-
nated router models can be equipped with a WiFi module with 3x3 MIMO antennas.
Configuration of the router may be done via a password-protected Web interface. Web
interface provides detailed statistics about the router's activities, signal strength, detailed sys-
tem log etc. The router supports VPN tunnels using IPSec (), OpenVPN, GRE, L2TP or PPTP
to make sure safe communication. IPv6 Dual Stack, DHCP, NAT, NAT-T, DynDNS, DNS
proxy, VLAN, QoS, NTP, VRRP, port forwarding, primary connection backup and many other
functions are supported.
The router supports the Low Power Mode and hardware watchdog, which monitors the
router status and performs an automatic restart if required.
The user may insert Linux scripts which are started on various actions. It is possible to
create up to four different configurations for the same router. These configurations can be
switched when necessary via Web interface or binary input status.
The router can automatically upgrade its configuration and firmware from your central
server. WebAccess/DMP
supported as well.
Examples of possible applications
• mobile office
• security system
• remote monitoring
• vending and dispatcher machines
and WebAccess/VPN remote device management platforms are
