- Page 1 INSTRUCTION MANUAL FOR PM-9100 Dual & Differential Input PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION 3, Hagavish st. Israel 58817 Tel: 972 3 5595252, Fax: 972 3 5594529 mrc@mrclab.com MRC.VER.02-11.10...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. FEATURES..............1 2. SPECIFICATIONS............1 2-1 General Specifications......... 1 2-2 Electrical Specifications........3 3. FRONT PANEL DESCRIPTION........4 3-1 Display............. 4 3-2 Power Off/On Button.........4 3-3 Hold Button............4 3-4 Zero Button..........3-5 " MAX./MIN. " Button........4 3-6 Unit Button.... -
Page 3: Features
1. FEATURES * Dual & differential input, 2000 mbar max. range. * Application : Industrial, laboratory, heating, ventilation, medical hospital, used for dry, non-corrosive and non-ionic air and gas only. Liquid is prohibited. * Sensor is built inside the housing. * Single lugs for pipe connection. - Page 4 Display units mbar, psi, Kg/cm 2 mm Hg, inch Hg, meter HF2 , inch HF2 , Atmosphere. Function Dual & differential input, data hold, zero/relative, memory. Zero adjust Push button on the front panel. Sensor * Sensor is built inside the housing. * Piezoelectric sensor.
-
Page 5: Electrical Specifications
2-2 Electrical Specifications Unit Max. range Resolution mbar 2000 mbar mbar 0.02 Kg/cm 2 2.040 Kg/cm 2 0.001 Kg/cm 2 mm Hg 1500 mm Hg mm Hg inch Hg 59.05 inch Hg 0.05 inch Hg meter HF2 20.40 meter HF2 ... -
Page 6: Front Panel Description
3. FRONT PANEL DESCRIPTION Fig. 1 3-1 Display 3-7 P1 input socket 3-2 Power Off/On Button 3-8 P2 input socket 3-3 Hold Button 3-9 RS-232 Output 3-4 Zero Button Terminal 3-5 " MAX./MIN. " Button 3-10 Battery Compartment 3-6 Unit Button /Cover 3-11 PLug/ quick coupler... -
Page 7: Measuring Procedure
4. MEASURING PROCEDURE 1) Power on the meter by pressing the " Power Off/On Button " ( 3-2, Fig. 1 ). 2) Select the desired temperature units ( mbar, psi, Kg/cm 2 mm Hg, inch Hg, meter HF2 , inch HF2 , Atmosphere ) ... -
Page 8: Auto Power Off Disable
7) Data Record ( Maximum, Minimum reading ) * The DATA RECORD function displays the maximum and minimum readings. To start the DATA RECORD function, press the " MAX./MIN. Button " ( 3-5, Fig. 1 ) once. " REC " symbol will appear on the LCD display. * With the "... -
Page 9: Rs232 Pc Serial Interface
5. AUTO POWER OFF DISABLE The instrument has built-in " Auto Power Shut-off " in order to prolong battery life. The meter will switch off automatically if none of the buttons are pressed within 10 min. To de-activate this feature, Select the memory record function during measurement, by pressing the "... -
Page 10: Battery Replacement
The 16 digit data stream will be displayed in the following format : D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0 Each digit indicate the following status : End Word D1 to D8 Display reading, D1=LSD, D8=MSD For example : If the display reading is 1234, then D8 to D1 is 00001234...
