Item # 1000 054 283
YOW SKU # 661 248
Model # 151-101-5MOD-V5
USE AND CARE GUIDE
TOBAGO 5 PIECE MODULAR SECTIONAL
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
this 5 piece modular sectional. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY TOBAGO 151-101-5MOD-V5
Summary of Contents for HAMPTON BAY TOBAGO 151-101-5MOD-V5
- Page 1 THANK YOU this 5 piece modular sectional. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Table of Contents............ Assembly (Left Arm Chair Section).........8 Safety Information........... Assembly (Armless Chair Section).........11 Care Instructions............2 Assembly (Right Arm Chair Section)......14 Special Care Instructions about The Table Top......2 Assembly (Table)............. 17 Pre-Assembly (Left Arm Chair Section).....3 Assembly (Ottoman)............18 Planning Assembly/ Hardware Included / Package Contents...3 Assembly (3-Seat Sofa)...........19... -
Page 3: Pre-Assembly (Left Arm Chair Section)
Pre-Assembly (Left Arm Chair Section) The whole set includes one left arm chair section, one armless chair section, one right arm chair section, one table and one ottoman. Please lay out all parts prior assembly to verify all parts are included. PLANNING ASSEMBLY It will take two people about 20 minutes to complete the assembly process. -
Page 4: Pre-Assembly (Armless Chair Section)
Pre-Assembly (Armless Chair Section) PLANNING ASSEMBLY It will take two people about 20 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x35) Washer (D6) Bolt cap Bolt (M6x48) Plastic clamp PACKAGE CONTENTS 0.300 0. -
Page 5: Pre-Assembly (Right Arm Chair Section)
Pre-Assembly (Right Arm Chair Section) PLANNING ASSEMBLY It will take two people about 20 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x35) Washer (D6) Bolt cap Plastic clamp PACKAGE CONTENTS 比例... -
Page 6: Pre-Assembly (Table)
Pre-Assembly (Table) PLANNING ASSEMBLY It will take two people about 10 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Washer Bolt cap Bolt (M6x20) PACKAGE CONTENTS Part Description Quantity Table top Table leg... -
Page 7: Pre-Assembly (Ottoman)
Pre-Assembly (Ottoman) PLANNING ASSEMBLY It will take two people about 10 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Washer Bolt cap Bolt (M6x18) Bolt (M6x40) PACKAGE CONTENTS Part Description Quantity Seat panel Side panel... -
Page 8: Assembly (Left Arm Chair Section)
Assembly (Left Arm Chair Section) Attaching the side panel to the back panel □ Stand the back panel (B) on a flat, smooth surface. □ Hook the side panel (A) into the back panel (B) as shown below. Attach the side panel (A) to the back panel (B) with washers (BB) and bolts (AA) using the wrench (DD). tighten bolts (AA) until the end of Step 3. - Page 9 Assembly (Left Arm Chair Section) Attaching the L-shaped panel □ Attach the L-shaped panel (D) to the side panel (A), the seat panel (C) and the back panel (B) with washers (BB) and bolts (AA) using the wrench (DD). □ Fully tighten all the bolts (AA) when all of them are in place.
- Page 10 Assembly (Left Arm Chair Section) Covering the bolts □ Cover all the bolts (AA) with bolt caps (CC). Placing the cushions □ Place the cushions (E and F) on the sectional chair. □ Adjust the foot glides to stabilize the sectional chair.
-
Page 11: Assembly (Armless Chair Section)
Assembly (Armless Chair Section) Attaching the seat panel to the back panel □ Place the back panel (B1) upside down on a flat smooth surface. □ Attach the seat panel (C1) with a washer (BB) and a bolt (AA) using the wrench (DD). Do not fully tighten the bolt (AA) until the end of Step 3. - Page 12 Assembly (Armless Chair Section) Attaching the U-shaped panel (continued) □ Secure the U-shaped panel (D1) to the back panel (B1) and the seat panel (C1) with washers (BB) and bolts (AA and EE) using the wrench (DD). □ Fully tighten all the bolts (AA and EE) when all the bolts are in place.
- Page 13 Assembly (Armless Chair Section) Covering the bolts □ Cover all the bolts (AA and EE) with bolt caps (CC). Placing cushions □ Place the seat cushion (E) and the back cushion (F) on the armless chair section. □ Adjust foot glides to stabilize the armless chair section. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 14: Assembly (Right Arm Chair Section)
Assembly (Right Arm Chair Section) Attaching the side panel to the back panel □ Stand the back panel (B2) on a flat, smooth surface. □ Hook the side panel (A2) into the back panel (B2) as shown below. Attach the side panel (A2) to the back panel (B2) with washers (BB) and bolts (AA) using the wrench (DD). tighten bolts (AA) until the end of Step 3. - Page 15 Assembly (Right Arm Chair Section) Attaching the L-shaped panel □ Attach the L-shaped panel (D2) to the side panel (A2), the seat panel (C) and the back panel (B2) with washers (BB) and bolts (AA) using the wrench (DD). □ Fully tighten all the bolts (AA) when all of them are in place.
- Page 16 Assembly (Right Arm Chair Section) Covering the bolts □ Cover all the bolts (AA) with bolt caps (CC). Placing cushions □ Placing the cushions (E and F) on this chair section. □ Adjust the foot glides to stabilize this chair section.
-
Page 17: Assembly (Table)
Assembly (Table) Attaching table legs Attaching bolt caps □ □ Place the table top (G) upside down on a flat, smooth surface. Cover all bolts (FF) with bolt caps (CC). □ Attach the table legs (H) to the table top (G) with washers (BB) and bolts (FF). -
Page 18: Assembly (Ottoman)
Assembly (Ottoman) Attaching side panels to the seat panel Covering the bolts □ □ Place the seat panel (I) upside down on a flat, smooth suraface. Cover all the bolts (II and GG) with bolt caps (CC). □ Attach side panels (J) to the seat of seat panel (I) with washers (BB) and bolts (II and GG) using the wrench (DD). -
Page 19: Assembly (3-Seat Sofa)
Assembly (3-Seat Sofa) Use plastic clamps (HH) to secure the left arm chair section and the right arm chair section to the armless chair section to form a 3-seat sofa. See diagram below. Secure cushions to the 3-seat sofa with hook and loop strips. Warranty 2 YEAR FRAME/ WEAVE/ FABRIC LIMITED WARRANTY WHAT IS COVERED... - Page 20 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8.00 a.m. – 6.00 p.m., EST, Monday-Friday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
