Panasonic CS-RZ25TKR Operating Instructions Manual

Indoor/outdoor units
Hide thumbs

Advertisement

Operating Instructions

Air Conditioner

Model No.
Indoor Unit
CS-RZ25TKR
CS-RZ35TKR
i AUTO-X
ECONOMY
Outdoor Unit
CU-RZ25TKR
CU-RZ35TKR
Operating Instructions
Air Conditioner
Before operating the unit, please read these operating
instructions thoroughly and keep them for future reference.
The included Installation Instructions should be kept and read
by the installer before installation.
Remote control is packaged in the indoor unit and removed
by the installer before installation.
ACXF55-11360

Advertisement

Table of Contents
loading

  Related Manuals for Panasonic CS-RZ25TKR

  Summary of Contents for Panasonic CS-RZ25TKR

  • Page 1: Operating Instructions

    Operating Instructions Air Conditioner i AUTO-X ECONOMY Model No. Indoor Unit Outdoor Unit CS-RZ25TKR CU-RZ25TKR CS-RZ35TKR CU-RZ35TKR Operating Instructions Air Conditioner Before operating the unit, please read these operating instructions thoroughly and keep them for future reference. The included Installation Instructions should be kept and read by the installer before installation.
  • Page 2 Provides maximum comfort and clean air with optimal energy saving methods. Use remote control within 8 m from the remote control receiver of the indoor unit. Quick Guide Inserting the batteries Clock setting 1 Press and set the time 1 Pull out the back cover of remote control.
  • Page 3: Table Of Contents

    Thank you for purchasing Panasonic Air Conditioner. Table of contents This symbol shows Safety precautions ………… 4-7 that this equipment uses a fl ammable How to use ……………………… 8-9 refrigerant. If the WARNING refrigerant is leaked, To learn more ………………… 10...
  • Page 4: Warning

    Safety precautions To prevent personal injury, injury to WARNING others or property damage, please comply with the following: Incorrect operation due to failure to follow instructions below may cause Indoor unit and outdoor unit harm or damage, the seriousness of which is classifi...
  • Page 5 Do not use means to accelerate To prevent overheating, fi re or the defrosting process or electric shock: to clean, other than those • Do not share the same power recommended by manufacturer. outlet with other equipment. Any unfi t method or using •...
  • Page 6: Safety Precautions

    Safety precautions This equipment must be earthed Since the working pressure is to prevent electrical shock or fi re. higher than that of refrigerant R22 models, some of the piping and installation and service tools Prevent electric shock by are special. switching off the power supply Especially, when replacing a and unplug:...
  • Page 7 Do not pierce or burn as the Do not place a vase or water appliance is pressurized. Do not container on the unit. Water may expose the appliance to heat, enter the unit and degrade the fl ame, sparks, or other sources insulation.
  • Page 8: How To Use

    How to use To adjust airfl ow direction To adjust airfl ow direction Upper direction AIR SWING i AUTO-X ECONOMY Indicator POWER • Do not adjust the fl ap by hand. TIMER i AUTO-X ECONOMY • For lateral direction, it is manually adjustable as shown.
  • Page 9 See "To learn more..." for details. To switch between powerful/quiet POWERFUL: To reach the preset temperature quickly • This operation stops automatically after 20 minutes. QUIET: To enjoy quiet operation • This operation reduces airfl ow noise. To set the timer 2 sets of ON and OFF timers are available to turn ON or OFF the unit at different preset times.
  • Page 10: To Learn More

    To learn more... Operation mode AUTO : During operation mode selection the POWER indicator blinks. • Unit selects operation mode every 10 minutes according to setting temperature and room temperature. HEAT : Unit takes a while to warm up. The POWER indicator blinks during this operation.
  • Page 11: Cleaning Instructions

    Cleaning instructions To ensure optimal performance of the Indoor unit unit, cleaning has to be carried out at Anti-bacterial fi lter regular intervals. Dirty unit may cause Aluminium fi n malfunction and you may see error code Front panel “H99”. Please consult authorised dealer. •...
  • Page 12: Troubleshooting

    Troubleshooting The following symptoms do not indicate malfunction. Symptom Cause POWER indicator blinks before the unit is • This is a preliminary step in preparation for the switched on. operation when the ON timer has been set. • When ON Timer is set, the unit may start earlier (up to 35 minutes) before the actual set time in order to achieve the desired temperature on time.
  • Page 13 When... ■The remote control is missing or a malfunction has occurred 1.Raise the front panel. 2.Press the button once to use in i AUTO-X mode. 3. Press and hold the button until you hear 1 beep, then release to use in AUTO forced COOL mode.
  • Page 14 Troubleshooting How to retrieve error codes If the unit stops and the TIMER indicator blinks, use the remote control to retrieve the error code. Press for Press until you hear beep 5 seconds sound, then write down the error code TIMER TIMER CANCEL...
  • Page 15: Information

    Information Information for Users on Collection and Disposal of Old Equipment and used Batteries [Information on Disposal in other Countries outside the European Union] These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal.
  • Page 16 Panasonic Corporation 1006 Kadoma, Kadoma City, Osaka, Japan Website: http://www.panasonic.com © Panasonic Corporation 2017 ACXF55-11360 Printed in Malaysia SM0717-0...
