Operating Instructions
Air Conditioner
Model No.
Indoor Unit
CS-Z9ZKA
CS-Z12ZKA
CS-Z18ZKA
CS-Z24ZKA
Outdoor Unit
CU-Z9ZKA
CU-Z12ZKA
CU-Z18ZKA
CU-Z24ZKA
操作說明書
空調器
在操作空調器前，請細讀此操作說明，並保存此書以備日後
參考。
安裝前，安裝人員應:
閱讀安裝說明，並要求顧客保留此安裝説明以備將來參考。
取出包裝在室内機箱子的遙控器。
如果將本空調器轉讓給新的用戶或送往回收廠，請務必將
本説明書一并交出。
Operating Instructions
Air Conditioner
Before operating the unit, please read these operating
instructions thoroughly and keep them for future reference.
Before installation, the installer should:
Read the Installation Instructions, then request the customer
keep them for future reference.
Remove the remote control packed with the indoor unit.
If the equipment is transferred to a new user or delivered
to a recycling plant, be sure also to hand over the manual.
2-22
24-44
ACXF55-34070
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Panasonic CS-Z9ZKA
Summary of Contents for Panasonic CS-Z9ZKA
- Page 1 Operating Instructions Air Conditioner Model No. Indoor Unit Outdoor Unit CS-Z9ZKA CU-Z9ZKA CS-Z12ZKA CU-Z12ZKA CS-Z18ZKA CU-Z18ZKA CS-Z24ZKA CU-Z24ZKA 操作說明書 2-22 空調器 在操作空調器前，請細讀此操作說明，並保存此書以備日後 參考。 安裝前，安裝人員應: 閱讀安裝說明，並要求顧客保留此安裝説明以備將來參考。 取出包裝在室内機箱子的遙控器。 如果將本空調器轉讓給新的用戶或送往回收廠，請務必將 本説明書一并交出。 Operating Instructions 24-44 Air Conditioner Before operating the unit, please read these operating instructions thoroughly and keep them for future reference.
- Page 2 A new built-in Network Adaptor that allows you to control your air conditioner unit operation from anywhere. Use the remote control within 8 m from the remote control receiver on the indoor unit. Quick Guide Inserting the batteries Clock setting 1 Press , then CLOCK...
-
Page 3: Table Of Contents
Thank you for purchasing Panasonic Air Conditioner. Table of Contents Safety Precautions ..26-33 How to Use ....34-36 To Learn More....37-38 Cleaning the Air Conditioner ....39 Troubleshooting ....40-43 Information ......44 Accessories • Remote control • AAA or R03 batteries × 2 •... -
Page 4: Safety Precautions
Safety Precautions To prevent personal injury, injury to others or property damage, please comply with the following: WARNING Incorrect operation due to failure to follow instructions below may cause harm or damage, the seriousness of which is classifi ed as below: This appliances is not intended for accessibility by the Indoor unit and outdoor unit general public. - Page 5 Power supply CAUTION Do not use a modifi ed cord, joint cord, extension cord or unspecifi ed cord to prevent Indoor unit and outdoor unit overheating and fi re. To prevent overheating, fi re or electric shock: Do not wash the indoor unit with water, benzine, thinner or scouring powder to avoid •...
- Page 6 Safety Precautions Must always ensure that foreign matter (oil, WARNING water, etc.) does not enter the piping. Also, when storing the piping, securely seal the opening by pinching, taping, etc. (Handling of R32 is similar to R410A.) This appliance is fi lled with R32 •...
- Page 7 f) Precautions shall be taken to avoid 2. Servicing excessive vibration or pulsation to 2-1. Service personnel refrigerating piping. • The system is inspected, regularly supervised g) Ensure protection devices, refrigerating and maintained by a trained and certifi ed piping and fittings are well protected service personnel who is employed by the against adverse environmental effects person user or party responsible.
- Page 8 Safety Precautions 2-3. Checking for presence of refrigerant 2-7. Checks to the refrigerating equipment • The area shall be checked with an • Where electrical components are being appropriate refrigerant detector prior to and changed, they shall be fi t for the purpose and during work, to ensure the technician is aware to the correct specifi...
