Installation & Operation Manual
Full Jacket Steam Tilting Kettle
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
M
R
ANUAL 10280
EV 3 (11/22)
$21.00
Gas Fired
FT-40GLS
servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
FT-40GLS
WARNING
A Middleby Company
www.crownsteamgroup.com
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
GAS FIRED FULL JACKET STEAM
TILTING KETTLE
M
S
ANUAL
ECTION
CO

Advertisement

loading
Need help?

Need help?

Do you have a question about the FT-40GLS and is the answer not in the manual?

Questions and answers

Related Manuals for Market Forge Industries FT-40GLS

Summary of Contents for Market Forge Industries FT-40GLS

  • Page 1 Date Purchased: _____________________ Installation & Operation Manual Gas Fired Full Jacket Steam Tilting Kettle FT-40GLS FT-40GLS WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.

  • Page 2: Important Notes For Installation And Operation

    Safety Precautions Gas Fired Full Jacket Steam Tilting Kettle SAFETY PRECAUTIONS Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator, service personnel, or to the equipment.

  • Page 3: Table Of Contents

    Gas Fired Full Jacket Steam Tilting Kettle Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Important Notes For Installation and Operation ..............2 Service Connections ......................4 Installation ..........................5 Operation ..........................8 Cleaning ..........................11 Maintenance .........................

  • Page 4: Service Connections

    – HOT WATER: 3/8” (10 mm) tubing to faucet (optional) GAS CHARACTERISTICS Gas Supply Model BTU/HR. kW/HR. Supply Pipe Pressure (W.C.) Natural Propane FT-40GLS 125,000 36.63 6”-14” (152-356 mm) 11”-14” (279-356 mm) COMPARTMENT PAN CAPACITY AND SPECIFICATIONS Model Pan Capacity Shipping Weight...

  • Page 5: Installation

    Gas Fired Full Jacket Steam Tilting Kettle Installation Installation Unpacking IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking, check for possible shipping damage. If the tilting braising pan is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Before installing, verify that the electrical service agrees with the specifications on the rating plate located on the left side panel as you face the front of the braising pan.
  • Page 6 Installation Gas Fired Full Jacket Steam Tilting Kettle Purge the supply line to clean out any dust, dirt, or other foreign matter before connecting the line to the unit. It is recommended that an individual manual shut off valve be installed in the gas supply line to the unit. Use pipe joint compound which is suitable for use with LP gas on all threaded connections.
  • Page 7 Gas Fired Full Jacket Steam Tilting Kettle Installation 2. 208/240 VAC - 60 Hz - Single and Three Phase Units with this electrical rating are factory equipped with a transformer. To connect supply wires, remove cover from right console. Route supply wires and ground wire through the hole in the console with a strain relief fitting. Connect wires to the terminal block in the rear of the right console.

  • Page 8: Operation

    Operation Gas Fired Full Jacket Steam Tilting Kettle Operation NOTICE Contact the factory, the factory representative or a local service company to perform maintenance and repairs should the appliance malfunction. CAUTION If you smell gas during the lighting procedure, immediately shut off the gas supply until the leak has been corrected. WARNING In the event of main burner ignition failure, a 5 minute purge period must be observed prior to re-establishing ignition source.
  • Page 9 Gas Fired Full Jacket Steam Tilting Kettle Operation Daily Shutdown 1. Turn power switch “OFF.” 2. Turn thermostat “OFF.” Complete Shutdown 1. Turn power switch “OFF.” 2. Turn thermostat “OFF”. 3. Turn power supply to unit “OFF”. 4. Remove front access panel on left side and turn dial on combination valve to “OFF”. 5.
  • Page 10 Operation Gas Fired Full Jacket Steam Tilting Kettle End User Tips For easier cleaning add cold water to the kettle immediately after removing contents. When preparing foods containing vinegar or tomatoes, or those which have a high salt content, clean the kettle immediately after using to prevent pitting.

  • Page 11: Cleaning

    Gas Fired Full Jacket Steam Tilting Kettle Cleaning Cleaning Cleaning Instructions WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING Never spray water into electric controls or components! CAUTION The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION Do not use cleaning agents that are corrosive.
  • Page 12 Cleaning Gas Fired Full Jacket Steam Tilting Kettle Dairy Draw-Off Valve Cleaning 1. Remove the plug by first removing the handle, then turn the plug to line up with the pin and pull with both hands. It is important to use both hands because the plug is heavy. 2.
  • Page 13 Gas Fired Full Jacket Steam Tilting Kettle Cleaning Stainless Steel To remove normal dirt, grease or product residue from stainless steel, use ordinary soap and water (with or without detergent) applied with a sponge or cloth. Dry thoroughly with a clean cloth. Never use vinegar or any other corrosive cleaner.

  • Page 14: Maintenance

    Maintenance Gas Fired Full Jacket Steam Tilting Kettle Maintenance NOTICE Contact the factory, the factory representative or a local service company to perform maintenance and repairs. WARNING Disconnect the power supply to the appliance before cleaning or servicing. Daily 1. Wash exposed cleanable areas. Monthly 1.
  • Page 15 Gas Fired Full Jacket Steam Tilting Kettle Maintenance Thermostat The thermostat adjustment should not be changed. Check the following before changing the thermostat. 1. With kettle cold, the pressure on the pressure gauge should read in the green vacuum zone (25 to 30 inches Hg vacuum).
  • Page 16 Maintenance Gas Fired Full Jacket Steam Tilting Kettle Adding Water (Low Water Light Comes On.) It may be necessary to replenish water in the jacket when the low water indicator comes on. Do so as follows: 1. Unit should be completely cold and off. 2.

  • Page 17: Troubleshooting

    Gas Fired Full Jacket Steam Tilting Kettle Troubleshooting Troubleshooting Problem Look For Motor will not run. • No current. Check that power is being supplied to the unit. • Defective thermostat or pressure switch. • Defective motor. • Motor overload out. •...

  • Page 18: Appendix A, Material Safety Data Sheet

    Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22)
  • Page 19 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22) PAGE OF 28...
  • Page 20 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22)
  • Page 21 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22) PAGE OF 28...
  • Page 22 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22)
  • Page 23 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22) PAGE OF 28...
  • Page 24 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22)
  • Page 25 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22) PAGE OF 28...
  • Page 26 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22)
  • Page 27 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 3 (11/22) PAGE OF 28...
  • Page 28 Gas Fired Full Jacket Steam Tilting Kettle FT-40GLS A product with the Market Forge name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
