USC-M6 Series
Startup Manual
Appearance
Front View
Rear View
*Please use only VESA compatible mounting
– Detailed table stand & wall mount datasheet available
to download at Advantech's website.
IO SPEC
I/O Appearance
Camera embedded (Optional )
RFID Embedded
(optional)
75x75 VESA
MSR
(optional)
Touch Panel &
LCD Display
Cable Cover
