- Page 1 C O L O R M O N I T O R Model No : CTL 5xn...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS 1. Read all of these instructions. 2. Save these instructions for later use. 3. Unplug this monitor from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use attachments not recommended by the monitor manufacturer as they may cause hazards. -
Page 3: Canadian Department Of Communications Compliance Statement
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 4 The power cord is used as a main disconnect device. Disconnect the power cord before servicing. The outlet must be installed near the monitor and must be easily accessible. As an NERGY TAR Partner, Daewoo Electronics Co., Ltd. has determined that this product meets the Energy Star guidelines for energy efficiency.
-
Page 5: Table Of Contents
CONTENTS Introduction Product Features Setup Installing the Tilt/Swivel Stand Connecting the D-Sub Signal Cable Connecting to Your Macintosh Computer Connecting the Power Cord Power Management System DDC for Plug & Play Operation & Adjustment Specifications Factory Preset Timings Troubleshooting Appendix Description for D-sub Connector... -
Page 6: Introduction
INTRODUCTION This manual explains how to correctly install, operate and get the best performance from your monitor. Please read this user's manual carefully before installing your monitor, then keep it near your monitor for quick reference. First, please check that the contents of the carton box corresponds with the following checklist : ¡... -
Page 7: Product Features
PRODUCT FEATURES ¡ The convenient and user-friendlly on-screen display allows for easy and accurate adjustments of horizontal and vertical screen size and position, geometry and screen color. ¡ The monitor supports a safe working environment in strict compliance with the MPR¥–standard for low emissions. ¡... -
Page 8: Setup
SETUP INSTALLING THE TILT/SWIVEL STAND 1. Ensure that the power to the monitor is off. 2. Set the monitor face down with the underside facing you. Please be careful so as not to scratch the monitor screen. 3. Align the four hooks on the stand with the guide holes of bottom chassis of the monitor. -
Page 9: Connecting The D-Sub Signal Cable
CONNECTING THE D-SUB SIGNAL CABLE 1. Turn off the computer and monitor. 2. Connect the 15 pin D-sub connector to the output port of the video card in your computer. 3. Tighten the screws of connector. CONNECTING TO YOUR MACINTOSH COMPUTER 1. -
Page 10: Power Management System
POWER MANAGEMENT SYSTEM If you use the monitor with a computer which complies with the power saving program, you can set the monitor to go blank when the system has remained unused for a period of time. To specify the period or to disable this feature, set the system timeout field of the computer's system setup program or use special software for power saving. -
Page 11: Operation & Adjustment
OPERATION & ADJUSTMENT EXIT : Launch OSD(On-Screen Display) Menus MENU : Select the next function : Select the previous function : Increase the value of any selected function : Decrease the value of any selected function – : Exit OSD Menus & Launch OSD Menus, when no OSD EXIT Key Process MENU... - Page 12 1. OSD(On-Screen Display) Menu 1 CONTRAST BRIGHTNESS H. POSITION H. SIZE V. POSITION V. SIZE Adjust the contrast of image, the difference between light and dark areas on the screen. Adjust the brightness of the entire display. Adjust the position of the display horizontally (left or right).
-
Page 13: Osd (On-Screen Display) Menu
2. OSD (On-Screen Display) Menu 2 PINCUSHION TRAPEZOID COLOR TEMP. USER 9300 6550 R. GAIN B. GAIN DEGAUSSING RECALL Adjust the left and right margins for more convex or more concave margins. ƒUImage turns to ƒUImage turns to Adjust the trapezoid of the screen by moving the lines inward or outward. -
Page 14: Specifications
SPECIFICATIONS Picture Tube Video Scan Frequency Max. Resolution Power Source Display Area Power Consumption Max. 80W Regulatory Approvals Type :15-inch, Flat Square Tube type (14-inch, viewing area) Dot Pitch : 0.28mm, MPR ¥– Face Treatment: Non-glare/Anti-static Input Signal : R.G.B Analog Amp. -
Page 15: Factory Preset Timings
Tilt /Swivel Range Dimension Weight (net/Gross) Operating Environment Storage Environment FACTORY PRESET TIMINGS Mode (dots¡ ¡ ¿ ¿ lines) VESA VGA 75 VESA 46K VESA 1024/60 VESA 800x600 @85Hz This monitor has stored above-mentioned six timings in factory. You can save up to 10 modes in the user memory automatically. Please note that if you save to user memory over ten times, the first mode saved will be replaced with your eleventh mode. -
Page 16: Troubleshooting
TROUBLESHOOTING Symptom No picture. POWER LED is not lit. Image is unstable. Image is not centered, too small, or too large. Picture bounces or a wave pattern is present in the picture. Color looks blotchy. Picture is blurred. Edges of available area on the screen are not straight. -
Page 17: Appendix
APPENDIX DESCRIPTION FOR D-SUB CONNECTOR GND (Self -Test) GND - Green GND - H.Sync GND-V.Sync Bi-directional Data (SDA) Horizontal Sync Vertical Sync (VCLK) Data Clock (SCL) Signal Green Blue GND - Red GND - Blue No Pin *GND = Ground... - Page 18 S/N: 9978623903...