- Page 9 3. Repairs to sealed components 6. Detection of fl ammable refrigerants • During repairs to sealed components, all • Under no circumstances shall potential electrical supplies shall be disconnected from sources of ignition be used in the searching or the equipment being worked upon prior to any detection of refrigerant leaks.
- Page 10 Safety Precautions 8. Removal and evacuation 9. Charging procedures • When breaking into the refrigerant circuit • In addition to conventional charging to make repairs – or for any other purpose procedures, the following requirements shall – conventional procedures shall be used. be followed.
- Page 11 e) If a vacuum is not possible, make a • The recovery equipment shall be in good manifold so that refrigerant can be working order with a set of instructions removed from various parts of the system. concerning the equipment that is at hand and f) Make sure that cylinder is situated on the shall be suitable for the recovery of fl...
-
Page 12: How To Use
How to Use Indicators To adjust airfl ow direction To adjust airfl ow direction (swing) Upper direction Lateral (swing) direction • Do not adjust the fl ap by hand. * For details operation, refer “To Learn More..” To adjust FAN SPEED and QUIET condition FAN SPEED: •... - Page 13 See "To Learn More..." for details. To reach the desired temperature quickly Set temperature -2°C / iAUTO-X -4°F Max = 4 hours • When iAUTO-X mode is turned on, the unit automatically reduces the temperature by 2°C (4°F) from the set temperature to accelerate the room cooling effect. •...
- Page 14 How to Use To set the timer You can set the timer to turn on and off the unit at 2 different preset time. • To cancel the timer, press select the respective setting , then press • If the timer has been cancelled manually or due to power failure, you can restore the timer again.
-
Page 15: To Learn More
To Learn More... Operation mode AUTO : During operation, the POWER indicator will blinks at initial. • Unit selects operation mode every 10 minutes according to the setting and room temperatures. HEAT : The POWER indicator blinks at the initial stage of this operation. Unit takes a while to warm up. - Page 16 To Learn More... Inside Cleaning This function is incorporated with humidity sensing and nanoe™X to improve effi ciency and effectiveness of the air conditioner unit. Depending on the unit’s accumulated operation time, the inside cleaning operation may be activated only once a day after the unit is turned off in standby mode.
-
Page 17: Cleaning The Air Conditioner
Cleaning the Air Conditioner Cleaning has to be carried out at regular Indoor unit intervals to ensure the unit is at optimal ( Structure of the unit may vary depending on performance. A dirty unit may cause the model) malfunction and you may retrieve “H 99” Aluminium fi... -
Page 18: Troubleshooting
Troubleshooting The following symptoms do not indicate malfunction. Symptom Cause POWER indicator blinks before the unit is • This is the preliminary step to prepare for the TIMER switched on. operation after it has been set. When Timer is set ON, the unit may start earlier up to (30 minutes) before the actual set time to achieve the desired temperature on time. - Page 19 Check the following before calling for servicing. Symptom Check Operation in HEAT / COOL mode is not • Set the temperature correctly. working effi ciently. • Close all doors and windows. • Clean or replace the fi lters. • Clear any obstruction at the air inlet and air outlet vents.
- Page 20 Troubleshooting When... ■The remote control is missing or a malfunction has occurred 1. Raise the front panel. 2. Press AUTO OFF/ON once to use in AUTO mode. 3. Press AUTO OFF/ON hold for 5 seconds until you hear 1 beep, then release to use in forced COOL mode.
- Page 21 How to retrieve error codes If the unit stops and the TIMER indicator blinks, use the remote control to retrieve the error code. Press for Press until you hear beep 5 seconds sound, then write down the error code Press for 5 Turn the unit off and seconds to quit inform the error code to an...
-
Page 22: Information
Information Information for Users on Collection and Disposal of Old Equipment and used Batteries [Information on Disposal in other Countries outside the European Union] These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal. - Page 23 Memo...
- Page 24 Memo...
- Page 25 Memo...
- Page 26 Panasonic Corporation 1006, Oaza Kadoma, Kadoma City, Osaka 570-8501, Japan Website: http://www.panasonic.com © Panasonic Corporation 2022 ACXF55-34070 Printed in Malaysia SC1222-0...
