Ctl 7dln User Manual

Computer technology link color monitor user's guide 7dln
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER'S GUIDE
COLOR MONITOR
7 dln
Model No :
C T L
S/N : 9978628208

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7dln and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ctl 7dln

Summary of Contents for Ctl 7dln

  • Page 1 USER’S GUIDE COLOR MONITOR 7 dln Model No : C T L S/N : 9978628208...

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS 1. Read all of these instructions. 2. Save these instructions for later use. 3. Unplug this monitor from the wall outlet before cleaning. Do not will prevent damage to the monitor and/or the use liquid cleaners or aerosol computer due to lightning and power line surges.

  • Page 3: Table Of Contents

    CONTENTS Introduction ... 1 Product Features ... 2 Setup ... 3 Installing the Tilt/Swivel Stand ... 3 Connecting the Signal Cable and Power Cord... 4 Operation & Adjustment ... 5 Specifications ... 10 Factory Preset Timings ... 10 Troubleshooting ... 11 INTRODUCTION This manual explains how to correctly install, operate and get the best performance from your monitor.

  • Page 4: Product Features

    PRODUCT FEATURES • The convenient and user-friendly on-screen display allows for easy and accurate adjustments of horizontal and vertical screen size and position, geometry and screen color. • The monitor supports a safe working environment in strict compliance with the MPR II standard for low emissions (TCO Optional).

  • Page 5: Connecting The Signal Cable And Power Cord

    CONNECTING THE SIGNAL CABLE AND POWER CORD 1. Turn off the computer and monitor. 2. Connect the 15 pin D-sub connector to the output port of the video card in your computer. 3. Tighten the screws of the connector. 4. Plug the power cord into the AC receptacle located on the back of the monitor.
  • Page 6 Key Process MENU SELECT MENU MENU MENU OSD OFF • When you choose the icon on the OSD window, you can exit the OSD screen. English - 6 OSD Functions ICON CONTROL FUNCTION Adjust the position of the display H. POSITION horizontally (left or right).
  • Page 7 ICON CONTROL FUNCTION Adjust the side pin corner balance top T. PIN BALANCE when the top sides of the screen are bowed towards left or right. Adjust the side pin corner balance bottom B. PIN BALANCE when the bottom sides of the screen are bowed towards left or right.

  • Page 8: Specifications

    SPECIFICATIONS CDT Size 17-inch Diagonal visible image area 16.2-inch Dot Pitch 0.27 mm Synchronization Horizontal 30 - 70 KHz Vertical 50 - 160 Hz Plug and Play DDC1/2B/CI Power Saving EPA, VESA DPMS, Nutek Compliant Power Source 100-240 Vac, 50/60Hz (Free Voltage) Power Consumption Dimension-W x H x D 420 x 453 x 429mm...
