Specifications

Camera resolution 1280 (H) x 720 (V) pixels
Frame rate 30 frames per second (fps), approximately
Probe Diameter 0.2 in. (5.5 mm) for HDV7C-55–HD-1
0.19 in. (4.9 mm) for HDV7C-49–DUAL-1
Field of View 90°
Depth of Field 0.4 to 4.0 in (10 to 100 mm)
Probe tip length 0.78 in. (20 mm) for HDV7C-55–HD-1
0.85 in. (21.6 mm) for HDV7C-49–DUAL-1
Probe length 3.3 ft (1 m)
Side-view camera HDV7C-49–DUAL-1 only
LED Worklights Worklights are controlled from the HDV700
Four forward worklights on HDV7C-55–HD-1
Five forward and one side worklight on HDV7C-
49–DUAL-1
Operating temperature 14 to 140℉ (–10 to 60℃)
Storage temperature –4 to 140℉ (-20 to 60℃)
Relative Humidity 10 to 95 % non-condensing
Approved liquids for digi- Approved for use in brake and transmission fluid,
tal camera probes diesel fuel, unleaded gasoline, engine oil, and
CPC hydraulic fluid (46AWS).
Ingress rating Probe tip and body: IP 67 (IEC 60529)
Protected from submersion in water up to 3.3 ft (1
m) for 30 minutes maximum. In use: rain,
splashes, and accidental submersion
