Using your gas cooktop
Details how to use the cooktop of your Four-Function cooker.
1. Auxiliary burner
2. Semi-rapid burner
3. Triple-ring wok burner
Auxiliary burner Semi-rapid burner Triple-ring wok burner
Gas burners
The knob controls the flow of gas through the safety valve.
0
•
= closed valve (OFF)
•
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX...
Fig. 24 Cooktop layout
Updated: Wed, 12 Apr 2023 09:14:24 GMT
Powered by
1
Advertisement
Related Manuals for Fisher & Paykel OR60SDBGFX2
Summary of Contents for Fisher & Paykel OR60SDBGFX2
- Page 1 3. Triple-ring wok burner Auxiliary burner Semi-rapid burner Triple-ring wok burner Gas burners The knob controls the flow of gas through the safety valve. • = closed valve (OFF) • https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:14:24 GMT Powered by...
- Page 2 • Read this user guide, taking special note of the ‘Safety and warnings’ section. • Turn the power to the cooker on at the wall. • Make sure all controls are turned off. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:14:24 GMT Powered by...
- Page 3 • The ignitors are sparking. If the ignitors are not sparking, they may be dirty or wet. Clean them with a toothbrush and methylated spirits, as shown in Fig. 26. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:14:24 GMT Powered by...
-
Page 4: If The Flame Is Irregular
Minimum Maximum Auxiliary 12 cm (6 cm with small pan support) 14 cm Semi-rapid 16 cm 24 cm 26 cm 28 cm Triple-ring wok Maximum diameter for woks 36 cm https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:14:24 GMT Powered by... - Page 5 This pan support is to be placed on top of the auxiliary burner when using small diameter pans, in order to prevent them from tipping over. Fig. 28a Small pan support Wok stand The wok stand fits over the triple-ring wok burner trivet. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:14:24 GMT Powered by...
- Page 6 • The wok stand MUST BE PLACED ONLY over the trivet for the triple-ring wok burner. • The cooktop becomes very hot during operation. Keep children well out of reach. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:14:24 GMT Powered by...
