- Page 1 HDMI/USB KVM Extender Over Cat5e/6 VER:1.1...
- Page 2 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
4. Specifications ....................4 5. Operation Controls and Functions ............6 5.1 Transmitter Panel ..................6 5.2 Receiver Panel ................... 7 6. Connection Diagram ................. 1. Introduction The HDMI/USB KVM Extender can extend high definition HDMI and USB signals up to 164ft/50m over a single Cat5e/6 cable with zero latency. It supports HDMI 1.4b and USB 2.0 standards. - Page 4 2. Features HDMI 1.4b, HDCP 1.4 and DVI compliant Video resolutions up to 1080p@60Hz HDMI audio pass through Zero latency and uncompressed transmission technology USB 2.0 Full-speed transmission and routing 12V POC (Power over Cable) function supported 3.
-
Page 5: Specifications
4. Specifications Technical HDMI 1.4b HDMI Compliance HDCP 1.4 HDCP Compliance USB 2.0 USB Compliance 720x576p50,720x480p60,640x480p60/75,800x600p60/75, 1024x768p60/75,1280x1024p60,1680x1050p60,1280x720p25/30/ Video Resolutions 50/60,1920x1080p25/30/50/60 HD [1080p@60Hz 24-bit color] up to 50m [164ft] Transmission Range: 8-bit Color Depth LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+ HDMI Audio Formats Human body model —... - Page 6 Receiver Input 1x CAT [RJ45] 1x HDMI Type A [19-pin female] Output 2x USB-A [USB A type] Mechanical Metal Enclosure Housing Black Color 109mm [W]x76.5mm [D]x25.4mm [H] Dimensions TX:213g RX:212g Weight Input: AC100 - 240V 50/60Hz Power Supply Output: DC 12V/1A (US/EU standards, CE/FCC/UL certified) TX:1.92W (Max) RX:1.68W (Max) Power Consumption Operation...
-
Page 7: Operation Controls And Functions
5. Operation Controls and Functions 5.1 Transmitter Panel POWER HDMI POWER: System power indicator. HDMI: Input HDMI signal indicator LED. On means there is an active signal. USB: USB status indicator LED, no USB signal being transmitted will show slow flashing, when USB signal being transmitted will show quick flashing. -
Page 8: Receiver Panel
DC 12V: Connect to a 12V DC power supply. No needs to connect another power supply if receiver is powered by an external 12V DC power supply. POC function allows you to power on Tx or Rx on any side ) HDMI IN: Connect to HDMI source device such as Blue-ray player or Set-Top box with an HDMI cable. - Page 9 POWER: System power indicator. HDMI: HDMI output connection indicator LED. On means there is an active HDMI display device be connected. USB: USB status indicator LED, no USB signal being transmitted will show slow flashing, when USB signal being transmitted shows quick flashing.
-
Page 10: Connection Diagram
6. Connection Diagram DC 12V HDMI OUT CAT5e/6 (POC)
