FAQ GMS-scai How to Connect Serial Console with uCon

1. Introduction

This procedure describes how to connect the serial console of a GMS-scai to a computer.

Micro USB cable (Type-A plug to Micro-B plug)

Windows Computer with installed terminal software, recommended is uCon (http://www.umonfw.com/ucon/)

Any other serial port terminal software may work as well

Connect the Micro USB cable to the USB connetor of your GMS-scai

Table of Contents

Do you have a question about the GMS-scai and is the answer not in the manual?

Page 1 FAQ GMS-scai How to Connect Serial Console with uCon 1. Introduction This procedure describes how to connect the serial console of a GMS-scai to a computer. 2. Required Tools Micro USB cable (Type-A plug to Micro-B plug) Windows Computer with installed terminal software, recommended is uCon (http://www.umonfw.com/ucon/) Any other serial port terminal software may work as well 3.
Page 2 4. Find COM port in Windows Turn on your GMS-scai In Windows under Device Manager-> Ports (COM & LPT), your GMS-scai appears as USB Serial Port Remember the COM port of the USB Serial Port 5. Connect with uCon Start uCon terminal software Choose the COM port of your USB Serial Port Choose baud rate 115.2K from the dropdown...
Page 3 6. Navigating the console If the startup process of the instrument is finished, you can press [ENTER] key on your keyboard The main menu will appear Each menu point has a letter assigned Press the key of the menu you want to select (e.g. [C] to enter the configuration menu, press [C] again to edit current configuration) Always confirm your selection pressing [ENTER] At the bottom of each sub-menu, further navigation options are listed 7.
