- Page 1 PCAN-miniPCIe FD User Manual User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
-
Page 2: Imprint
Single Channel model has an identical form factor like the Double Channel model but varies in equipment. Imprint PCAN is a registered trademark of PEAK-System Technik GmbH. CiA® is a registered community trade mark of CAN in Automation e.V. All other product names in this document may be the trademarks or registered trademarks of their respective companies. -
Page 3: Table Of Contents
5 API PCAN-Basic 5.1 Features of PCAN-Basic 5.2 Principle Description of the API 6 Technical Data Appendix A CE Certificate Appendix B Dimension Drawings Appendix C Quick Reference Appendix D Linux Contents PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 4: Introduction
Device drivers and application information for Linux: www.peak-system.com/quick/DL-Driver-E At the end of this manual you can find a Quick Reference with brief information about the installation and operation of the CAN interface. 1 Introduction PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 5: Properties At A Glance
Extended operating temperature range from -40 to +85 °C (-40 to +185 °F) ■ 1.2 System Requirements Computer with: Operating system Windows® 11 (64 bit), 10 (32/64 bit) or Linux (32/64-bit) ■ PCI Express Mini slot with PCIe lane ■ 1 Introduction PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 6: Scope Of Supply
Device drivers for Windows® 11 (64 bit), 10 (32/64 bit) and Linux (32/64-bit) ■ CAN monitor PCAN-View for Windows ■ Programming interface PCAN-Basic for developing applications with CAN ■ connection Programming interfaces for standardized protocols from the automotive sector ■ 1 Introduction PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 7: Installation
Install the driver before you install the CAN interface. 2.1 Install Device Driver Setup 1. Download the device driver setup from our website: www.peak-system.com/quick/DL-Driver-E 2. Unpack the file PEAK-System_Driver-Setup.zip 3. Double-click the file PeakOemDrv.exe The driver setup starts. 4. Follow the program instructions. -
Page 8: Check Operational Readiness
Windows detects the new hardware and completes the driver installation. 2.3 Check Operational Readiness 1. Open the Windows Start menu. 2. Type Peak Settings and press |Enter|. The window PEAK Settings appears. 3. Select CAN Hardware. The connected CAN interface is displayed. -
Page 9: Connecting The Can Bus
FD-optimized connection to an existing CAN bus. This makes interference-free operation possible at higher CAN FD bit rates, because stubs and Y distributions are avoided as far as possible. 3 Connecting the CAN Bus PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... - Page 10 4, 5, 9 None Note: The activation of the daisy chain is optional. The manual is available on request from our customer support. Please contact support@peak-system.com. 3 Connecting the CAN Bus PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
-
Page 11: Internal Termination
The termination prevents interfering signal reflections and ensures the proper operation of the transceivers of the connected CAN nodes (CAN interfaces, control devices). 3.4.2 Example of a Connection 3 Connecting the CAN Bus PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 12: Example Application Under Windows
3.5 Example Application under Windows As an example application for accessing the CAN interface, run the CAN monitor PCAN-View from the Windows Start menu. 3 Connecting the CAN Bus PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 13: Can Monitor Pcan-View
In the following the initialization of a CAN interface is described as an example. Detailed information about using PCAN-View can be found in the program window under the menu item Help. 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 14: Can Interface Initialize
2. If there are several CAN interfaces, select the desired interface. For multiple channels, select the desired channel from the list. 3. Enter the bit rate(s) and other settings according to the connected CAN bus. 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... - Page 15 4. Confirm the entries with OK. The main window appears and displays the Receive / Transmit tab. 5. For initializing another channel or CAN interface, open another instance of PCAN- View. 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
-
Page 16: Transmit Can Message
4. To send the message manually, select the menu command Transmit > Send or press the |space| bar. The manual transmission process is performed additionally for periodically transmitted CAN messages. 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 17: Additional Tabs
4.3.1 Trace Tab The tracer (data logger) records the communication of the CAN bus in linear or ring buffer mode. The trace data can be saved to a file. 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... - Page 18 4.3.2 CAN interface Tab The CAN interface tab shows information about the hardware and the used Windows device driver. In this case exemplary for the PCAN-miniPCIe FD. Depending on the CAN interface, a hardware ID can be determined to distinguish several interfaces of the same type.
- Page 19 4.3.3 Bus Load Tab The Bus Load tab displays the current bus load, its time history and statistical information of the connected CAN channel. 4.3.4 Error Generator Tab 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
- Page 20 You can destroy CAN frames with the error generator by one of two methods: once after activation ■ repeatedly at specific intervals related to a CAN ID ■ 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
- Page 21 4. Determine the Number of Frames to destroy. 5. Confirm the entries with Apply to activate the error generator. 6. Stop destroying further CAN frames with Disable. 4 CAN Monitor PCAN-View PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
-
Page 22: Api Pcan-Basic
The programming interface (API) PCAN-Basic provides basic functions for the connection of own programs to the CAN interface of PEAK-System. PCAN-Basic is the interface between the program and the device driver. In Windows operating systems this is a DLL (Dynamic Link Library) and in Linux operating systems an SO (Dynamic Shared Object). -
Page 23: Features Of Pcan-Basic
Windows® 11 (64 bit), 10 (32/64 bit) ■ Linux (32/64-bit) ■ Multiple PEAK-System applications and your own can be operated on a physical ■ channel at the same time Single DLL (Win) / SO (Linux) for all supported hardware types ■... -
Page 24: Principle Description Of The Api
To end the communication the function CAN_Uninitialize is called in order to release the reserved resources for the CAN channel, among others. In addition the CAN channel is marked as "Free" and is available to other applications. 5 API PCAN-Basic PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 25: Technical Data
Time stamp resolution 1 µs Galvanic isolation up to 300 V, separate for each CAN connector Not activated at delivery. Internal termination Soldering manual on request: support@peak-system.com Not activated at delivery. Daisy Chain Soldering manual on request: support@peak-system.com Power supply Single Channel 350 mA Max. - Page 26 Relative humidity 15 to 90 %, not condensing Conformity Directive 2011/65/EU (RoHS 2) + 2015/863/EU RoHS DIN EN IEC 63000:2019-05;VDE 0042-12:2019-05 Directive 2014/30/EU EN 55024:2016-05;VDE 0878-24:2016-05 EN 55032:2016-02;VDE 0878-32:2016-02 6 Technical Data PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
-
Page 27: Appendix A Ce Certificate
Appendix A CE Certificate Appendix A CE Certificate PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... -
Page 28: Appendix B Dimension Drawings
Appendix B Dimension Drawings Dimensions in mm of PCAN-miniPCIe FD Single Channel and Double Channel. Appendix B Dimension Drawings PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH... - Page 29 Dimensions in mm of PCAN-miniPCIe FD Quad Channel. Appendix B Dimension Drawings PCAN-miniPCIe FD User Manual 2.0.1 © 2022 PEAK-System Technik GmbH...
-
Page 30: Appendix C Quick Reference
Mini slot (using PCIe lane). The new hardware is detected at the next Windows start and the driver is initialized. Check the operational readiness. Open the Windows Start menu. Type Peak Settings and press |Enter|. The window PEAK settings appears. The connected CAN interface is displayed under CAN Hardware. -
Page 31: Appendix D Linux
Appendix D Linux Depending on the Kernel version, device drivers for the CAN interfaces from PEAK- System are already included in the operating system. The CAN interfaces are treated as network devices (SocketCAN, netdev). You can find the documentation for SocketCAN under: https://www.kernel.org/doc/Documentation/networking/can.txt...
