  • Page 2: Operation Instructions

    Operation Instructions Thank you for purchasing this monitor, a high-resolution multi-scan color monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    Content Safety Precautions.......................1 First Setup ...........................2 Installing the LCD Monitor....................2 Quick Installation .........................3 Front View of the Product ....................4 Rear View of the Product .....................5 Using On Screen Display (OSD) Functions .................6 Supporting Timing Modes ....................6 Technical Information ......................10 Care and Maintenance.......................11 Troubleshooting .........................11...

  • Page 4: Safety Precautions

    Safety Precautions This monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may result danger to the monitor as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy.

  • Page 5: First Setup

    First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories : • AC Power Cord • Audio cable • VGA cable (15 pin) • User’s guide • DisplayPort cable (20 pin) Installing the LCD Monitor Installing the Stand Base 1.

  • Page 6: Quick Installation

    Quick Installation 1. Connect Video cable Make sure both monitor and computer are powered OFF. Connect the video cable (VGA cable) to the computer, then to the monitor. or connect DisplayPort cable Connect the DisplayPort cable from DisplayPort output of computer to the DisplayPort input of the monitor.

  • Page 7: Front View Of The Product

    Front View of the Product OSD Menu On/Off Scroll Down/ Decrease Scroll Up/ Increase Confirm Select Power ON/OFF LED Indicator...

  • Page 8: Rear View Of The Product

    Rear View of the Product Power input (AC input) Audio input DisplayPort input (DisplayPort 20 pin) HDMI/MHL input (HDMI 19 pin) VGA input (D-Sub 15 pin)

  • Page 9: Using On Screen Display (Osd) Functions

    Using On Screen Display (OSD) Functions Display main menu Exit from OSD menu Manual adjust mode select for VGA, HDMI, DisplayPort, Auto mode Select the desired item when in OSD menu ▼ When not in OSD menu, directly enters Audio Adjust menu, press 3 seconds enters Auto Image Adjust Select the desired item when in OSD menu ▲...
  • Page 10 Contrast: To adjust the foreground white level of screen image. ▲: increase contrast, ▼: decrease contrast. Brightness: To adjust the luminance of the video. ▲: increase brightness, ▼: decrease brightness. Adv.Contrast: Turn on/off DCR mode. If DCR mode is ON, max value of Dynamic Brightness will be restricted.
  • Page 11 Manual Image Adjust: To manually adjust the H. / V. Position, Clock, Phase, Sharpness and Video Mode Adjust. H. / V. Position: To adjust the horizontal and vertical position of the video. H. Position: ▲: move screen to the right, ▼: move screen to the left. V.

  • Page 12: Supporting Timing Modes

    Supporting Timing Modes 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA...

  • Page 13: Technical Information

    Technical Information Technical Specification LCD Panel 54.6 cm (21.5”) TFT (with LED back light) Power Management Energy Star VESA DPMS compatible Off Mode, < 0.5 W Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.24825 x 0.24825 mm LCD Display Color 16.7M...

  • Page 14: Care And Maintenance

    Care and Maintenance Care Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place any heavy things on top of your monitor. Make certain your monitor is installed in a clean and moisture-free area.
  • Page 15 2001132455T...
