AT L A S
STAINLESS STEEL UNDERMOUNT SINK
SKU: 944633, 944632, 944644, 944635, 944643, 944631, 944629, 944636, 944641, 944630, 944642, 944634
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing �xtures. Signature
Hardware accepts no liability for any damage to the
plumbing, sink, counter top, or for personal injury during
Observe all local plumbing and building codes.
Unpack and inspect the product for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
GETTING STARTED
For this installation it is assumed that the countertop
has been cut to the dimensions of the sink. We
recommend consulting a professional if you are
unfamiliar with this type of installation, Signature
Hardware accepts no liability for any damages to the
�oor, walls, plumbing or for personal injury during
installation.
Use care when lifting and installing any sink. Place sink
on a level surface with a towel or other soft cloth
beneath to prevent damage.
For Warranty information, please visit: signaturehardware.com/services/warranty
TOOLS AND MATERIALS:
Thread Sealant
Silicone Sealant
Pencil
1
Damp Cloth
REVISED 05/29/2020
CODES: 514395, 514408, 514392, 503287
514391, 514407, 514397, 503292, 514390
514604, 503301, 514396, 503291, 514409
503304, 514393, 514394, 503289, 506665
506668, 506667, 506666, 530322, 530321
