Use the MikroTik smartphone app to configure your router in the field, or to apply the most basic initial settings for your MikroTik home access point.
1. Scan QR code and choose your preferred OS.
2. Install and open application.
3. By default, the IP address and user name will be already entered.
4. Click Connect to establish a connection to your device through a wireless network.
5. Choose Quick setup and application will guide you through all basic configuration settings in a couple of easy steps.
6. An advanced menu is available to fully configure all necessary settings.
Powering
The device accepts power in the following ways:
USB type C accepts 5 V DC.
The power consumption under maximum load can reach 8 W.
Configuration
Once logged in, we recommend clicking the "Check for updates" button in the QuickSet menu, as updating your RouterOS software to the latest version
ensures the best performance and stability. For wireless models, please make sure you have selected the country where the device will be used, to
conform with local regulations.
RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to
the possibilities: https://mt.lv/help
of the device from the LAN side (all access is blocked from the Internet port by default).
For recovery purposes, it is possible to boot the device for reinstallation, see section
Mounting
The device is designed to be used indoors and placed on a flat surface with all needed cables connecting to the front of the unit.
The IP rating scale of this device is IPX0. We recommend using Cat6 shielded cables.
Warning! This equipment should be installed and operated with a minimum distance of 20 cm between the device and your body. Operation of this
equipment in the residential environment could cause radio interference.

Expansion slots and ports

Product code L41G-2axD
CPU Dual-Core IPQ-5010 1 GHz
CPU architecture ARM 64bit (RouterOS 32bit)
Size of RAM 256 MB
Storage 128 MB, NAND
Number of 1G Ethernet ports 4
Switch chip model MT7531BE
Wireless band 2.4 GHz
Wireless interface model IPQ-5010
Wireless 802.11b/g/n/ax dual-chain
Wireless antenna max gain 4.3 dBi
Dimensions 124 x 100 x 54 mm
Operating system RouterOS v7, License level 4
Operating temperature -40°C to +70°C
. In case IP connection is not available, the Winbox tool ( https://mt.lv/winbox ) can be used to connect to the MAC address
Buttons and Jumpers .
