USER'S GUIDE
COLOR MONITOR
7cln
Model No :
C T L
S/N:9978626503

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7cln and is the answer not in the manual?

Questions and answers

Related Manuals for Ctl 7cln

Summary of Contents for Ctl 7cln

  • Page 1 USER’S GUIDE COLOR MONITOR 7cln Model No : C T L S/N:9978626503...

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS 1. Read all of these instructions. 2. Save these instructions for later use. 3. Unplug this monitor from the wall outlet before cleaning. Do not will prevent damage to the monitor and/or the use liquid cleaners or aerosol computer due to lightning and power line surges.
  • Page 3 The power cord is used as a main disconnect device. Disconnect the power cord before servicing. The outlet must be installed near the monitor and must be easily accessible. As an ENERGY STAR Partner, Computer Technology Link, Inc. has determined that this product meets the Energy Star guidelines for energy efficiency.

  • Page 4: Table Of Contents

    CONTENTS Introduction ... 1 Product Features ... 2 Setup ... 3 Installing the Tilt/Swivel Stand ... 3 Connecting the Signal Cable and Power Cord... 4 Power Management System ... 5 DDC for Plug & Play ... 5 Operation & Adjustment ...

  • Page 5: Product Features

    PRODUCT FEATURES • The convenient and user-friendly on-screen display allows for easy and accurate adjustments of horizontal and vertical screen size and position, geometry and screen color. • The monitor supports a safe working environment in strict compliance with the MPR II standard for low emissions. •...

  • Page 6: Connecting The Signal Cable And Power Cord

    CONNECTING THE SIGNAL CABLE AND POWER CORD 1. Turn off the computer and monitor. 2. Connect the 15 pin D-sub connector to the output port of the video card in your computer. 3. Tighten the screws of the connector. 4. Plug the power cord into the AC receptacle located on the back of the monitor.

  • Page 7: Operation & Adjustment

    OPERATION & ADJUSTMENT Control Panel Move cursor to the right window on the OSD • window. Increase the value of any selected function. • Move cursor to the left window on the OSD • window. Decrease the value of any selected function. •...
  • Page 8 OSD Functions ICON CONTROL FUNCTIONS Select language for OSD (5 languages). LANGUAGE Adjust the position of the display H. CENTER & horizontally(left or right) and vertically V. CENTER (up or down) Choose different preset color temperatures or set your own customized COLOR TEMP color parameters.

  • Page 9: Factory Preset Timings

    ICON CONTROL FUNCTIONS Display horizontal & vertical frequency STATUS and polarity. YES : VESA DPMS operation. POWER SAVER NO : NO DPMS operation. Display a RGB Color Bar to determine TEST PATTERN whether the screen color is expressed normally or not. Reset the screen to the Factory Preset RECALL Display Settings.

  • Page 10: Troubleshooting

    TROUBLESHOOTING Symptom Check No picture. Check if power switch and computer power switch are in the on position. Check if the signal cable is correctly connected to the video card. Check if the pins of D subconnector are not bent. Check if the computer is in the power- saving mode.
