- Page 1 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 1 / 8 Record page Revise Revised Version Revised summary description person Date 刘晨风 Initialversion 2019-9-12 Approval： Approve by： Issue：刘晨风 Date： Date： Date：2019/9/12...
- Page 2 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 1 / 8 USB 2.0 Extender (100M) VER 1.0 ...
- Page 3 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 2 / 8 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect andextend the life of your equipment. Table of Contents 1. Introduction ....................... 3 2. Features ...................... 3 3. Package Contents .................... 4 4. Specifications ..................... 4 5. Operation Controls and Functions .............. 5 5.1 Front Panel .................... 5 5.2 Rear Panel .................... 6 ...
- Page 4 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 3 / 8 1. Introduction The USB 2.0 Extender can extend USB signal up to 100 meters / 328ft via Cat 5e/6 cable. In transmitter, the USB‐B port is connected a PC. In receiver, you can connect a device with USB port at the two USB ports such as U disk or printer, etc. Transmitter and Receiver support PoC (Power over Cable) function. The product can be widely used long distance signal transmission between a PC and USB device. Simple plug and play, no drive and setting installation required. 2. Features ☆ Supports USB 2.0 protocol, transmission rate up to 480Mbps ☆ Supports extend distance up to 100 meters / 328ft via CAT 5e/6 cable ☆ Supports one USB‐B port input in transmitter ☆ Supports two USB 2.0 ports output in receiver ☆ Supports PoC function, it means that either transmitter or receiver is ...
- Page 5 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 4 / 8 3. Package Contents ① 1× USB 2.0 Extender (Transmitter) ② 1× USB 2.0 Extender (Receiver) ③ 1× USB cable (USB‐B male head to USB‐A male head, one meter ) ④ 1× 12V/1A Locking Power Adapter ⑤ 1× User Manual 4. Specifications Technical USB protocol USB 2.0 Transmission rate Up to 480Mbps Transmission distance ...
- Page 6 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 5 / 8 Power Consumption Transmitter: 1.3W, Receiver: 2.3W Operating 0°C ~ 40°C / 32°F ~ 104°F Temperature Storage Temperature ‐20°C ~ 60°C / ‐4°F ~ 140°F Relative Humidity 20~90% RH (non‐condensing) 5. Operation Controls and Functions 5.1 Front Panel Number Name Function description 1 USB port Use USB‐B male head to USB‐A male head wire to connect USB port of a PC. ...
- Page 7 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 6 / 8 5.2 Rear Panel Number Name Function description 1 USB 2.0 port Connect to a device with USB port such as printer or U disk, etc. 2 POWER LED Power LED indicator. The green LED will illuminate when the receiver is connected power supply. 3 DC 12V Plug 12V/1A DC power supply into the unit and connect the adapter to an AC outlet. 4 CAT port The CAT port is connected transmitter’s CAT port by CAT 5e/6 cable. ...
- Page 8 File No. RD-I-19-020 Version Effective Date 2019-9-12 HDC-EU2100 User Manual Page 7 / 8 6. Connection diagram ...
