HDCVT TECHNOLOGY HDV-BE50 User Manual

Hdmi2.0 extender over single cat6 with ir control
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
File No.
RD-I-18-005
Version
1.0
Effective Date
2018-11-16
HDV-BE50 User Manual
Page
1 / 16
Record page
Revise
Revised
Version
No.
Revised summary description
person
Date
刘晨风 2018-11-16
1
Initial version
1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDV-BE50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HDCVT TECHNOLOGY HDV-BE50

Summary of Contents for HDCVT TECHNOLOGY HDV-BE50

  • Page 1 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 1 / 16 Record page Revise Revised Version Revised summary description person Date 刘晨风 2018-11-16 Initial version...
  • Page 2 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 2 / 16 Approval： Approve by： Issue：刘晨风 Date： Date： Date：2018/11/16...
  • Page 3 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 3 / 16 HDMI2.0 Extender over Single CAT6 with IR Control...
  • Page 4 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 4 / 16 VER 1.0 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.

  • Page 5: Table Of Contents

    File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 5 / 16 life of your equipment. Table of Contents 1. Introduction ....................... 5 2. Features ......................7 3. Package Contents ....................8 4. Specifications ..................... 8 5. Operation Controls and Functions ..............10 5.1 Transmitter Panel ..................
  • Page 6 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 6 / 16 signals and one-way IR, at a distance of up to 164ft/50m over a single Cat6 cable. With only one cost effective Cat6 cable, high definition sources with HDMI outputs can be connected to high definition displays with HDMI inputs over long distances.

  • Page 7: Features

    File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 7 / 16 perfect solution for any application. 2. Features ☆ HDMI 2.0, HDCP 2.2/HDCP 1.4 and DVI 1.0 compliant ☆ Supports 18Gbps bandwidth ☆ Supports input and output video resolutions the maximum up to 4k2k@60Hz RGB/Ycbcr 4:4:4/Ycbcr 4:2:2, extends distance the furthest up to 164ft/50m ☆...

  • Page 8: Package Contents

    File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 8 / 16 ☆ Compact design for easy and flexible installation. 3. Package Contents ① 1× HDMI2.0 Extender Transmitter ② 1× HDMI2.0 Extender Receiver ③ 1× Wideband IR Blaster cable ④...
  • Page 9 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 9 / 16 HDCP Compliance HDCP 2.2/HDCP 1.4 Video Bandwidth 18Gbps Video Resolution Up to 4K60Hz 4:4:4 Color Space RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0 Color Depth 8/10/12-bit HDMI Audio Formats...

  • Page 10: Operation Controls And Functions

    File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 10 / 16 Mechanical Housing Metal Enclosure Silkscreen Color Black Dimensions 101.5mm [W] x 69.3mm [D] x 13.3mm [H] Weight Transmitter: 150g, Receiver: 144g Power Supply Input: AC100 - 240V 50/60Hz, Output: DC 12V/1A...
  • Page 11 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 11 / 16 Number Name Function description SERVICE port For firmware updated use. ▪ When in “TX” position, the unit will copy the EDID COPY TX / RX setting of the HDMI loop output display device to source device.

  • Page 12: Receiver Panel

    File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 12 / 16 HDMI IN HDMI input port, connect to HDMI source device such as DVD or PS4 player with an HDMI cable. HDMI OUT HDMI loop output port, connect to HDMI display device such as TV or Projector with an HDMI cable.
  • Page 13 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 13 / 16 Lamp Connection signal The lamp will illuminate when the transmitter and Indicator Lamp the receiver have signal transmission. HDMI OUT HDMI output port, connect to HDMI display device...

  • Page 14: Ir Pin Definition

    File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 14 / 16 5.3 IR Pin Definition IR Receiver and Blaster pin’s definition as below:...

  • Page 15: Application Example

    File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 15 / 16 6. Application Example...
  • Page 16 File No. RD-I-18-005 Version Effective Date 2018-11-16 HDV-BE50 User Manual Page 16 / 16...
