USER'S GUIDE
COLOR MONITOR
2 1 dn
Model No :
C T L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21dn and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ctl 21dn

Summary of Contents for Ctl 21dn

  • Page 1 USER’S GUIDE COLOR MONITOR 2 1 dn Model No : C T L...

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS 1. Read all of these instructions. 2. Save these instructions for later use. 3. Unplug this monitor from the wall outlet before cleaning. Do not will prevent damage to the monitor and/or the use liquid cleaners or aerosol computer due to lightning and power line surges.

  • Page 3: Table Of Contents

    CONTENTS Introduction ... 1 Product Features ... 2 Setup ... 3 Connecting the D-sub Signal Cable ... 3 Connecting the BNC Signal Cable ... 4 Connecting the Power Cord ... 5 Power Management System ... 5 DDC for Plug & Play ... 5 Operation &...

  • Page 4: Product Features

    PRODUCT FEATURES • The convenient and user-friendly on-screen display allows for easy and accurate adjustments of horizontal and vertical screen size and position, geometry and screen color. • The monitor supports a safe working environment in strict compliance with the MPR II standard for low emissions (TCO optional).

  • Page 5: Connecting The Bnc Signal Cable

    CONNECTING THE BNC SIGNAL CABLE 1. Turn off the computer and monitor. 2. Connect the 5 BNC connectors from the signal cable to the monitor. 3. Push in and turn the connectors clockwise until they are locked in place. BNC signal cable (Optional Accessory) CONNECTING THE POWER CORD 1.

  • Page 6: Operation & Adjustment

    OPERATION & ADJUSTMENT Control Panel • Move cursor to the right window on the OSD window. • Increase the value of any selected function. • Move cursor to the left window on the OSD window. • Decrease the value of any selected function. •...
  • Page 7 OSD Functions ICON CONTROL FUNCTION Select language for OSD (5 languages). LANGUAGE Adjust the position of the display H. CENTER & horizontally(left or right) and vertically V. CENTER (up or down) Choose different preset color temperatures or set your own customized COLOR TEMP color parameters.
  • Page 8 ICON CONTROL FUNCTION Adjust the pin W control when the sides PIN W CONTROL of the screen are in a W shape. Adjust the rotation when the screen is ROTATION tilted left or right. Degaussing keeps the monitor free from DEGAUSS unwanted magnetism that can result in color impurity.

  • Page 9: Specifications

    SPECIFICATIONS CDT Size 21-inch Diagonal visible image area 20-inch Dot Pitch 0.25 mm Synchronization Horizontal 30 - 107 KHz Vertical 50 - 160 Hz Plug and Play DDC1/2B/CI Power Saving EPA, VESA DPMS, Nutek Compliant Power Source 100-240 Vac, 50/60Hz (Free Voltage) Power Consumption 135 W Dimension-W x H x D...

  • Page 10: Description For D-Sub Connector

    DESCRIPTION FOR D-SUB CONNECTOR Signal Green Blue GND-Red GND-Green GND-Blue +5Vdc GND-H.Sync GND-V.Sync Bi-directional Data(SDA) Horizontal Sync Vertical Sync(VCLK) Data Clock(SCL) GND=Ground...
  • Page 11 S/N : 9978628318...
