- Page 1 5MP V2 UltraHD Fisheye POE Camera User Manual Version 1.0.0 September 21 , 2021...
-
Page 2: Table Of Contents
Contents Welcome ..................................3 Important Security Warning ............................3 Important Safeguards and Warnings ..........................3 Features and Specifications ............................4 Overview ..................................4 Features ..................................4 Device Overview ................................5 Technical Specifications ..............................5 Connection & Installation .............................. 7 Connection Guide ................................7 Installation Guide ................................ -
Page 3: Welcome
USA: +1-713-893-8956 Canada: 437-888-0177 UK: 203-769-2757 Important Security Warning To keep your Amcrest camera secure and prevent unauthorized access, please make sure to follow the steps below: • Always make sure that your camera has the latest firmware as listed on www.amcrest.com/firmware... -
Page 4: Features And Specifications
Features and Specifications Overview Amcrest provides an excellent digital surveillance product that can be useful to a wide variety of users. This 5MP version 2 fisheye camera features the latest JS technology and updated chipset which allows the camera to be viewed in any web browser without the use of a plugin. -
Page 5: Device Overview
Device Overview The image below shows the structure of the camera. The images below show the dimensions for the camera. The measurements are in millimeters (mm): Technical Specifications Model IP5M-F1180EW-V2 Camera Image Sensor 1/2.7”5Megapixel progressive CMOS Effective Pixels 2592 (H) × 1944 (V) - Page 6 Note: The DORI distance calculated based on sensor specification and lab test result 62676-4 which defines the criteria for Detect, Observe, Recognize, and Identify. Smart Event Heat Map Supported Intelligent Alerts IVS (Perimeter Protection) Tripwire; intrusion Support people counting in area, and displaying and outputting People Counting yearly/monthly/daily reports (matching devices are needed);...
-
Page 7: Connection & Installation
CGI; Milestone; Genetec; P2P User/Host 20 (Total Bandwidth: 64 MB) Storage Amcrest Cloud, FTP, NAS, MicroSD Card (Up to 256GB) Amcrest Surveillance Pro, Amcrest View Pro (iOS/Android), Amcrest Cloud, Management Software Amcrest Blue Iris, most mainstream web browsers including Google Chrome, Mozilla Firefox, Microsoft Edge, Safari, etc. - Page 8 Removing the Mounting Plate The mounting plate will be in the “open” state by default. Ensure that it stays “open” when installing the camera and adjust it to the close position after installation. Fixing the Mounting Plate When installing the mounting plate, use the included mounting template that was included with your camera. If you do not have the mounting template, line the mounting screws with the holes provided on the mounting plate.
-
Page 9: Microsd Card Installation Guide
Installing the Camera To install the camera onto a wall, follow the steps below: Using a drill, drill out the holes of the provided positioning map aligning the arrows on the mounting plate and positioning map. Insert the provided wall anchors into the holes. If the camera’s cables are being ran through the mounting surface, use a 1”... -
Page 10: Basic Wiring Overview
2. Open the hatch to expose the microSD card/factory reset button. 3. Place a microSD card into the provided microSD card slot, gold pins down, and press to secure. Note: To perform a factory reset on the camera, hold the WPS/Reset switch for 30 seconds allowing the device to reset. -
Page 11: Default Username And Password
1. Download and open the Amcrest Cloud app from the App Store or Play Store. Note: Connect your mobile device to the same network that your camera is on. 2. Register for an Amcrest Cloud account. To register click on Sign Up and fill out the form to complete registration. - Page 12 3. Tap on Add Camera 4. Give your camera a name (Ex. Garage, Living Room, Kitchen, etc.) and tap Next to continue. 6. If you are adding a new camera that does not have a 5. Scan the QR code on the back/side/bottom of set password the app will automatically detect that a the camera or manually enter the camera’s serial...
- Page 13 Download and install the Amcrest View Pro app for the App Store or Google Play Store. Open the app on your mobile device and allow the app to load.
- Page 14 3. Tap “Start”. 4. Tap “POE Camera”.
-
Page 15: Desktop Access Setup
The default username and password will be admin. Tap “Start Live View”. For more information about Amcrest View Pro and its functionalities visit amcrest.com/support Desktop Access Setup This camera features the latest in Java script technology which allows you to access your camera using a wide variety of web browsers including, Google Chrome, Firefox, Safari, or other mainstream web browsers using your PC or Mac. - Page 16 To access your camera from your computer you will need to first locate the camera’s IP address. To locate the camera’s IP address is it highly recommended to download our free Amcrest IP Config Tool software. The Amcrest Config Tool can be downloaded at the following web page: amcerest.com/downloads...
- Page 17 Enter in login details into the username and password fields and click login. Port Forwarding Remote Web Access Setup Port Forwarding is an alternative method to setting up remote access for Amcrest cameras. This method should only be used if the UPnP/DDNS Remote Access method did not work.
-
Page 18: Operation And Interface
For example, if the DDNS domain name is http://abc123456789.AmcrestDDNS.com and your HTTP Port is 33333, the URL would be http://abc123456789.AmcrestDDNS.com:33333 Enter in login details into the username and password fields and click login. If the process above is not working, please contact Amcrest Support via one of the following options: Visit http://amcrest.com/contact and use the email form. -
Page 19: Network
Section 5: This section allows the user to have quick access to Live view, Playback and Cloud Storage options. If you select Cloud Storage you will be directed to amcrestcloud.com to access or register an Amcrest Cloud account. - Page 20 Section 6: This section allows the user to access Setup menus, Alarm, and log out the web user interface. For more information on the Setup menu, refer to section 5.4 Setup. Section 7: This section allows the user to view and adjust fisheye settings associated with the camera such as installation modes and play modes.
